8K CFM OPEN DUST
SAFETY, OPERATION AND
COLLECTION
AD076573
MAINTENANCE MANUAL
8K CFM OPEN DUST COLLECTION
Serial #: ________________
TOLL FREE: 1-800-888-1352 • PH: 1-541-855-1512 • FAX: 1-541-855-1165
Sweed Machinery, Inc. • 653 2nd Avenue • P.O. Box 228 • Gold Hill, OR 97525 USA
• Email: sweed@sweed.com
www.sweed.com
Revision
Date
Written By
Description of Change
Reviewed
1
10/3/2022
Dave L
DAL
UPDATED ISSUE OF OPERATIONS MAINTENANCE MANUAL
Advertisement
Summary of Contents for SWEED 8K CFM
- Page 1 MAINTENANCE MANUAL 8K CFM OPEN DUST COLLECTION Serial #: ________________ TOLL FREE: 1-800-888-1352 • PH: 1-541-855-1512 • FAX: 1-541-855-1165 Sweed Machinery, Inc. • 653 2nd Avenue • P.O. Box 228 • Gold Hill, OR 97525 USA • Email: sweed@sweed.com www.sweed.com Revision...
- Page 2 Any misuse of Sweed Machinery equipment can be dangerous. all operators should be familiar with the general operating instructions and warnings.
- Page 3 Sweed products. * Although all bolts are torqued at the Sweed Facility it may be advantageous to double check torques if the machine has been twisted or jarred during shipping. Additionally, the machine will be required to mount to a level floor.
- Page 4 8K CFM OPEN DUST COLLECTION Page 4 of 10 Figure 1: Sweed Machinery Machine Labels Revision Date Written By Description of Change Reviewed 10/3/2022 DAVE L UPDATED ISSUE OF OPERATIONS MAINTENANCE MANUAL...
-
Page 5: Operation
8K CFM OPEN DUST COLLECTION Page 5 of 10 Initial Startup 03.A Duct Work The inlet ducting must be inspected to assure it is properly supported, installed and complete. The ductwork is not designed to accept loads of any kind. Ducts should be free of foreign material such as welding rods, tools etc. -
Page 6: Troubleshooting
8K CFM OPEN DUST COLLECTION Page 6 of 10 Dust Disposal (Clean the filter.) 05.A Power system down and lock out tag out according to your company’s maintenance safety policy. (see Figure 2), 05.B Using the Shaker Lever push and pull the lever vigorously to loosen any material caught in the sleeve. - Page 7 8K CFM OPEN DUST COLLECTION Page 7 of 10 Troubleshooting cont… Dust Escaping Cause Solution 14.A Dust Coming from Inspect lid to see if it is damaged. Remove lid. Empty Barrel if necessary. Barrel Lid Clean off top of barrel where the lid seats and reseal.
- Page 8 8K CFM OPEN DUST COLLECTION Page 8 of 10 Maintenance Log Date Parts Replaced / Part # Performed By Hours / Time of Use Revision Date Written By Description of Change Reviewed 10/3/2022 DAVE L UPDATED ISSUE OF OPERATIONS MAINTENANCE MANUAL...
- Page 9 8K CFM OPEN DUST COLLECTION Page 9 of 10 Upper Chamber Hatch Filter Bag (80) Shaker Lever Figure 2 Hose Clamps (8) Shaker Lever 8” Ø Vacuum Hose Quick Clamp Barrel Lid Figure 3 Revision Date Written By Description of Change...
-
Page 10: Warranty
Sweed Machinery, Inc., be liable for special, indirect, incidental or consequential damages, however arising. Sweed Machinery, Inc does not warranty this machine to meet the requirements of any safety codes of any state, municipality, or other jurisdiction, and the purchaser assumes all risk and liability whatsoever resulting from the use thereof whether used singularly or in combination with other machinery or apparatus.
