Summary of Contents for Janam GT1
- Page 1 User Manual GT1 Head Unit Technology at Work® Version 2 April 2022 © 2022 Janam Technologies LLC. All rights reserved.
- Page 2 Janam Technologies LLC will at no stage be responsible for the inability or failure of the Third Party Materials to operate on this device or in interaction with any other devices of the purchaser. To the maximum extent permitted by law, Janam Technologies LLC disclaims all liability for any claims, demands, suits or actions, and more specifically —...
-
Page 3: Table Of Contents
Introduction Key Features Equipment Hardware Product Specifications Initial Setup Pedestal Assembly Battery Door Removal & Application Battery Insertion & Removal XT2+ / XT3 Insertion 8 - 9 Power On & Off Attachable Wheels Connect Battery Charger Janam Technologies LLC Contents... -
Page 4: Product Overview
Powered by a large-capacity battery with over 24 hours of operating time, GT1 delivers robust, no-touch scanning of 1D/2D barcodes, RFID tags on tickets and wristbands, Apple Wallet passes and Google Pay passes from any location in the venue.! Attention-grabbing LEDs and audio alerts allow a single attendant to monitor... -
Page 5: Key Features
PHYSICALLY UNTETHERED SOFTWARE INTEGRATION DURABLE BUILD High-capacity battery provides Integrates with virtually all Withstands exposure to 24+ hours of continuous operation third-party ticketing software light dust and rain on a single charge Janam Technologies LLC... -
Page 6: Equipment Hardware
User Manual Equipment Hardware High-visibility LEDs NFC reader Multi-touch capacitive screen 1D/2D barcode reader High-capacity battery Janam Technologies LLC... -
Page 7: Product Specifications
AC input: 110-240v, 50/60HZ Max charge voltage: 36V-42V Cycle life: ~2,000 cycles Charging time: Approx. 6 hours I/O on GT1 includes power input jacks for wall adapter and battery, ethernet port, and USB port Operating Temperature -4º to 140ºF / -20°C to 60°C Storage Temperature -13º... -
Page 8: Initial Setup
Remove the single screws on both sides of the pedestal while in folded position. Raise the folded top half of GT1, bending it at the hinge until the stem of the pedestal is fully vertical. At the hinge, securely fasten the top and bottom halves of GT1 by inserting the appropriate screws into the holes on the sides of the device. - Page 9 On the back side of the pedestal, there is a small knob at the top of the battery door. Using a flathead screwdriver, turn the knob counterclockwise 90° to unlock. Once unlocked, tip the door backwards and lift it up and out of place to remove. To apply the battery door, reverse this process. Janam Technologies LLC...
- Page 10 Initial Setup Battery Insertion There is a black power cord native to the GT1 pedestal. Ensure that the power cord is laced through the designated hole at the top of the battery holder. Screw the black power cord into the top of the battery, as depicted below.
- Page 11 Using one hand, continue to hold the mobile device in place. Secure the mobile device in place by sliding the clasps on top of both sides of the mobile device holder downward. Locked in place Janam Technologies LLC...
- Page 12 User Manual Initial Setup XT2+ / XT3 Insertion (continued) Slide the NFC / RFID plate downward into its original position. To remove the mobile device, reverse the steps taken for insertion. Janam Technologies LLC...
- Page 13 At the top of the battery, there is a red power button. On the red power button, the line symbol means “power on” and the circle symbol means “power!off”. Toggle the switch to turn on or off. Janam Technologies LLC...
- Page 14 floor. Align the hole in the attachable wheels with the hole in the base of the pedestal. Insert the attachable wheels key into the aligned holes. Tilt the pedestal backwards to utilize attachable wheels. Janam Technologies LLC...
- Page 15 RF exposure and compliance.Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf. Janam Technologies LLC...
