Worldwide WSIQ-COM-I8 Instructions Manual

Digital input smart card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions
Digital Input Smart Card
(WSIQ-COM-I8)
Product Compatibility
The Digital Input Smart Card is suitable for use with WSIQ soft starters running user
interface software version 50.x.
This user manual (710-19981-00A) is compatible with WSIQ soft starters using parameter
list version 20.x.
To check the versions of software currently installed in the starter, view the Starter
Information screen or use Software Versions in the Setup Tools.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WSIQ-COM-I8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Worldwide WSIQ-COM-I8

  • Page 1 Instructions Digital Input Smart Card (WSIQ-COM-I8) Product Compatibility The Digital Input Smart Card is suitable for use with WSIQ soft starters running user interface software version 50.x. This user manual (710-19981-00A) is compatible with WSIQ soft starters using parameter list version 20.x.

  • Page 2: Table Of Contents

    Disclaimer Digital Input Smart Card Contents Disclaimer .......................... 2 Warnings ..........................2 Overview ..........................3 Setup Procedure Overview ....................3 Installation ......................... 4 Configuration ........................5 Operation ......................... 16 Parameter record ......................16 Specifications ........................16 Disclaimer The examples and diagrams in this manual are included solely for illustrative purposes. The information contained in this manual is subject to change at any time and without prior notice.

  • Page 3: Overview

    Digital Input Smart Card Overview Overview Operation The digital input smart card provides an additional eight digital inputs, allowing the starter to connect to external devices for protection and control. The smart card can trip, start or stop the starter in response to the state of the digital inputs. The starter’s response can be individually selected for each input.

  • Page 4: Installation

    Installation Digital Input Smart Card Installation Installing the Expansion Card 1. Push a small flat-bladed screwdriver into the slot in the centre of the expansion port cover, and ease the cover away from the starter. 2. Line up the card with the expansion port. Gently push the card along the guide rails until it clicks into the starter.

  • Page 5: Configuration

    Digital Input Smart Card Configuration Configuration Input type (normally open/normally closed) The default state of each input can be selected via DIP switches on the smart card, or via the parameters in the soft starter. The default setting for all inputs is software selection and disabled.
  • Page 6 Configuration Digital Input Smart Card Active state The smart card can be configured to respond to each input in selected operating states only. 20505.A Time A Any Start command Full voltage B Operating C Ready Stop command End of stop D Starting only Restart delay Running only...
  • Page 7 Digital Input Smart Card Configuration Delays The smart card can be configured with delays before responding to each input. Initial delay • After a start command is received, the smart card will wait for the specified time before monitoring the input. •...
  • Page 8 Configuration Digital Input Smart Card Customise the input name The name associated with each input can be customised. The input name is used in the event log, and is displayed on the keypad if the input trips the starter. Custom names must be loaded into the soft starter via the USB port, using a plain text (.txt) file.
  • Page 9 Digital Input Smart Card Configuration Soft Starter Programmable Parameters Operating parameters for the smart card are set and stored in the soft starter. Parameters can be configured via the main menu, or uploaded using the USB Save & Load function. For details on how to configure the soft starter, refer to the soft starter user manual.
  • Page 10 Configuration Digital Input Smart Card 30E – Input 1 Action Options: Start The smart card will send a start command when the input activates. The smart card will only send a start command if the starter is in ready state. If the starter is not ready when the input activates, but changes to ready while the input is still active, the start command will be sent.
  • Page 11 Digital Input Smart Card Configuration 32 Input 3 Configuration 32A – Input 3 Type Options: Disabled (default) Normally Open (N/O) Normally Closed (N/C) Description: Selects whether the input is normally open, normally closed or disabled. 32B – Input 3 Active State Options: Any (default) Running Only...
  • Page 12 Configuration Digital Input Smart Card 33E – Input 4 Action Options: Start Stop Trip Starter (default) Description: Selects the smart card’s action when the input activates. 34 Input 5 Configuration 34A – Input 5 Type Options: Disabled (default) Normally Open (N/O) Normally Closed (N/C) Description: Selects whether the input is normally open, normally closed or disabled.
  • Page 13 Digital Input Smart Card Configuration 35C – Input 6 Initial Delay Range: 00:00 - 10:00 (minutes:seconds) Default: 0 second Description: Sets a delay before the smart card will monitor the input. 35D – Input 6 Action Delay Range: Default: 00:00 - 10:00 (minutes:seconds) 1 second Description: Sets a delay after the input activates, before the smart card performs the selected action.
  • Page 14 Configuration Digital Input Smart Card 37B – Input 8 Active State Options: Any (default) Running Only Ready Stopping Only Starting Only Operating Description: Selects when the starter will monitor the input. 37C – Input 8 Initial Delay Range: Default: 00:00 - 10:00 (minutes:seconds) 0 second Description: Sets a delay before the smart card will monitor the input.
  • Page 15 Digital Input Smart Card Configuration 38C – Input 3 Trip Action Options: Soft Trip and Log Trip and Reset Soft Trip and Reset Warn and Log Trip Starter (default) Log Only Description: Selects the soft starter’s action when the smart card sends a trip command. 38D –...

  • Page 16: Operation

    Operation Digital Input Smart Card Operation Input state To review the current state of each input, use Setup Tools > Card Input State. Card Input State Physical: 00011010 Logical: 10001101 The top line of the screen shows whether 24 V is present on the input (=1) or not present (=0).
