Summary of Contents for Zenit HELIOS-40-2
- Page 1 Photographic lens HELIOS-40-2 User manual...
- Page 2 PURPOSE The photographic lens “Helios-40-2” is interchangeable lens for “Zenit” series cameras. It has adjustable aperture value stopper. The lens is fast, and it is purposed to shoot portraits, low light outdoor scenes, fast moving objects etc. SPECIFICATIONS Focal length...
- Page 3 THE MOUNT FEATURES The mount is made taking into account application field of the lens. Besides its focusing mount, it has the movable focusing mechanism mounted onto the bracket (10) which allows putting it onto a tripod with the camera oriented either vertically or horizontally relatively to the object. The position can be secured with the crew (11).
- Page 4 You should feel a click confirming that the ring (4) is set into a discrete position. Then you can focus the camera by the ground glass, turn the ring (6) till stop, and press the camera shutter release button. When you turn the ring till stop (required aperture value is set therefore), index mark (5) become aligned with the index mark (3).
