Summary of Contents for ARCTIC HAYES AH61
- Page 1 ARCTIC HAYES GAS LEAK DETECTOR User Manual AH61 Before using the instrument, please read this manual carefully, and save for future reference.
- Page 2 Safety Instructions In order to use the gas leak detector correctly, please read the instructions carefully before use, noting any safety information. It is recommended that you keep this instruction manual safe for future reference. • Before using the gas leak detector inspect the plastic casing.
-
Page 3: Maintenance Information
Safety Instructions Maintenance Information. The unit may be cleaned using a dry soft cloth, do not use a wet or abrasive cloth, solvents or detergents. Warning. Turn the gas detector on in a clean air environment away from the test area. Failure to do so may cause the unit to indicate a false reading. - Page 4 Physical Appearance Function head with gas sensor Function keys LCD display Battery cover Height - 287mm Weight - 49.5g Width - 32mm (without batteries) Depth - 30mm...
-
Page 5: Sensitivity Selection
Measurement Operation Turn on: Press the power key and hold it for more than 1 second, then turn on the instrument with a beep. Turn off: Press the power key and hold it for more than 1 second, then the buzzer will beep for a long time to turn off. - Page 6 Measurement Operation • Move the sensor head closer to the detection point. • When the detector detects combustible gas, the number of simulation bars will increase with the increase of gas concentration. The beeping sound will also become faster as the gas concentration increases.
-
Page 7: Battery Replacement
Specification & Battery Replacement General technical specifications Sensor Gas sensitive bulk semi-conductor Reaction sensitivity 50ppm (methane) Warm up time Approx 30 seconds Reaction time 2 Seconds Operating conditions 0°C to 50°C / 20 to 80%RH Storage conditions -10°C to 60°C / 20 to 80%RH Battery life Approx 3 hours Power supply... -
Page 8: Limited Warranty
Do not dispose of the unit with the usual domestic refuse. Do not burn the product. Arctic Hayes Ltd Arctic Hayes Ltd 9 Millshaw Park Ave | Leeds Ipco B.V, Spinel 400 LS11 0LR | United Kingdom 3316 LG Dordrecht sales@arctic-hayes.com...
