Part Identification – HT-Air® Air Supply
Power
Cord
Strap
Hose Release Button
Control Panel Label
Power Cord
(US/UK/Euro)
WARNING: The HT-Air is not compatible with DC power supplies.
The HT-Air is not for use with the HoverJack Battery Cart.

Air200G/Air400G Air Supplies

If using HoverTech's Air200G or Air400G Air Supplies, press the grey
button on the top of the canister to initiate air flow. Press the button
again to stop air flow.
User Manual
Carrying Handle/
Attachment Hook
Hose
Nozzle
Hose
Air Filter
Cover
HMManual, Rev. M
HT-Air® Keypad Functions
Adjustable Speed
Indication
(Green Flashing LED)
Adjustable/
Pressure
Setting
Standby (Amber LED)
ADJUSTABLE: For use with HoverTech air-assisted positioning
devices. There are four different settings. Each press of the
button increases the air pressure and rate of inflation. The Green
Flashing LED will indicate the inflation speed by the number of
flashes (i.e. two flashes equals the second inflation speed).
All of the settings in the ADJUSTABLE range are substantially
lower than the HoverMatt and HoverJack settings. The
ADJUSTABLE function is not to be used for transferring.
The ADJUSTABLE setting is a safety feature that can be used
to ensure the patient is centered on HoverTech air-assisted
devices and to gradually accustom a patient who is timid or in
pain to both the noise and functionality of the inflated devices.
STANDBY: Used to stop inflation/air flow (Amber LED indicates
STANDBY mode).
HOVERMATT 28/34: For use with 28" & 34" HoverMatts and
HoverSlings.
HOVERMATT 39/50 & HOVERJACK: For use with 39" & 50"
HoverMatts and HoverSlings and 32" & 39" HoverJacks.
Power Indication
Green LEDs
Transfer
Speed
High
Transfer
Speed
Low
