- Page 1 Dual Channel PT100 / PT1000 Datalogger BG 38PT Professional Temperature Measuring Instrument Instruction manual V2.2...
-
Page 3: Table Of Contents
Contents Document Description...................................... 1 1. Safety Instruction......................................2 2. Intended Use......................................... 3 3. Product Description...................................... 4 3.1 Display and Control Elements................................. 4 3.2 Interface......................................6 3.3 Power Supply.....................................6 4. Operation........................................7 4.1 Preparation......................................7 4.2 Turn On/Off......................................7 4.3 Backlight......................................7 4.4 Multi-Functional Button..................................8 4.5 Channel Mode.................................... -
Page 4: Document Description
Document Description This section provides important advise while using this instrument. This document contains all the information that is required about how to use this instrument safely and effectively. Please read it carefully and be familiar with the operation of this product. Button Introduction Short Press: Press the button and then lift it, there will be a beep when pressed. -
Page 5: Safety Instruction
1. Safety Introduction This section describe the general rules that must be obeyed and followed in order to use this product safely. Avoid Personal Injury/Equipment Damage Do not use this instrument to measure on alive parts or nearby. (Especially for high voltage) ... -
Page 6: Intended Use
2. Intended Use This chapter describes the intended using range of this product. Use this product only for those applications which it is designed specifically. This product is a dual-channel high-precision measuring instrument with calibration for temperature measurement. Accurate Measurement: Whether it is a low-temperature cold storage or a high-temperature boiler, PT100 and PT1000 sensors can ensure accurate measurement across the entire range. -
Page 7: Product Description
3. Product Description This section describes an overview of the product components and their functions. 3.1 Display and Control Elements Instrument Overview Probe Interface LCD Display USB Interface Button Battery Case... - Page 8 Button Button Function Multi-functional button 1, its function will be displayed at the bottom left of the screen Turn on the instrument, turn off the instrument(long press) Turn on/off the backlight Multi-functional button 2, its function will be displayed at the bottom right of the screen Switch the type of probe PROBE Keep the current reading...
-
Page 9: Interface
Regional Division Status Area Main Display Area Indicator Area Dividing area is to facilitate you quickly to locate the position of the icon or reading you want to view. 3.2 Interface Probe Interface The pluggable probe can be connected to the instrument through the probe interface. —... -
Page 10: Operation
4. Operation This section describes operations frequently performed when using this product. 4.1 Preparation Tear the protective film off on the display. Put in the battery/rechargeable battery and pay attention to the polarity of the battery. Connect the plug of the probe to the probe interface of the instrument. ... -
Page 11: Multi-Functional Button
4.4 Multi-Funcitonal Button There are two multi-functional buttons for this instrument: . Their specific functions will be displayed in the indicator area. Common Function for F1 Common Function for F2 Config Enter the configuration interface Menu Enter the menu interface Enter Enter the next option interface Exit the configuration interface or menu... -
Page 12: Channel Mode
4.5 Channel Mode This instrument has two platinum resistance measurement channels and four channel modes, which can be used flexibly to meet various measurement needs. As shown in the following table: Dual channel merge Single channel Single channel Dual channel Channel Mode mode mode one... -
Page 13: Instrument Settings
Single Channel Trend Chart High limit alarm value maximum temperature,unit °C minimum temperature,unit °C Temperature curve Timeline (negative sign indicates Low limit alarm value this is the past time in seconds) ‼ The trend graph maximum temperature is set to 105% of the maximum measured temperature over the past 70 seconds. -
Page 14: Data Settings
Configuration mode is opened ,move the cursor to "Channel Mode" and press (Enter). Press to select mode. Press (Ok)to confirm or press (Back)to exit. To set the sound when pressing button Enter the configuration interface and move the cursor to "Sound". ... - Page 15 ‼ Press to switch menu options. If there is a triangle icon at the right end of the cursor, it means that there are sub-options, press to switch. ‼ The options related to measurement data are in the menu interface. ‼...
-
Page 16: Calibration
In dual channel difference mode, enter the menu interface. ‼ The basis of the temperature difference alarm is that the absolute value of the temperature difference of the dual channels is greater than the temperature difference alarm value. Move the cursor to "Diff-Alarm", press (Set)to turn on or off the temperature difference alarm. - Page 17 Add a calibration point Enable the calibration mode and select the probe type to be calibrated in the "Select probe type" interface. ‼ Each calibration point displays the temperature value before calibration, such as "Point 1: -100.00°C", which means the temperature value of the first calibration point before calibration is -100.00°C.
-
Page 18: Data Logging (Model With Data Recording Function)
becomes "Remove point 2", and press (Yes) to remove the calibration point data. 4.9 Data Logging (Model with Recording Function) Enable the recording mode Turn on the instrument and enter the menu interface to ensure sufficient power. ‼ This product supports 20000 data points. - Page 19 View storage capacity Enable the logging mode and enter the Logging interface. Move the cursor to "Flash", press (View)to enter the storage capacity interface. Regenerate files ‼ When the file is damaged, it can be used to restore the file. If you want to generate files in other formats, please set the file format before generating again.
-
Page 20: Measuring
instrument at this time. If pressing (Exit), the instrument will only be powered by the computer but not connected to the computer. File format settings Enable the record mode and enter the Log Setting interface. Move the cursor to "Set File Format", press (Set)to enter the text format interface. -
Page 21: Maintenance
reading. When viewing the maximum, minimum and average values, press (Reset) to clear statistics. Switch unit Press to switch Celsius and Fahrenheit. ℃/℉ Switch probe In two dual channel modes, press to enter the switch probe interface, PROBE will flash in PROBE the status area. -
Page 22: Faq
7. FAQ Question Reason Solution is bright, even flashing Battery is too low Replace battery Enable the automatic shutdown Disenable the automatic function shutdown function Instrument shuts down Dead battery Replace battery automatically Use temperature exceeds the Move to a location that meets the ... -
Page 23: Specification
8. Specification Probe type PT100 PT1000 Measuring parameters Temperature(℃/℉) Measuring range -200~+800℃ 0.001℃(-99.999℃~+99.999℃) Resolution 0.01℃(-200℃~+800℃) 0.01℃(other) Accuracy ±(0.05%|t|+0.10)℃ ±(0.05%|t|+0.05)℃ Storage capacity 20000 readings (models with recording function) Measuring rate Recording interval 1~86399seconds adjustable( models with recording function) Operation temperature -10~+50℃ Storage temperature -20~+60℃(without batteries) Power supply...
