Summary of Contents for Konka U50SR684TC
- Page 1 U50SR684TC SMART TV Quick Start Guide Please read this manual carefully before TV operation. Retain it for future reference.
-
Page 3: Safety Information
PREFACE 1. Read this Quick Start Guide before starting Set-up. 2. Then, carefully follow the Instructions, heeding all Warnings. 3. Do Not remove the TV back cover or block the TV ventilation openings. 4. Do Not use the TV near water or a heat Source. 5. - Page 4 This symbol indicates important Ce symbole indique important instructions accompanying the les instructions accompagnant l' product. produit. This symbol indicates "dangerous voltage" Ce symbole indique « tension dangereuse » inside the product that presents a risk of à l’intérieur du produit qui présente un risque de electric shock or personal injury.
- Page 5 16. Minimum 5cm around the apparatus for sufficient ventilation; 17. Battery should be recycled or disposed as per state and local guidelines; The batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. 18.
- Page 6 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2.
- Page 7 ISED Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1.This device may not cause interference. 2.This device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 8: Package Contents
Package Contents U50SR684TC SMART TV Quick Start Guide Please read this manual carefully before TV operation. Retain it for future reference. AAA Batteries for TV x 1pcs Quick Start Guide x 1pcs Remote x 2 pcs Remote Control x 1pcs... -
Page 9: Wall Mounting Installation
Attach the Table Stands How to assemble the stand If you need to remove or assemble the stand please read the following instructions. - Before attaching/detaching the stand, make sure to turn off the TV. - Before performing work, spread cushioning over the base area to lay the LED TV on. This will prevent it from being damaged. -
Page 10: Front Panel
To use the more advanced features, you must use the remote control. Remote Control Sensor POWER(In the standby mode, press to turn on the TV. In the boot state, short press to shut down.) Specifications U50SR684TC Model Display size 50" Diagonal (max.) LED panel resolution... -
Page 11: Connect The Tv
Connect The TV 1. Insert the female end of the Power Cord into the back of the TV. Then carefully plug the standard AC plug end into a 100-240V AC outlet. 2. If you are connecting other devices to the TV, utilize the appropriate optional cables and connect to the appropriate ports on the back or side of the TV. - Page 12 External Equipment TV label Cable VHF/UHF Antenna ANT/CABLE Cable ANT OUT Antenna HDMI VIDEO EQUIPMENT VIDEO Yellow AV IN White Camcorder SPDIF Audio Receiver HEADPHONE The TV can be connected to the following devices: Cable Box, Satellite Box, Antenna, Video Game, Stereo System, Sound Bar, Headphones, Blu-ray Player, DVD Player, VCR, Streaming Box or Stick, Camcorder, etc.
-
Page 13: Prepare The Remote Control
Prepare The Remote Control Remove the battery cover and insert the provided batteries. Then replace the battery cover. Installing Batteries Open the battery compartment cover on the back side. Battery Cover Insert two 1.5V AAA size batteries in correct polarity. Don´t mix old or used batteries with new ones. -
Page 14: Remote Buttons
Remote Buttons 1. INPUT: Press to open the input source list. 2. POWER: Turn the TV on and off. 3. Profile: Switch profile. 4. Google Assistant: Open Google Assistant. 5. Settings: Access the settings (direct or through the dashboard in GTV) from any place in the system. s pqtu 6. - Page 15 SET-UP THE TV (Using the Remote Control) Initial Setup 1. Press the Power Button at the Top of the Remote. Note: TV Controls on the TV are located on the bottom or on the side of the TV. (If the TV is in Boot State, a long press on the Power Button under the TV might be necessary.) 2.
-
Page 16: Troubleshooting
Trouble Shooting Having trouble? Don’t worry, it’s usually an easy fix. After Auto Tuning only Check your area is covered by Digital Video Broadcasts. some channels are Try re-tuning or manually tuning missing channels. available Check that you are using the correct antenna type. Check if the channel has been blocked in the main menu Channel cannot be settings. - Page 17 This product has been sold under the responsibility of Treasure Creek Limited. KONKA logo are trademarks used under license by Treasure Creek Limited. All other products, services, companies, trademarks, trade or product names and logos referenced herein are the property of their respective owner.
