Installation Manual for TBS readers:
NOTE:
The latest version of this document is always available at:
https://cloud1.tbs-biometrics.com/index.php/s/IcgqtcdZXJVBrzA
Revision
Oct 22, 2021
April 13, 2022
Aug 18, 2022
Nov 20, 2023
2D IRON and 3D AIR
Document TBS-056-057
Author
New content
AG/TO
First Release
AG/TO
Minor updates
AG
Name changes
AG
Port assignments for BME, device front closing, FM box dimensions
Advertisement
Table of Contents
Summary of Contents for tbs electronics 2D IRON
- Page 1 Installation Manual for TBS readers: 2D IRON and 3D AIR Document TBS-056-057 NOTE: The latest version of this document is always available at: https://cloud1.tbs-biometrics.com/index.php/s/IcgqtcdZXJVBrzA Revision Author New content Oct 22, 2021 AG/TO First Release April 13, 2022 AG/TO Minor updates...
-
Page 2: Table Of Contents
Tamper Switch ..........................16 Appendix ............................17 Maintenance............................17 Trouble Shooting ..........................17 TBS Port Assignments ........................19 References to other TBS documents ....................21 • • TBS 2D IRON 3D AIR Mounting and Installation Guideline TBS-056-057 Rev 11-2023 page 2 of 21... -
Page 3: Introduction
Introduction The TBS 2D IRON and 3D AIR terminals bring Access Control and Time & Attendance applications featuring biometrics to a new level. They combine highest security with user convenience and the most flexible configuration options on the market. This installation manual provides information and instruction for the 2D IRON and 3D AIR, which are available as flush mount or wall mount options. -
Page 4: Legal And Safety Instructions
TBS Installation Manual – 2D IRON & 3D AIR Legal and Safety Instructions Allowed Applications TBS products are not designed, authorized, or warranted to be suitable for use in medical, military, aircraft, space or life support equipment, nor in applications where failure or malfunction of a TBS product can reasonably be expected to result in personal injury, death or severe property or environmental damage. -
Page 5: Declarations Of Conformity
USA (FCC) regulatory notices The 2D IRON and 3D AIR comply with FCC 47 CFR Part 15B. Operation is subject to the following two conditions: (1) the device may not cause harmful interference, and (2) the device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Mounting And Installation
TBS Installation Manual – 2D IRON & 3D AIR Mounting and Installation Recommended Configuration The recommended configuration for installation is to connect the TBS terminal, mounted in the non- secure area, via Ethernet, RS232, RS485 or Wiegand interfaces to the gate control system, located in the secure area. -
Page 7: Accessing The Device
TBS Installation Manual – 2D IRON & 3D AIR Accessing The Device The terminals can be accessed by opening two screws on the bottom and removing the front panel. The process is the same for all three mounting variants (wall mount, heavy duty wall mount, flush mount) 4.2.1 Opening the Device... -
Page 8: Closing The Device
TBS Installation Manual – 2D IRON & 3D AIR 4.2.2 Closing the Device Plug In (1) Plug in the 2 bolts on front part into corresponding holes on back cover. Push front part towards back cover until it snaps in (you hear a... -
Page 9: Mounting Instructions
TBS Installation Manual – 2D IRON & 3D AIR Mounting Instructions 4.3.1 Preparation IMPORTANT: Make sure that all power sources for the device are turned off before installation. Before mounting the device, make sure of the following points to achieve an optimal installation: •... -
Page 10: Heavy Duty Box (Ip65)
TBS Installation Manual – 2D IRON & 3D AIR 4.3.3 Heavy Duty Box (IP65) The following equipment and tools are required for mounting the heavy duty variant. • Four ø4-5mm screws and fitting raw plugs suitable for the wall material (not included) •... -
Page 11: Flush Mount Box (Ip54)
TBS Installation Manual – 2D IRON & 3D AIR 4.3.4 Flush Mount Box (IP54) The following equipment and tools are required to install the flush mount variant: • Four ø3.5mm screws and fitting raw plugs suitable for the wall material (not included) •... -
Page 12: Power And Signal Wiring
TBS Installation Manual – 2D IRON & 3D AIR Power and Signal Wiring IMPORTANT: For all signal wiring, including ethernet cables, it is recommended to connect cables of less than 30m length to avoid surge current spikes that may damage the equipment. -
Page 13: Power Supply
NOTE: If several terminals are powered through the same PoE switch, make sure the switch can provide enough power to each device (minimum 11 W per 3D AIR and minimum 7 Watt per 2D IRON). Ethernet Connection For Ethernet connections, the wire terminal board provides a RJ45 LAN connector compliant with IEEE802.3at. -
Page 14: General Purpose Input / Output
TBS Installation Manual – 2D IRON & 3D AIR General Purpose Input / Output 5.4.1 General Purpose Inputs Two general purpose inputs are available on a detachable wire terminal block. These inputs can be used for interconnection with a door monitoring switch, request to exit button or other equipment. -
Page 15: Integrated Relay
TBS Installation Manual – 2D IRON & 3D AIR Integrated Relay Label on TBS Terminal Name Power Rating Normally Open Normally Closed Common 30 VDC, 1A 220 VDC, 0.14 A 120 VDC, 0.25 A 250 VAC, 0.12 A TBS recommends to not operate the relay at the upper level of the voltage range for long periods of time, and not to power devices constantly through the relay, as such may shorten its life span. -
Page 16: Tamper Switch
TBS Installation Manual – 2D IRON & 3D AIR Serial Interface RS485 Please connect from TBS device RS485 port directly to controller: Label on TBS Terminal Name Type Voltage Level Data - In/Out 0V-5V Bias (±7 V Offset) Data + In/Out 0V-5V Bias (±7 V Offset) -
Page 17: Appendix
Use soft towels for cleaning only, don’t use abrasive cleaning equipment. The optical sensor of 2D IRON is protected by a glass covering that withstands most chemicals. However, pay attention never to use aggressive chemical cleaning agents; these could attack plastic coatings around the sensor or the device itself. - Page 18 TBS Installation Manual – 2D IRON & 3D AIR Device blocked remotely using RemoteControl interface. Device not connected to server (either wrong configuration connection problems). Device not validated on server. Validate the device on BioManager. Device in non-operable state - DB reload Wait for DB reload process to complete.
-
Page 19: Tbs Port Assignments
TBS Installation Manual – 2D IRON & 3D AIR TBS Port Assignments The following tables list all TCP/UDP ports that are used in TBS software and firmware as part of the biometric subsystem infrastructure. Table 3: Port Assignments for BIOMANAGER ENTERPRISE installations (BME, Firmware 3.xx):... - Page 20 TBS Installation Manual – 2D IRON & 3D AIR Table 4: Port Assignments for WebEdition installations (WE, Firmware 2.xx): Machine Port Protocol Comment Inbound Outbound WE Server PC Device channel HTTP default communication channel (SOAP needs to be enabled in firewall settings,...
-
Page 21: References To Other Tbs Documents
TBS 2D IRON and 3D AIR Mounting and Installation Guideline Permanent link: https://cloud1.tbs-biometrics.com/index.php/s/rZ1LVs8tacOCoKA The QR code printed on the product opens this link, leading to the 2D IRON and 3D AIR product folder from where this manual is available. TBS Terminal Firmware Permanent link: https://biometrics.talentlms.com...
