Summary of Contents for Profelmnet FAST PACK Series
- Page 2 Children are not allowed be touch the control devices or remote transmitters. A warning sign must be placed somewhere on the barrier according to the national standard. Please keep this instruction properly for future reference. PROFELMNET |FAST-PARK SERIES...
- Page 3 Fast-Park LED LED boom < 3Μ 1,8 seconds 2 seconds Fast-Park LED LED boom <4.50Μ 3 seconds 3,50 seconds Fast-Park Folding 5 seconds Folding Boom <6Μ 6 seconds Fast-Park Fence 24V Fence Boom <4.50Μ 3 seconds 3,50 seconds PROFELMNET |FAST-PARK SERIES...
- Page 4 Barrier Direction Left-hand Barrier Right-hand Barrier Barriers Dimensions PROFELMNET |FAST-PARK SERIES...
- Page 5 During installation, turn off the power supply. Control board technical characteristics Power Supply 24VDC Current Absorption 5 Α -15 Α max Motor Type Brushless 24V Encoder Temperature -40 oC - + 85oC Control Board Protection Overcurrent Protection/ Overvoltage Protection/ Short circuit Protection PROFELMNET |FAST-PARK SERIES...
- Page 6 Control Board Connection PROFELMNET |FAST-PARK SERIES...
- Page 7 On the display, we see F-00. To navigate the menu, we use the button UP+DOWN. In order to return the initial display, we press steadily for 3 seconds the button FUNCTION/SAVE. For configuration, see the following table. PROFELMNET |FAST-PARK SERIES...
- Page 8 With your hands, move the base of the boom to its horizontal position as shown in picture Screw the screws that we unscrewed in picture 1 very well The barrier has changed direction Picture 1 Picture 2 PROFELMNET |FAST-PARK SERIES...
- Page 9 Navigate to F-21 and momentarily press the Function/Save button to enter it With OPEN or CLOSE choose the desired value for the opening speed (00-99 seconds – Default value 90) Press the "Confirm/Stop/Copy/Delete" button to save the desired value. Be careful the automation will take command. PROFELMNET |FAST-PARK SERIES...
- Page 10 See above step 2 F-07 Led boom mode 00 : Traffic Light 01 : Traffic Light 1 02 : Traffic Light 2 03 : Alarm Light F-09 Opening Angle 00-99 degrees F-10 Closing Angle 00-30 -> -6 to 0 degrees PROFELMNET |FAST-PARK SERIES...
- Page 11 -Check if any obstacle interferes with the smooth movement of the boom -Change with F-13 the current of the obstacle detection strenght - Check if the spring of the automation is correctly adjusted -The drive system has a fault PROFELMNET |FAST-PARK SERIES...
- Page 12 The motor arm must reaches and touches the corresponding limit screw in order for the barrier to lock into terminal position. It is recommended that the barrier should move under human control during manual release process. Motor arm Limit screw Limit screw Crank shaft PROFELMNET |FAST-PARK SERIES...
- Page 13 PROFELMNET |FAST-PARK SERIES...
