ATTE ADD-RACK2U2 Instruction Manual

ADD-RACK2U2
RACK 2U mounting adapter with holes - shifted in depth
The ADD-RACK2U2 mounting adapter is a dedicated solution for mounting ATTE modules in a RACK
cabinet. ADD-RACK2U2 is a version set back by 68 mm from the front of the RACK cabinet.
The use of the adapter facilitates the assembly and convenient arrangement of the modules and
helps to organize the wiring. Together with the patch panel, which is the end of the structured
cabling for twisted-pair cable, and the cable organizer, which facilitates the routing of cables in the
cabinet, it allows to increase the aesthetics of the assembly and ensures a professional appearance of
the installation.
Enables the installation of ATTE modules in a RACK cabinet
•
Front mounting
•
4.8 mm system holes in 10.8 mm pitch, compatible with all modules from the offer
•
Possibility of mounting elements in any vertical or horizontal arrangement
•

Technical Specification

Housing Construction
Assembly
Ingress Protection Rating
Operating Temperature
Dimensions
Weight
ul. 3 Maja 5, 32-400 Myślenice, tel: +48 12 378 94 02, e-mail: support@atte.pl
INSTRUCTION MANUAL
General view of the device
Powder coated steel sheet RAL 9004
RACK 19", M6 screws (included)
IP20
-25 ... +60°C
482x 87 x 80 mm
0,45 kg
