1 GENERAL INFORMATION

Smena-Symbol is modern 35mm camera purposed for wide variety of photo amateurs.

It has coated lens, optical viewfinder, central shutter with wide range of speed, weather/distance scale,

flash lamp synchronizer.

Distinctive feature of the Smena-Symbol camera is use of symbolic system to set exposure and distance.

The camera can work at temperature range from –15 to +45°C, and shouldn't be exposed to direct sun

radiation or atmospheric precipitations.

Please read this manual carefully before using the camera.

2 SPECIFICATIONS

Film width

Frame size

Frame count

The lens is coated 3-elemet anastigmat:

Focal length

Relative aperture

Shutter speeds

Distance scale

Film speed scale

Filter mounting thread

The camera contains 0.012g of silver.

35mm

24x36mm

40mm

1:4

1/250, 1/125, 1/60, 1/30, 1/15, "B"

From 1m (3.5ft) to infinity

16-250 GOST/ASA or 13-25 DIN

35.5mm

Table of Contents

Need help?

Do you have a question about the SMENA SYMBOL and is the answer not in the manual?

Questions and answers

Summary of Contents for OMO SMENA SYMBOL

Page 1 1 GENERAL INFORMATION Smena-Symbol is modern 35mm camera purposed for wide variety of photo amateurs. It has coated lens, optical viewfinder, central shutter with wide range of speed, weather/distance scale, flash lamp synchronizer. Distinctive feature of the Smena-Symbol camera is use of symbolic system to set exposure and distance. The camera can work at temperature range from –15 to +45°C, and shouldn’t be exposed to direct sun radiation or atmospheric precipitations.
Page 2 3 DELIVERY SET 1. The camera Smena-Symbol 1 2. The camera case 3. The packing box 4. User manual 4 CONSTRUCTION 4.1 Camera parts (pictures 1, 2, 3, 4, 5, 6) 1. Viewfinder. 2. Indexed ring. 3. Lens. 4. Aperture ring. 5.
Page 3 4.2 Purpose of the camera parts The weather symbols scale is purposed to determine and set of the shutter speed. The program of exposure setting for different films is given in the table below. The film sensitivity The weather symbols and corresponding shutter speeds (seconds) Thunderstorm Cloudy Sun in...
Page 4 The lens diaphragm controls diameter of the aperture. You can set the aperture value turning the aperture ring. You may decrease the aperture to get larger depth of field or if object is too bright for selected shutter speed. Picture 5 Picture 6 Picture 7 Steps of the aperture and shutter speed scales are calculated such way that changing either of them by...
Page 5 6 OPERATION Set the shutter speed and aperture value. It can be done either by weather symbols or by shutter speed and aperture scales. To set the shutter speed and aperture value using weather symbols, it is necessary to set the film speed first on the scale on the front parts of the lens, turning the ring with indexes till align with corresponding film speed.
Page 6 To get the camera ready for the next picture, pull the lever till stop – this will cock the shutter and advance the film by one frame. The camera allows using of a flash lamp (Picture 13). To synchronize moment of the flash with moment of the fully opened shutter, there is built in synchronizer.
