Eloma EL2002917 Service Information

SERVICE-INFORMATION
Model: all devices
Subject: CPU board Typ C0
Jumpers on CPU board C0
Dear service team partner,
we would like to inform you about important information regarding CPU C0
jumper settings and part numbers for our devices.
Depending on the device type and display variant, the CPU C0 requires different
settings of the jumpers on the board.
There are altogether three different article numbers for the CPU board C0. These
part numbers correspond to the different display variants that are configured by
solder jumpers on the board. Please always use the correct part number according
to the device configuration when ordering spare parts or for repair requests.
article number
CPU Board C0
display
jumper
delivery status
SP
soldering joint
1/2/3
J3 without jumper
J4 without jumper
J5 without jumper
J6 with jumper
JTERM with jumper
Eloma GmbH | Otto-Hahn-Straße 10 | 82216 Maisach/Germany
Tel: +49 (0) 8141 395-0 | Fax: +49 (0) 8141 395-130 | info@eloma.com | www.eloma.com
figure 1: CPU board C0
EL2002917 EL2006524
5" 5" 7"
MM EB30 Joker
2A
3A
1-2
1-2 1-2 1-2
2023-011
EL2009772
7" 9"
GMT GMT
2A
3A
1-2
1-2
1-2
1-2 1-2
Date: 08.09.2023
Comment
Check position
of the solder
joint
for display 9"
for display 9"
For display 7"
Battery
activation
Not connected
