Summary of Contents for Modulus PVTHERM
- Page 1 Contact Us www.moduluslogistics.com info@moduluslogsitics.com...
-
Page 3: Table Of Contents
PVTHERM: User Manual CONTENTS Introduction ............................5 1.1. Product Advantages and Benefits ........................5 Safety Instructions & Warnings ....................... 6 2.2. Transport and Storage ..............................7 2.3. Disclaimer .................................... 8 Installation Instructions ........................8 3.1. Installation Areas to Avoid ............................9 3.2. - Page 4 PVTHERM: User Manual Table 1: PV Size Calculation ................................11 Table 2: Specifications..................................15 Table 3: Error Descriptions................................17 Table 4: Terms and Definitions ..............................17 Table 5: Installation Checklist ................................. 18 Page 4...
-
Page 5: Introduction
PV is comparable to heating with traditional collectors, either flat plat or evacuated tubes. PVTHERM™, a product of Modulus Logistics, is a PV controller that converts the electrical power generated with photovoltaic panels and applies this power directly to the existing geyser element. -
Page 6: Safety Instructions & Warnings
PVTHERM: User Manual • Grid can be used for backup if required. • Even if the water pipes between a thermal collector and geyser are lagged, the thermal losses are still huge. The losses in the electrical cables (voltage drop) are minimal and therefore the panels can be far from the geyser, or even at a different floor level. -
Page 7: Transport And Storage
PVTHERM: User Manual • The product is a combination of a high voltage DC source and mains/grid AC source. Even if the equipment is switched off, a dangerous electrical voltage can occur at the input and/or output terminals of the inverter due to charged capacitors. -
Page 8: Disclaimer
PVTHERM: User Manual 2.3. Disclaimer This product is transported, used, and operated under environmental and electrical conditions. The Supplier (The Company who has supplied the customer with the Solar Water Inverter) has the right not providing after-sales services or assistance under following conditions: •... -
Page 9: Installation Areas To Avoid
PVTHERM: User Manual uninterruptable grounding for safety purposes. An additional earthing/grounding connection point is located on the terminals area of the product. • If the grounding protection is damaged, the product should be taken out of operation and prevented from accidentally being put into operation again and contact qualified maintenance personnel. -
Page 10: System Connections
PVTHERM: User Manual such as a kitchen. It will deteriorate plastic parts, causing the parts to fail or the unit to leak water. • Area that generates substances that adversely affect the equipment, such as sulphuric gas, chlorine gas, acid, or alkali. It will cause the copper pipes and brazed joints to corrode, which can cause refrigerant leakage. -
Page 11: Installing The Unit
PVTHERM: User Manual Geyser Size Optimal Panel Size Element PV String Voltage (Vmp) 150L 4 x 330Wp in series 120V to 200V 200L 4 x 330Wp in series 100V to 200V Table 1: PV Size Calculation 3.4. Installing the Unit Firstly, install the mounting plate with suitable fixing bolts. - Page 12 PVTHERM: User Manual Unit iii. Mains Load Switching OFF procedure/order: Load Mains iii. Unit Once all above connections are made, turn on the system as follows: • The ON/OFF SWITCH is currently in OFF position. • Turn ON system as described above.
-
Page 13: Single Line Diagram For Installation
PVTHERM: User Manual CAUTION NEVER turn off PV when Mains is present. NEVER parallel AC sources at the unit AC input or geyser element. 3.6. Single Line Diagram for Installation Figure 3: Line Diagram for Installation 04. Operational Functionality The system reports on solar data but does indicate mains/grid mode when solar is not available. -
Page 14: System Protection
• Separate earth connection onto unit • Anti-Islanding 05. Maintenance • PVTHERM™ does not require specific maintenance. • It will suffice to check all connections once a year. • Avoid moisture and oil/soot/vapours and keep the device clean. • PV modules should self-clean if the angle of installation is more than 10 degrees to the horizontal. -
Page 15: System Specifications
PVTHERM: User Manual 06. System Specifications 6.1. Technical Specifications MPPT Efficiency >99% Overall Efficiency >95% Operating Temperature -10C to 60C Topology Transformerless Cooling Method Natural convection via heatsinks Working hours Solar mode default, grid/mains mode as backup Mains/Solar interchange Automatically... -
Page 16: Error Indications And Troubleshooting
PVTHERM: User Manual 07. Error Indications and Troubleshooting Important note: Do not attempt to open the unit as this could be dangerous and void the warrantee. 7.1. General Error Indications and Troubleshooting With the procedures below, most errors can be quickly identified. If an error cannot be resolved, please refer to your system supplier. -
Page 17: Terminology
Alternating current Direct current MPPT Maximum power point tracker Product Refers to the PVTHERM™ Solar Water Heater Inverter including all subcomponents Photovoltaic Subcomponent All components that make up the product, including but not limited to all switches; screws and wiring... -
Page 18: Installation Checklist
PVTHERM: User Manual 09. Installation Checklist Please complete the below checklist before switching on the unit and before leaving the premises after installation: Action Completed Confirm all connections as per Section 3.2i.e.: PV on left; Loads in middle; Grid on right Confirm Open Circuit Voltage from the PV, not higher than 300V. -
Page 19: 010. Warranty
PVTHERM: User Manual 010. Warranty Please register your product at https://www.moduluslogistics.com/warranty/ or by scanning the QR code below. Figure 4: Warranty QR Code Page 19...
