Glass Expansion IsoMist XS Operation Manual

Programmable temperature spray chamber
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IsoMist XS
TM
Programmable Temperature
Spray Chamber Operation Manual
INS-0580

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IsoMist XS and is the answer not in the manual?

Questions and answers

Summary of Contents for Glass Expansion IsoMist XS

  • Page 1 IsoMist XS Programmable Temperature Spray Chamber Operation Manual INS-0580...

  • Page 2: Table Of Contents

    Safety Information Graph (Data) Utilities Warning Diagnostics Flammable Samples Regulatory Compliance Faults and Corrective Action Manufacturer’s Declaration Reset IsoMist XS to Default Uninstall IsoMist XS software Before you start Service and Support Pack Contents Product Care IsoMist XS Overview General Care...

  • Page 3: Notices

    Product Record The product label situated on the underside of the IsoMist XS specifies serial number and model details. Quote this information when you contact your supplier or Glass Expansion office for service.

  • Page 4: Safety Information

    Safety Information Warning • The IsoMist XS should only be operated by people who are competent in the operation of ICP equipment and have a basic level of PC competence. • Use only the power adaptor supplied with the IsoMist XS to operate the device.

  • Page 5: Manufacturer's Declaration

    This portable transmitter with its antenna complies with FCC/IC RF exposure limits for general population / uncontrolled exposure. If this equipment does cause radio interference (which can be determined by switching off the device) contact the supplier or Glass Expansion. Glass Expansion® IsoMist XS™ Operation Manual...
  • Page 6 Glass Expansion deems the business end-users responsible for the disposal of unwanted Glass Expansion products. The business end user is obliged to deal with the product in accordance with local WEEE regulation. Glass Expansion®...

  • Page 7: Before You Start

    Before you start Pack Contents Congratulations on your purchase of your new IsoMist XS, which consists of the following items: IsoMist XS Assembly Spray Chamber Power Adaptor Ethernet Data Cable IsoMist XS USB Installation Media USB to Ethernet Adapter Glass Expansion®...

  • Page 8: Isomist Xs Overview

    IsoMist XS utilizes the Peltier effect to provide electrical cooling or heating to the spray chamber. The Set Temperature is monitored and controlled internally using electronic hardware/ software. The IsoMist XS performance can be monitored and controlled from a lab PC via Ethernet or USB with supplied dongle. IsoMist XS side...
  • Page 9 Ethernet Port or USB with supplied dongle Ethernet port/ USB Port Middleware (supplied with USB Installation Media) JVM (Java Virtual Machine) 1.6.0+ ** IsoMist XS software will need to be installed on your host PC Glass Expansion® IsoMist XS™ Operation Manual...

  • Page 10: Spray Chamber

    Quartz IsoMist XS spray chambers, or c) PFA IsoMist XS spray chambers. • IsoMist XS is usually supplied as part of a kit. The IsoMist XS kit will contain all the necessary items required to connect the IsoMist to your ICP (or sample requirements).

  • Page 11: Getting Started

    Getting Started Removing/Replacing the Spray Chamber When supplied, the IsoMist XS is already fitted with its spray chamber. If you wish to remove the spray chamber, perform the following procedure: 1. If in use, remove all connections to the IsoMist XS spray chamber.

  • Page 12: Isomist Xs Placement

    IsoMist configurations to suit the diverse variety of ICP’s currently on the market. Each IsoMist XS configuration that suits a specific OEM is referred to as a kit. In most cases, this kit will be supplied with your IsoMist package. Each kit is supplied with an Installation Guide, which will detail: •...

  • Page 13: Helix Ct Fitting

    Helix CT Fitting – Nebulizer Connection As supplied, the IsoMist XS spray chamber is fitted with a Helix CT fitting. The Helix CT is a consumable item that will need to be replaced overtime. To order replacement parts visit www.geicp.com A.

  • Page 14: Power & Ethernet Cable Connections

    Power and Ethernet cable connections Connect the power adaptor to an appropriate (refer technical specification) AC power outlet. Connect the power adaptor to IsoMist XS . Caution Use only the original power adaptor supplied with IsoMist XS. This will be appropriate for your local region.
  • Page 15 • If you are unsure about the electrical connection, check with your supervisor. • Do not connect a live power adaptor to IsoMist XS as a means to start-up. The best practice is to always use power outlet on/off switch.
  • Page 16 Option B - Step 3. Removing the Power and Ethernet Cable Grip the sleeve, use other hand to support the IsoMist XS. Squeeze sleeve between fingers to unlock the locating pin. While squeezing sleeve, pull back to remove the cable. Do not pull cable without squeezing sleeve.

  • Page 17: Software Installation

    As dispatched, IsoMist will function at the default temperature setting - Refer to the technical specifications. To monitor your IsoMist XS and modify its settings, you will need to install IsoMist software to your host PC.
  • Page 18 If the following dialogue appears, click Yes. Wait for Installation Wizard to start. Click Next. Glass Expansion® IsoMist XS™ Operation Manual...
  • Page 19 Click Next. Click Finish. Glass Expansion® IsoMist XS™ Operation Manual...

  • Page 20: Operation

    System start-up, 5 seconds* • Green LED flash and continuous: IsoMist XS is functioning. Power Down The IsoMist XS can be powered down at any time by switching off the power at the AC power outlet or clicking Power icon through the IsoMist XS software.

  • Page 21: Start Isomist Xs Application

    ® Locate IsoMist XS Application and double click to open. When IsoMist XS software is first opened it will look like this until communication is established by clicking the connect button. Refer next topic “Communication”. Glass Expansion® IsoMist XS™ Operation Manual...

  • Page 22: Communication

    IsoMist XS software screen. If you encounter problems with communication, review “Getting Started” section. If necessary, refer to the diagnostic section of this manual. Once connection is established, IsoMist XS software will look like this: Icon indicates commuunication Glass Expansion®...

  • Page 23: Software Functions

    When communication is established you will be presented the following screen: Set Chamber Temperature Dialogue Box Delta T Indicator: Difference between Select Temperature unit either in Celsius or Fahrenheit reference temp and the Isomist XS (chamber) temperature Indicates Power Actual chamber...
  • Page 24 Switch Off At IsoMist XS provides the facility to switch off the device at a particular time. To do this select File►Switch Off At. Select your desired switch off time in the calendar dialogue and press OK. After a second or two the status indicator at the top right of the program will display the Switch Off Time as selected.

  • Page 25: Graph (Data) Utilities

    XS software) will present the following options: Properties Window to make changes to graph format. Save as Window to save the current graph image to your PC. Print Window to format and print current graph image using your printer. Glass Expansion® IsoMist XS™ Operation Manual...

  • Page 26: Diagnostics

    The following table lists a number of actions that can be taken should you encounter a problem with the IsoMist XS. If you cannot resolve the problem after completing these instructions, please contact your IsoMist XS supplier or Glass Expansion.

  • Page 27: Reset Isomist Xs To Default

    Reset IsoMist XS to Default Settings To return IsoMist XS settings to default (Factory Settings) perform the following: 1. Power down IsoMist XS. 2. Turn on power, IsoMist XS will now start as normal. IsoMist XS can also be reset to default from the software screen: Options►Advanced►Factory Defaults...

  • Page 28: Uninstall Isomist Xs Software

    First, you must close any other programs you may have running and it is recommended you restart your PC when prompted. How to uninstall Detach the IsoMist XS Ethernet cable from your PC before removing the IsoMist XS software. 1. Click Start ►...
  • Page 29 4. Scroll Down Program list, Locate then select: IsoMist XS 1.0 Click ►Uninstall/Change ►Yes 5. Click Next. 6. Click Finish. Note: IsoMist XS Software can also be uninstalled by running “uninstall.exe” within the IsoMist XS Folder. Glass Expansion® IsoMist XS™ Operation Manual...

  • Page 30: Service And Support

    • Is there adequate ventilation around the IsoMist XS? • Have you reviewed the Diagnostic section in this manual? • Is the ICP Instrument functioning correctly? Should none of these actions resolve the problem, contact your IsoMist XS supplier or Glass Expansion. Asia Pacific...

  • Page 31: Product Care

    Ensure components associated with the IsoMist XS are not dropped, nor have heavy objects dropped or stored on top of them. If you know or suspect a heavy object or liquid has been dropped onto the IsoMist XS or the power adaptor, turn off device immediately and contact the IsoMist supplier or Glass Expansion.

  • Page 32: Warranty

    12-month returning to us. warranty. The consumable items listed here are Glass Expansion reserves the right to refuse warranted only that they are free from defects in acceptance and/or inspection of any returned...
  • Page 33 For more information please visit www.geicp.com or contact one of our offices below Asia Pacific 6 Central Boulevard, Port Melbourne, VIC 3207, Australia Telephone: +61 3 9320 1111 Email: enquiries@geicp.com Americas 31 Jonathan Bourne Drive, Unit 7 Pocasset, MA 02559, USA Telephone: 508 563 1800 Email: geusa@geicp.com Europe...
