Yamaha PF-1000 Data List

Yamaha pf-1000: supplementary guide
Hide thumbs Also See for PF-1000:

Advertisement

Quick Links

Download this manual See also: Service Manual, Owner's Manual
Data List
Daten-Liste
Liste des données
Lista de datos
Voice List
Voice-Liste
Liste des voix
Lista de voces
Drum/key Assignment List
Liste der Tastenzuordnungen der Schlaginstrumente
Liste d'assignation instrument de batterie/touche du clavier
Lista de asignación de teclas/batería
Style List
Liste der Styles
Liste des styles
Lista de estilos
Effect Type List
Liste der Effekttypen
Liste des types d'effet
Lista de tipos de efecto
Effect Parameter List
Liste der Effektparameter
Liste des paramètres d'effets
2
Lista de parámetros de efectos
Effect Data Assign Table
Effektdaten-Zuordnungstabelle
Tableau d'fassignation des données d'effets
7
Tabla de asignación de datos para efectos
Harmony/Echo Type List
Liste der Harmony/Echo-Effekttypen
Liste des types d'fharmonie/d'écho
9
Lista de tipos de ecos/armonías
Parameter Chart
Parametertabelle
Tableau des paramètres
10
Gráfico de parámetros
MIDI Data Format
MIDI-Datenformat
Format des données MIDI
11
Formato de datos MIDI
Song System Exclusive Message List
Liste der System-Exclusive-Meldungen der Songs
Liste des messages exclusifs au système de morceaux
14
Lista de mensajes exclusivos del sistema de canciones
Song Meta Event List
Liste der Meta-Events der Songs
Liste des méta-événements des morceaux
14
Lista de meta-eventos de canciones
MIDI Implementation Chart
MIDI-Implementierungstabelle
Tableau d'implémentation MIDI
15
Gráfico de implementación MIDI
20
33
33
34

Advertisement

loading

Related Manuals for Yamaha PF-1000

Summary of Contents for Yamaha PF-1000

  • Page 1 Data List Daten-Liste Liste des données Lista de datos Voice List Voice-Liste Liste des voix Lista de voces Drum/key Assignment List Liste der Tastenzuordnungen der Schlaginstrumente Liste d’assignation instrument de batterie/touche du clavier Lista de asignación de teclas/batería Style List Liste der Styles Liste des styles Lista de estilos...

  • Page 2: Voice List / Voice-Liste / Liste Des Voix / Lista De Voces

    Voice List / Voice-Liste / Liste des voix / Lista de voces Category Voice Name Voice Type Bank Select PIANO & HARPSI. GrandPiano1 Natural! GrandPiano2 Natural! Piano&Str Natural! RockPiano Natural! Oct.Piano1 Natural! Harpsichrd8' Natural! Hc8'+4' Natural! Harpsi&Str Natural! Piano&EP Natural! Oct.Piano2 Natural! BrightPiano...
  • Page 3 Category Voice Name Voice Type Bank Select BASS Funk Bass Aco.Bass Fretless Bass&Cymbal Fusion Bass Rave Bass Dance Bass Synth Bass Snap Bass Click Bass BRASS Trumpet Sweet! Trombone Sweet! Muted Trump Flugel Horn SoftTrumpet BrassSection MellowBrass BigBandBrs Pop Brass Brass Combo SoloTrumpet Solo Tromb...
  • Page 4 Category Voice Type Bank Select PIANO Grand Piano GrndPianoKSP MellowGrPno PianoStrings Dream Bright Piano BritePnoKSP ElecGrandPno ElecGrPnoKSP Detuned CP80 Layered CP 1 Layered CP 2 Honkytonk HonkytonkKSP El.Piano 1 El.Piano1KSP Mellow EP 1 Chorus EP 1 HardEl.Piano VXfade El.P1 60sEl.Piano1 El.Piano 2 El.Piano2KSP Chorus EP 2...
  • Page 5 Category Voice Type Bank Select BASS ClickSynBass SynBass2Dark SmoothSyBass ModulrSyBass DX Bass X Wire Bass STRINGS Violin SlwAtkViolin Viola Cello Contrabass Trem.Strings SlwAtTremStr SuspenseStr PizzicatoStr Orch.Harp Yang Chin Timpani ENSEMBLE Strings 1 StereoStrngs SlwAtkStrngs Arco Strings 60's Strings Orchestra Orchestra 2 TremOrchstra Velo.Strings Strings 2...
  • Page 6 Category Voice Type Bank Select SYNTH PAD Glass Pad Metallic Pad Tine Pad Pan Pad Halo Pad Sweep Pad Shwimmer Converge Polar Pad Celestial SYNTH EFFECTS Rain Clavi Pad Harmo Rain African Wind Carib Sound Track Prologue Ancestral Crystal SynthDr.Comp Popcorn Tiny Bells RoundGlocken...
  • Page 7 Drum/key Assignment List Liste der Tastenzuordnungen der Schlaginstrumente Liste d’assignation instrument de batterie/touche du clavier Lista de asignación de teclas/batería Bank Select MSB (0-127) Bank Select LSB (0-127) Program Change (0-127) MIDI Keyboard Alternate Standard Kit1 Note Group Note# Note C#-1 (C#0) Surdo Mute...
  • Page 8 Bank Select MSB (0-127) Bank Select LSB (0-127) Program Change (0-127) MIDI Keyboard Alternate Jazz Kit Brush Kit Note Group Note# Note C#-1 (C#0) (D0) D#-1 (D#0) (E0) (F0) F#-1 (F#0) (G0) G#-1 (G#0) (A0) A#-1 (A#0) (B0) Snare Jazz H Brush Slap 2 Open Rim Shot Light Kick Jazz...
  • Page 9 Style List / Liste der Styles / Liste des styles / Lista de estilos Category Style Name POP & ROCK HeartBeat 60'sGtrPop 60's8Beat 8Beat1 8Beat2 OffBeat 60'sRock1 60'sRock2 Rock+HalfTime RockShuffle RootRock 8BeatRock SynthRock PopShuffle1 PopShuffle2 GuitarPop 16BtUptempo KoolShuffle FunkyFusion JazzRock POP BALLADS 8BeatModern MovieBallad...
  • Page 10 Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto ■ Effect Type (for Natural Voices) Reverb Chorus ROOM CHORUS DELAY LCR DARK HALL 1 CELESTE DELAY LR MELLOW HALL 2 FLANGER ECHO NORMAL STAGE...

  • Page 11: Effect Parameter List / Liste Der Effektparameter Liste Des Paramètres D'effets / Lista De Parámetros De Efectos

    Effect Parameter List / Liste der Effektparameter Liste des paramètres d’effets / Lista de parámetros de efectos ● Parameters marked with a in the Control column can be controlled from an AC1 (assignable controller 1) etc. However, this is valid only for a Variation effect (when selected for Insertion). Effect Name HALL1, HALL2 ROOM1, ROOM2, ROOM3...
  • Page 12 KARAOKE1, 2, 3 Parameter Display Delay Time 0.1mS-400.0mS Feedback Level –63-+63 HPF Cutoff Thru-8.0kHz LPF Cutoff 1.0kHz-Thru Dry/Wet D63>W-D=W-D<W63 CHORUS1, 2, 3, 4 CELESTE1, 2, 3, 4 Parameter Display LFO Frequency 0.00Hz-39.7Hz LFO Depth 0-127 Feedback Level –63-+63 Delay Offset 0.0mS-50mS EQ Low Frequency 32Hz-2.0kHz...
  • Page 13 DISTORTION OVERDRIVE Parameter Display Drive 0-127 EQ Low Frequency 32Hz-2.0kHz EQ Low Gain –12-+12dB LPF Cutoff 1.0kHz-Thru Output Level 0-127 EQ Mid Frequency 100Hz-10.0kHz EQ Mid Gain –12-+12dB EQ Mid Width 1.0-12.0 Dry/Wet D63>W-D=W-D<W63 Edge (Clip Curve) 0-127 AMP SIMULATOR Parameter Display Drive...

  • Page 14: Effect Data Assign Table / Effektdaten-Zuordnungstabelle Tableau D'assignation Des Données D'effets/Tabla De Asignación De Datos Para Efectos

    Effect Data Assign Table / Effektdaten-Zuordnungstabelle Tableau d’assignation des données d’effets/ Tabla de asignación de datos para efectos Table#1 Table#4 LFO Frequency Reverb Time Data Value Data Value Data Value Data Value 0.00 1.35 2.69 8.41 0.04 1.39 2.78 8.75 0.08 1.43 2.86...
  • Page 15 Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros Settings are saved/called up for each type. Data Type The data is saved... Setup When you change settings in a display page and then exit from the page. Voice When you change settings in the Voice Set display and then save the data as Voice file.
  • Page 16 Parameter System Voice SetUp PedalPolarity Keyboard/Panel TouchSense TouchOffLevel TouchOnOff TransposeAssign Regist.Sequence/Freeze/VoiceSet RegistrationSequence RegistSequenceData RegistSequenceEnable Regist(+)Pedal Regist(-)Pedal SequenceEnd Freeze FreezeGroupSetting VoiceSet VoiceSetEnable Main VoiceSetEnable Layer VoiceSetEnable Left Harmony/Echo Type Volume Speed Assign ChordNoteOnly TouchLimit Utility Configuration Speaker DisplayVoiceNumber MetronomeVolume MetronomeSound TimeSignature ParameterLock TapCountPercussion TapCountVelocity...
  • Page 17 Parameter System Voice SetUp Pedal Punch In/Out Quantize Track Size Strength Delete Source1 Source2 Destination Channel Transpose SetUp Filter Main Filter Control Change Filter Accompaniment Filter Tempo Tempo ➞ Transpose MainWindow DigitalStudio>DigitalRecording>Style Creator Basic Section Pattern Length Tempo Beat Assembly Source Pattern Section Part...
  • Page 18 Parameter System Voice SetUp ➞ Mono/Poly Voice Effect ➞ Portament Time DigitalStudio>Mixing Console Left Pedal ➞ Left Pedal Type Controller-Pedal ➞ Left Pedal Settings Controller-Pedal ➞ Filter Brightness DigitalStudio>Mixing Console ➞ Filter Resonance DigitalStudio>Mixing Console EG Attack(Main,Layer) EG Attack(Left) EG Decay(Main,Layer) EG Decay(Left) EG Release(Main,Layer) EG Release(Left)
  • Page 19 Parameter System Voice SetUp Natural Voice Reverb Type Reverb Depth Acmp Part Song Part Main,Layer Left Acmp(Offset) Song(Offset) Chorus Type Chorus Return Level Natural Voice Chorus Type Chorus Depth Acmp Part Song Part Main,Layer Left Acmp(Offset) Song(Offset) DSP1 Type DSP1 Return Level Natural Voice DSP Type DSP Depth Style Part...

  • Page 20: Midi Data Format / Midi-Datenformat / Format Des Données Midi / Formato De Datos Midi

    MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI Many MIDI messages listed in the MIDI Data Format are expressed in decimal numbers, binary numbers and hexadecimal numbers. Hexadecimal numbers may include the letter “H” as a suffix. Also, “n” can freely be defined as any whole number. To enter data/values, refer to the table below.
  • Page 21 MIDI CHANNEL MESSAGE (1) MIDI Events Status byte 1st Data byte Status Data (HEX) Parameter Key Off (n:Channel Key no. Number) (0~127) Key On (n:Channel Key no. Number) (0~127) Control BnH (n:Channel (00H) Bank Select Change Number) (01H) Modulation (05H) Portamento Time (06H)
  • Page 22 MIDI Events Status byte 1st Data byte Status Data (HEX) Parameter Program CnH (n:Channel pp (00H...7FH) Voice Number Change Number) (0~127) Channel DnH (n:Channel vv (00H...7FH) Data After Touch Number) Polyphonic AnH (n:Channel kk (00H...7FH) Key no. After Touch Number) (0~127) Pitch Bend EnH (n:Channel...
  • Page 23 NRPN Data Entry Parameter 00H 00H mmH Pitch Bend Sensitivity mm: 00H-18H (0...+24[semitones]) 00H 01H mmH Fine Tune mm ll : 00H 00H mm ll : 40H 00H mm ll : 7FH 7FH 00H 02H mmH Coarse Tune mm: 28H-40H-58H (- 24...0...+24[semitones]) 7FH 7FH Null...
  • Page 24 MIDI PARAMETER CHANGE TABLE * Not Received when Receive System Exclusive Message Parameters is set to off. * Not transmitted when Transmit System Exclusive Message Parmeters is set to on. MIDI Parameter Change table (XG SYSTEM) Address Size Data Parameter Description (H) (H) 00-0F MASTER TUNE...
  • Page 25 Address Size Data Parameter Description (H) (H) 00-7F CHORUS TYPE MSB Refer to Effect Parameter List 00-7F CHORUS TYPE LSB 00-7F CHORUS PARAMETER 1 00-7F CHORUS PARAMETER 2 00-7F CHORUS PARAMETER 3 00-7F CHORUS PARAMETER 4 00-7F CHORUS PARAMETER 5 00-7F CHORUS PARAMETER 6 00-7F CHORUS PARAMETER 7 00-7F CHORUS PARAMETER 8...
  • Page 26 Address Size Data Parameter Description (H) (H) 01-7F VARIATION PAN L63...C...R63 00-7F SEND VARIATION TO -∞dB...0dB...+6dB REVERB (0...96...127) 00-7F SEND VARIATION TO -∞dB...0dB...+6dB CHORUS (0...96...127) 00-01 VARIATION CONNECTION INSERTION, SYSTEM 00-7F VARIATION PART Reception NUMBER Part1...16(0...15) Transmission Part1...16(0...15) AD(64) OFF(127) 00-7F MW VARIATION -64...0...+63 CONTROL DEPTH...

  • Page 27: Total Size

    Address Size Data Parameter Description (H) (H) 00-01 Rcv PITCH BEND OFF, ON 00-01 Rcv CH AFTER TOUCH OFF, ON (CAT) 00-01 Rcv PROGRAM CHANGE OFF, ON 00-01 Rcv CONTROL CHANGE OFF, ON 00-01 Rcv POLY AFTER TOUCH OFF, ON (PAT) 00-01 Rcv NOTE MESSAGE OFF, ON...
  • Page 28 Address Size Data Parameter Description (H) (H) NOT USED NOT USED 04-28 EQ BASS FREQUENCY 32...2.0k[Hz] 1C-3A EQ TREBLE FREQUENCY 500...16.0k[Hz] NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED TOTAL SIZE nn = PART NUMBER If there is a Drum Voice assigned to the part, the following parameters are ineffective.
  • Page 29 NOT USED TOTAL SIZE n: Drum Setup Number (0-1) rr: note number (0D-5B) In the following cases, the PF-1000 will initialize all Drum Setups. XG SYSTEM ON received GM SYSTEM ON received DRUM SETUP RESET received (only when in XG mode) [Note] When a part to which a Drum Setup is assigned receives a program change, the assigned Drum Setup will be initialized.

  • Page 30: System Exclusive Messages

    MIDI Event Data Format Section F0 43 7E 00 ss dd F7 Control 11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01111110 7E = Style 00000000 00 = 0sssssss ss = Switch No. INTRO A INTRO B INTRO C...
  • Page 31 F0 43 1n 4C hh mm ll dd ... F7 Parameter 11110000 F0 = Exclusive status Change 01000011 43 = YAMAHA ID 0001nnnn 1n = Device Number n=always 0 (when transmit), n=0-F (when recieve) 01001100 4C = Model ID 0hhhhhhh hh = Address High...
  • Page 32 System Exclusive Messages (Clavinova compliance) 11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01110011 73 = Clavinova ID 11110111 F7 = End of Exclusive MIDI Event Data Format Internal F0 43 73 01 02 F7 Clock 00000001 01 = Model ID (Clavinova common ID)
  • Page 33 FF 7F len 43 73 0C 00 [Data] Style Name FF 7F len 43 73 0D 00 [Data] Song OTS YAMAHA XF META Event FF 7F 07 43 7B 01 cr ct bn bt Chord Name FF 7F 05 43 7B 03 dd 08...
  • Page 34 YAMAHA [ Electronic Piano ] Model PF-1000 MIDI Implementation Chart (Natural sound source) Function... Basic Default Channel Changed Mode Default Messages Altered Note Number : True voice Velocity Note ON Note OFF After Key's Touch Ch's Pitch Bend Control 0,32...
  • Page 35 YAMAHA [ Electoronic Piano ] Model PF-1000 MIDI Implementation Chart (XG sound source) Function... Basic Default Channel Changed Mode Default Messages Altered Note Number : True voice Velocity Note ON Note OFF After Key's Touch Ch's Pitch Bend Control 0,32...
  • Page 36 M.D.G., Pro Audio & Digital Musical Instrument Division, Yamaha Corporation © 2002 Yamaha Corporation V944530 205MWAP1.3-01A0 Printed in Japan...
