Summary of Contents for AMAZONEN-Werke AMACO
- Page 1 Operating manual AMAz AMACO Hectare meter Please read this operating manual before first MG3730 commissioning. BAG0028.0 04.06 Printed in Germany Keep it in a safe place for future use!
- Page 2 Only in this way could you be satisfied both with the machine and with yourself. This goal is the purpose of this instruction manual. Leipzig-Plagwitz 1872. Amaco BAG0028.0 04.06...
- Page 3 Document number: MG3730 Compilation date: 04.06 Copyright AMAZONEN-WERKE H. DREYER GmbH & Co. KG, 2006 All rights reserved. Reprinting, even of sections, only possible with the approval of AMA- ZONEN-WERKE H. DREYER GmbH & Co. KG. Amaco BAG0028.0 04.06...
- Page 4 Dear Customer, You have chosen one of the quality products from the wide product range of AMAZONEN-WERKE, H. DREYER GmbH & Co. KG. We thank you for your confidence in our products. On receiving the machine, check to see if it was damaged during transport or if parts are missing.
-
Page 5: Table Of Contents
7.2.1 Disconnecting the sensor cable plug from the calculator ............26 Protecting the calculator ......................26 Faults ......................27 Checking the functions......................27 Checking the battery voltage ....................27 Checking the functions of the calculator ................27 Checking sensor ”ha” for function..................28 Amaco BAG0028.0 04.06... -
Page 6: User Information
Number items in diagrams Numbers in round bracket refer to items in diagrams. The first number refers to the diagram and the second number to the item in the figure. Example: (Fig. 3/6) • Figure 3 • Item 6 Amaco BAG0028.0 04.06... -
Page 7: General Safety Instructions
For the health and safety of the user or third persons, • For the machine, • For other goods. Only use the machine • For the purpose for which it was intended. • In a perfect state of repair. Eliminate any faults immediately, which could impair safety. Amaco BAG0028.0 04.06... - Page 8 • Independently-executed construction changes to the machine. • Insufficient monitoring of machine parts, which are subject to wear. • Improperly executed repairs. • Disasters through the impact of foreign bodies and acts of God. Amaco BAG0028.0 04.06...
-
Page 9: Representation Of Safety Symbols
Non-compliance with these instructions can cause faults on the machine or in the environment. NOTE Indicates handling tips and particularly useful information. These instructions will help you to use all the functions of your machine to the optimum. Amaco BAG0028.0 04.06... -
Page 10: Organisational Measures
ο Ensure that the retrofitted electrical and electronic compo- nents comply with the EMC directive 2006/42/EEC in the appropriate version and carry the CE label. Amaco BAG0028.0 04.06... -
Page 11: Product Description
Product description Product description This chapter: • Provides a comprehensive overview of the AMACO structure. • Provides the names of the individual modules and controls. Overview • Scope of delivery and spare part numbers Fig. 1 Description: Part-No. Quantity: Electronic hectare meter 954671 (including. -
Page 12: Intended Use
Retainer for magnet Self thread cutting screw M4x10 Spring washer Intended use AMACO is exclusively designed to function as display- and meter- ing- and monitoring device for agricultural machinery. The intended use also includes: • Compliance with all the instructions in this operating manual. -
Page 13: Conformity
Product description Conformity Directives / standards The AMACO fulfils the: • Machines directive 2006/42/EC • EMC directive 2004/108/EEC Amaco BAG0028.0 04.06... -
Page 14: Structure And Function
Structure and function Structure and function The following chapter provides information on the AMACO struc- ture and the functions of the individual components. Method of operation The AMACO is an electronic hectare meter displaying the worked area. Structure • Display (Fig. 2/1). - Page 15 1. sensor “ha“ 2. magnet gearbox shaft Fig. 5 Precision seeders ED Fig. 6 shows the mounting points of the sensor ”ha” and of the magnet to the gearbox shaft 1. sensor “ha“ 2. magnet gearbox shaft Fig. 6 Amaco BAG0028.0 04.06...
-
Page 16: Fitting Instruction
2. Fix magnet cable to the seed drill with ad- hesive plates and with cable ties. The stick- ing areas must be clean and free of grease/oil. CAUTION Place sensor cable in such a way that the cable will not be damaged during operation. Fig. 8 Amaco BAG0028.0 04.06... -
Page 17: Fitting Magnet And Sensor "Ha" To The Two Range Gearbox
8. Fix magnet cable to the seed drill with ad- hesive plates (Fig. 9/10) and with cable ties. The sticking areas must be clean and free of grease/oil. 9. Reinsert clip pin (Fig. 9/1) into the gearbox hollow shaft. Amaco BAG0028.0 04.06... -
Page 18: Fitting And Magnet And Sensor "Ha" For Precision Airseeder/Planter Ed
In any case, at this kind of fitting the factor should be calculated accord- ing to see on page 23 and be pro- grammed together with the working width according to see on page 24. Fig. 12 Amaco BAG0028.0 04.06... -
Page 19: Commissioning
The latest programmed implement-No., e.g. F.4 If the display shows [-bl-] switch off calculator (see on page 25) and exchange batteries (see on page 16). For the AMACO to correctly measure the worked area, the following must be entered according to the machine: •... -
Page 20: Entering Machine Code
F. 8 6.0 m 18.0 72.0 F. 9 D8 SUPER Tyres 11.5/80-15 Number of crank turns at the wheel Working width Code 1/40 ha 1/10 ha 4.5 m 22.0 88.0 F. 10 6.0 m 16.5 66.0 F. 11 Amaco BAG0028.0 04.06... - Page 21 F. 22 3.2 m F. 23 3.6 m F. 24 4.0 m F. 25 4.2 m F. 26 4.5 m F. 27 4.8 m F. 28 5.4 m F. 29 6.0 m F. 30 6.4 m F. 31 Amaco BAG0028.0 04.06...
-
Page 22: Entering Code
-key for 2 seconds, as soon as in the display the desired code is shown. The code then has been entered (pro- grammed). If you do not press the -key the displayed (flicking) code will be programmed automatically after 10 seconds. Amaco BAG0028.0 04.06... -
Page 23: Entering Machine Factor And Working Width
2. Hereby count the number of turns (z) of the magnet on the gear- box shaft. 3. Calculate the factor from the values determined: L (m) x 100 factor = Example: L = 100 m z = 59.5 100 (m) x 100 factor = 59.5 factor = 168.1 Amaco BAG0028.0 04.06... -
Page 24: Programming (Entering) Factor And Working Width
Continue this way until the working width (e.g. [_3.00] for 3 m working width) has been set. 5. Press -key until the implement-No. ”F.0” appears. The factor which you have programmed and the programmed working width have been stored under the code ”F 0”. Amaco BAG0028.0 04.06... -
Page 25: Use Of The Machine
After switching off the calculator stays in waiting position, • until it receives an impulse from the sensor ”ha” or • until a key is pressed. Before exchanging the batteries switch off the calculator not to loose any data from the memory. Amaco BAG0028.0 04.06... -
Page 26: Disconnecting The Sensor Cable Plug From The Calculator
Inside vehicles which park in full sunshine high temperatures occur. Do not expose calculator to high temperatures over a longer period. The calculator can be damaged by this. During winter, store the computer in a frost-safe room. Amaco BAG0028.0 04.06... -
Page 27: Faults
The calculator processes the impulses simulated by the bridging over of the poles and shows this by adding in the display. 4. If the calculator does not process the im- pulses properly it must be exchanged Fig. 13 Amaco BAG0028.0 04.06... -
Page 28: Checking Sensor "Ha" For Function
→ If the calculator does not process the impulses correctly the sensor must be exchanged. → If the calculator operates properly: Reduce the gap between sensor and magnet on the seed drill. Amaco BAG0028.0 04.06... - Page 29 Notes Amaco BAG0028.0 04.06...
- Page 30 H. DREYER GmbH & Co. KG Postfach 51 Tel.: + 49 (0) 5405 501-0 D-49202 Hasbergen-Gaste Fax: + 49 (0) 5405 501-234 Germany e-mail: amazone@amazone.de http:// www.amazone.de Plants: D-27794 Hude • D-04249 Leipzig • F-57602 Forbach Branches in England and France Manufacturers of mineral fertiliser spreaders, field sprayers, seed drills, soil cultivation machines, mul- tipurpose warehouses and communal units...
