User Manual of Product 1:
Cooler Master MasterBox TD500 Mesh White Airflow ATX
Mid-Tower with Polygonal Mesh Front Panel, Crystalline
Tempered Glass, E-ATX up to 10.5", Three 120mm ARGB
Lighting Fans
User Manual of Product 2:
Seagate BarraCuda 2TB Internal Hard Drive HDD – 3.5 Inch
SATA 6Gb/s 7200 RPM 256MB Cache – Frustration Free
Packaging (ST2000DM008/ST2000DMZ08)
Advertisement
Table of Contents
Related Manuals for Cooler Master MASTERBOX TD500 MESH
Summary of Contents for Cooler Master MASTERBOX TD500 MESH
- Page 1 User Manual of Product 1: Cooler Master MasterBox TD500 Mesh White Airflow ATX Mid-Tower with Polygonal Mesh Front Panel, Crystalline Tempered Glass, E-ATX up to 10.5", Three 120mm ARGB Lighting Fans User Manual of Product 2: Seagate BarraCuda 2TB Internal Hard Drive HDD – 3.5 Inch SATA 6Gb/s 7200 RPM 256MB Cache –...
- Page 3 SATA Product Manual Standard models ST2000DM008 100817550, Rev. F August 2018...
- Page 4 Revision History Version and Date Description of Changes Rev A, 04/03/2017 Initial release. Rev B, 06/22/2017 7 & 10: Updated Max Height to 20.20mm/0.795 in. 20: Updated Max Height in Figure 2: Mounting dimensions (1 and 2-disk models) Rev C, 10/18/2017 12: Added Figure 1: Location of the HDA temperature check point 15-18: Updated Safety, EMC, FCC &...
-
Page 5: Table Of Contents
www.seagate.com Contents Introduction ................6 About the SATA interface . - Page 6 www.seagate.com Contents Configuring and Mounting the Drive ............19 Handling and static-discharge precautions .
- Page 7 www.seagate.com Figures Figure 1 Location of the HDA temperature check point ..........12 Figure 2 Attaching SATA cabling .
- Page 8 Seagate® Technology Support Services For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate BarraCuda Product Manual, Rev. F...
-
Page 9: Introduction
1.0 Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate® BarraCuda® model drives: ST2000DM008 These drives provide the following key features: • Compliant with RoHS requirements in China and Europe. • High instantaneous (burst) data-transfer rates (up to 600MB per second). •... -
Page 10: Drive Specifications
www.seagate.com 2.0 Drive Specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: ST2000DM008 Specification summary tables The specifications listed in are for quick reference. - Page 11 Table 1 Drive specifications summary for 2TB model (continued) Drive Specification* ST2000DM008 30°C max (operating) Wet bulb temperature (max) 40°C max (non-operating) –304m to 3048m Altitude, operating (–1000 ft to 10,000 ft) Altitude, non-operating –304m to12,192m (below mean sea level, max) (–1000 ft to 40,000+ ft) Operational shock (max) 80 Gs (read) / 70 Gs (write) at 2ms...
-
Page 12: Formatted Capacity
www.seagate.com Formatted capacity Model Formatted capacity* Guaranteed sectors Bytes per sector 2000GB 3,907,029,168 4096 *One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. 2.2.1 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. -
Page 13: Start/Stop Times
www.seagate.com Start/stop times The start/stop times are listed below. Standard models ST2000DM008 Power-on to ready 11 (typical) (in seconds) Standby to ready 11 (typical) (in seconds) Ready to spindle stop 11 (typical) (in seconds) Time-to-ready may be longer than normal if the drive power is removed without going through normal OS powerdown procedures. -
Page 14: Voltage Tolerance
www.seagate.com 2.7.3 Voltage tolerance Voltage tolerance (including noise): • 5V ±5% • 12V ±10% 2.7.4 Power-management modes The drive provides programmable power management to provide greater energy efficiency. In most systems, users can control power management through the system setup program. The drive features the following power-management modes: Power modes Heads Spindle... -
Page 15: Environmental Specifications
www.seagate.com Environmental specifications This section provides the temperature, humidity, shock, and vibration specifications for Barracuda drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000ft. (305 meters), the maximum temperature is derated linearly by 1°C every 1000 ft. Refer to for base plate measurement location. -
Page 16: Shock And Vibration
www.seagate.com 2.8.5 Shock and Vibration All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.8.5.1 Operating shock These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 80 Gs (read) / 70 Gs (write) based on half-sine shock pulses of 2ms during read operations. -
Page 17: Test For Prominent Discrete Tones (Pdts)
www.seagate.com 2.9.1 Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 18: Agency And Safety Certifications
www.seagate.com 2.12 Agency and Safety Certifications Each Hard Drive and Solid State Drive ("drives") has a product label that includes certifications that are applicable to that specific drive. The following information provides an overview of requirements that may be applicable to the drive. 2.12.1 Safety certification The drives are recognized in accordance with UL/cUL 60950-1 and EN 60950-1. -
Page 19: Morocco Commodity Mark
www.seagate.com 2.12.6 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 20: Environmental Protection
www.seagate.com 2.13 Environmental protection Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. 2.13.1 European Union Restriction of Hazardous Substance Law 2.13.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate drives are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863. -
Page 21: Taiwan Requirements - Taiwan Rohs
www.seagate.com 2.13.3 Taiwan Requirements — Taiwan RoHS Taiwan RoHS refers to the Taiwan Bureau of Standards, Metrology and Inspection’s (BSMI) requirements in standard CNS 15663, Guidance to reduction of the restricted chemical substances in electrical and electronic equipment. Seagate products must comply with the “Marking of presence”... -
Page 22: Configuring And Mounting The Drive
www.seagate.com 3.0 Configuring and Mounting the Drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution •... -
Page 23: Drive Mounting
Drive mounting Users can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. Refer to Figure 3 for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: •... -
Page 24: Sata Interface
www.seagate.com 4.0 SATA Interface These drives use the industry-standard Serial ATA (SATA) interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0 to 4; multiword DMA modes 0 to 2, and Ultra DMA modes 0 to 6. For detailed information about the SATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment”... -
Page 25: Supported Ata Commands
Supported ATA commands The following table lists SATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA International Organization: Serial ATA Revision 3.0 (http://www.sata-io.org). See “S.M.A.R.T. commands” on page 30 for details and subcommands used in the S.M.A.R.T. implementation. Table 8 SATA standard commands Command name... - Page 26 www.seagate.com Table 8 SATA standard commands (continued) Command name Command code (in hex) Security Freeze Lock Security Set Password Security Unlock Seek Set Features Set Max Address Note: Individual Set Max Address Address: commands are identified by the value Password: placed in the Set Max Features register as Lock: defined to the right.
-
Page 27: Identify Device Command
www.seagate.com 4.3.1 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in on page 22. All reserved bits or words should be set to zero. - Page 28 www.seagate.com Table 9 Identify Device commands (continued) Word Description Value Capabilities: (see 7.17.7.17) 15 Shall be cleared to zero 14 Shall be set to one 4000 13:2 Reserved 1 Obsolete 0 Shall be set to one to indicate a vendor specific Standby timer value minimum PIO data-transfer cycle timing mode 0200 Retired (Obsolete)
- Page 29 www.seagate.com Table 9 Identify Device commands (continued) Word Description Value Additional Supported 15 CFast Specification Support 14 Deterministic data in trimmed LBA range(s) is supported 13 Long Physical Sector Alignment Error Reporting Control is supported 12 Obsolete 11 READ BUFFER DMA is supported 10 WRITE BUFFER DMA is supported 9 Obsolete 0000...
- Page 30 www.seagate.com Table 9 Identify Device commands (continued) Word Description Value ATA-reserved 0000 The mandatory value of the world wide name (WWN) for the drive. 108-111 Each drive will have a unique value. NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support. 112-118 ATA-reserved 0000...
- Page 31 www.seagate.com Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported. Multiword DMA mode 1 is supported. Multiword DMA mode 2 is supported. Multiword DMA mode 0 is currently active. Multiword DMA mode 1 is currently active. Multiword DMA mode 2 is currently active.
-
Page 32: Set Features Command
www.seagate.com 4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. -
Page 33: Commands
www.seagate.com 4.3.3 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disk drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T. makes a status report available to the host. - Page 34 Seagate Technology LLC AMERICAS Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100817550 Rev.
