- Page 1 ELISA PLATE SHAKER DIA4000 User Manual Version 09.23 DIAsource ImmunoAssays S.A. Rue du Bosquet, 2 - B - 1348 Louvain-la-Neuve – Belgium Phone : +32 10 84 99 11 : +32 10 84 99 90 www.diasource.be instrumentation@diasource.be...
-
Page 2: Table Of Contents
Content Content ................................2 1. General Information ............................3 1.1. Warranty Information: ..........................3 1.2. Technical Service:........................... 3 1.3. Disposal instruction: ..........................3 1.4. Contacts: ..............................4 2. General Safety Warnings ..........................5 2.1. Security ..............................5 2.2. General Symbols ..........................7 3. -
Page 3: General Information
DIAsource ImmunoAssays S.A. will at its discretion repair or replace parts, which may be found defective in the warranty period. The warranty does not include any responsibility for direct or indirect personal and/or material damages, caused by improper use or maintenance of the instrument. -
Page 4: Contacts
1.4. Contacts: DIAsource ImmunoAssays S.A. Rue du Bosquet 2 BE-1348 Louvain-La-Neuve BELGIUM Instrumentation Support Service Hotline phones availabilities : Monday to Friday; 08 :00 to 16:30 (Belgium time) Hotline phone number : 0032 (0)10 849976 Fax : 0032 (0)10 849990 Email : instrumentation@diasource.be... -
Page 5: General Safety Warnings
2. General Safety Warnings 2.1. Security Before using the instrument, user need have a complete understanding how to operate it safety. Before running the instrument, please read this manual carefully. Forbid anyone to operate the instrument before reading the manual. If operate not in accordance with the tips on the manual ,the heat generated by the instrument at runtime may cause severe burns, and electric shock accident. - Page 6 inserted into the socket, when pull out the plug, must hand-hold the plug as well and don't pull the power cord. The instrument should be put in lower humidity and less dust and away from water and avoid direct sunshine and strong light, indoor should be well ventilated, no corrosive gas or strong magnetic field interference, away from heat, stoves and other heat sources.
-
Page 7: General Symbols
2.2. General Symbols Symbol Description For internal and external grounding. Please ensure that the instrument is well grounded. Power-on Power-off Caution: To avoid injury, death, or damage to the instrument, the operator must comply with the instructions in the manual. CE mark Symbol for “Manufacturer”... -
Page 8: Introduction
3. Introduction 3.1. Use of the Instrument Elisa Plate Shaker (Ref. DIA4000) is a laboratory equipment controlled by brushless DC motor and PID intelligent temperature control technology. It is small volume, light weight, no pollution; temperature, shaking speed and time showed in a LCD display, beautiful and easy to operate. Mainly used for shaking and cultivation with elisa plates(96/384 wells),tissue culture plates(24/48/96 wells). -
Page 9: Specifications
3.2. Specifications Normal operation condition Ambient temperature：5C 30C Relative humidity：≤70% Power supply：AC220V Parameters and performance Parameters Temperature RT.+5 ℃ ~80 ℃ Time setting 1min ~ 99h59min Shaking speed range 200～1600rpm Accuracy of temperature ≤ ± 0.5 ℃ Display accuracy 0.1 ℃... -
Page 10: Instrument Description
4. Instrument Description This chapter introduces Elisa Plate Shaker mechanical structure and the central panel’s functions and some preparations before power-on. You should be familiar with this chapter before the shaker is first operated. 4.1. Structure description Hot lid Heating plate Keyboard Power switch Power connector... -
Page 11: Keyboard Description
4.2. Keyboard description Temperature Shaking speed Remaining time/status 3 7 .5 1 2 0 0 STOP 3 7 .5 1 6 0 0 0 1 :3 0 Set temperature Set shaking Knob Set time speed Note : Remaining running time/ status START : Instrument is running according to set parameters. -
Page 12: Operation Guide
5. Operation Guide 5.1. Temperature and time setting a) When the instrument powers on, display screen will show system loading. The instrument goes into the initial state with a sound System loading >>>>>>>>>>>> b) PV displays current temperature(25.0) and “Stop” means system is in parameter setting interface. 37.5 1600 01:29 37.5 1600 01:30 c) Press knob, turn left to select parameters that need to be adjusted. -
Page 13: Micro Plate Installation
5.3. Micro plate installation a) Open cover, let one side of microplate near shrapnel and compress it as per direction of arrow. b) Press down the other side of microplate as per direction of arrow. c) Press down micro plate and touch with heating plate. d) Fix another plate according to above steps. -
Page 14: Troubleshooting
6. Troubleshooting Phenomenon Possible Causes Processing Procedure Check the connection of No power Display window power doesn’t response after power-on switch damaged Change switch Temperature display serious incompatible with Sensor damaged Contact to supplier the actual temperature LCD displays: “Fault Status” sensor fault Contact to supplier “PT-Error!”...
