Cub Cadet COMMERCIAL 2004701 Parts List

Electric, Spot-Sprayer Parts List
02004701 25-Gallon, 1/4" x 25' FlexCoil Hose
Ref.
No. Part No. Description
1 00012470 Cable Tie
2 00018283 Electric Wire Harness includes:
00032615 Wire, 16-3
00032630 Shrink Tube, 3/8"
3 00018334 Wand Assembly includes:
00005173 Strainer
4 00020851 Diaphragm Pump, Flojet
5 -- Hose, 3/8"
6 00031247 Valve, 90°, 1/4 FPT
7 00032078 Nipple, 3/8 MPT Close
8 00032081 Tee, 3/8 FPT Brass
9 00032086 Fitting, Adapter, 1/4 MPT x 11/1 61
10 00032113 Elbow, 90°, 1/4 MPT x 3/8 Hose Barb
11 00034947 Cap Screw, 5/16-18 x 1/2 Hex Hd.
12 00035599 Fitting, Adapter
3/8 hose
18.0" LG.
Qty.
10ft.
4in.
3/8 hose
5.0" LG.
3/8 hose each
14.0" LG.
3/8 hose: 2.0" LG.
Run Blue Hose through
this piece and mount
to tank along with harness
using 1/2" conduit strap
Ref.
No. Part No. Description
1 13 00035600 Hose Barb, 3/8 x 90° Swivel Elbow
1 14 00035601 Filter, 30 Mesh S.S. Screen
15 00035626 Hose Barb, 3/8" x 90° Male Elbow
16 00035627 Hose Barb, 3/8 Nylon
1 17 00035628 Swivel Nut, Nylon
1 18 00035631 Hose Barb, 3/8 x 3/8 MPT
1 19 00035678 Mach. Screw, # 10-24 x 3/4 Pan Hd.
3 20 00035781 Hose Barb, 3/8 x 1/4 MPT
1 21 00035790 Conduit Strap, 1/2
1 22 00035816 Hose, 1/4" x 25', FlexCoil
1 00034896 3/8 Hose, Reinforced PVC-25 ft.
1 23 01000215 Hose Clamp
1 24 01006835 Tank, 25 Gallon, Polyethylene includes:
1 01007969 Tank Lid
1
Starting Date: 8/2007 –
Qty.
1
1
1
2
2
1
4
2
1
1
1
8
1
1
