INSTALLATION &
OPERATIONS MANUAL
AdvancedIQ
STAND ALONE
NITROGEN GENERATOR
AG-6500/11000 | AG-18500/22500
Products for use under U.S. Patents 8,720,591, 9,144,700 and 9,186,533

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AdvancedIQ AG-6500 and is the answer not in the manual?

Questions and answers

Summary of Contents for ECS Electronics AdvancedIQ AG-6500

  • Page 1 INSTALLATION & OPERATIONS MANUAL AdvancedIQ STAND ALONE NITROGEN GENERATOR AG-6500/11000 | AG-18500/22500 Products for use under U.S. Patents 8,720,591, 9,144,700 and 9,186,533...

  • Page 2: Table Of Contents

    Table of Contents 1. General ..……………………………………………………………………………………………………………….. a. Copyrights and Safety b. System and Product Information c. Technical Specifications d. Operational Information 2. Start Up and Operational Procedures ………………..……………………………………………….. a. Installation b. Commissioning and Start Up Procedure c. Normal Operation d. Fire Sprinkler System Maintenance Procedure 3.

  • Page 3: General

    General COPYRIGHTS and SAFETY Copyright © 2023 Engineered Corrosion Solutions, LLC - All Rights Reserved Reproduction or use, without express written permission from Engineered Corrosion Solutions, of any portion of this manual is prohibited. While all reasonable efforts have been taken in the preparation of this manual to assure its accuracy, Engineered Corrosion Solutions, LLC, assumes no liability resulting from any errors or omissions in this manual, or from the use of the information contained herein.
  • Page 4 Cautions and Warnings CAUTION: Do not install the Nitrogen Generator or Air Compressor Package in an area where ammonia, sulfur dioxide, hydrogen sulfide, mercaptans, chlorides, chlorine, oxides of nitrogen, acid fumes, solvent vent vapors, and ozone vapors or similar contaminates exist. The equipment can be damaged by ammonia and other vapors shortening membrane life.

  • Page 5: System And Product Information

    SYSTEM and PRODUCT INFORMATION Dry Pipe Nitrogen Inerting (DPNI) Dry Pipe Nitrogen Inerting technology was developed by Engineered Corrosion Solutions, LLC, (ECS) and is used to control oxygen corrosion in dry pipe and/or preaction fire sprinkler systems. DPNI is executed by employing a “fill and purge”...
  • Page 6 Oxygen Removal Vent To completely remove the oxygen in a dry pipe and preaction fire sprinkler system, it is necessary to install a vent on the main riser of each fire sprinkler system. Vents allow for a system to breathe, which requires a 3-5 psig (.2-.3 bar) pressure range to facilitate removal of oxygen gas from the system.
  • Page 7 Recommended Monitoring Equipment In-Line Corrosion Detectors The In-Line Corrosion Detector (ILD) is designed to provide an early warning of corrosion activity within the fire sprinkler system. The ILD features a double wall construction that incorporates a thin milled section of pipe (.035” (8.9mm)) surrounded by a full-thickness piece of pipe to detect and alert to the presence of corrosion activity.
  • Page 8 AdvancedIQ Vent Controller (AVC) The AdvancedIQ Vent Controller (AVC) provides automatic oxygen venting, monitoring of nitrogen/oxygen concentration levels and monitoring of the sprinkler system pressure within each dry pipe/preaction fire sprinkler system. As a fire sprinkler system is filled with a continuous supply of nitrogen gas from the nitrogen generator system, the vent, installed on the sprinkler system riser, allow oxygen-rich gas to be vented from the fire sprinkler system.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS Nitrogen Generators Dimensions – AG-6500/11000 24.5"(622mm) W x 52.5"(1,334mm) H x 8.5"(216mm) D Dimensions – AG-18500/22500 24.5"(622mm) W x 76"(1,930mm) H x 12.5"(318mm) D Dimensions with Bypass Assembly - AG-6500/11000 32.5"(826mm) W x 52.5"(1,334mm) H x 8.5"(216mm) D Dimensions with Bypass Assembly - AG-18500/22500 32"(813mm) W x 76"(1,930mm) H x 12.5"(318mm) D Weight - AG-6500/11000...
  • Page 10 Nitrogen Generator Approvals FM Approved - Standard 1035 UL Listed - 508A Industrial Control Panel UL-508A Listed to Canadian Standards CE Certification Air Compressors COMP-5-2 Dimensions (Duplex/Horizontal) 84.2"(2,140mm) (L) x 34.6"(878mm) (W) x 48.2"(1,224mm) (H) COMP-7.5 Dimensions (Simplex/Vertical) 23.6"(1,097mm) (L) x 38.1"(968mm) (W) x 70.1"(1,781mm) (H) COMP-7.5-2 Dimensions (Duplex/Horizontal) 84.2"(2,140mm) (L) x 34.6"(878mm) (W) x 48.2"(1,224mm) (H) COMP-10 Dimensions (Simplex/Vertical)
  • Page 11 Nitrogen Generator Dimensions AG-6500 and AG-11000 32” (813mm) Nitrogen Generator Dimensions AG-18500 and AG-22500 24.5” 12.5” (622mm) (318mm) 32” (813mm) 24.5” 12.5” (622mm) (318mm) 52.5” (1,334mm) 76” (1,930mm)
  • Page 12 Air Compressor Dimensions 38.1” 23.6” (968mm) (599mm) 70.1” 70.1” (1,781mm) (1,781mm) COMP-7.5 Simplex Air Compressor 34.6” 34.6” 84.2” 84.2” (878mm) (878mm) (2,140mm) (2,140mm) 48.2” 48.2” (1,224mm) (1,224mm) COMP-5-2 Duplex Air Compressor COMP-7.5-2 Duplex Air Compressor 30” 43.2” (762mm) (1,097mm 35.8” 87.5”...

  • Page 13: Operational Information

    OPERATIONAL INFORMATION System Operating Pressures When multiple dry pipe and preaction fire sprinkler systems are connected to one nitrogen generator, the fire sprinkler systems must operate at the same supervisory gas pressure. In applications where multiple dry pipe and preaction fire sprinkler systems are connected to one (1) nitrogen generator and there is more than one (1) supervisory gas pressure an ECS Nitrogen Interface Controller (NIC-1) must be included in the project.
  • Page 14 To ensure proper operation of the sprinkler system and the nitrogen generator, calibrate the sprinkler system operating pressure to the turn-on and turn-off pressure of the nitrogen generator using the Air Maintenance Device Pressure Adjustment Procedure (section 6.f.) in the Maintenance Section of this manual.
  • Page 15 Sprinkler Leak Rate to ECS Nitrogen Generator Run Cycle Comparison Generator Cycle Time Cycles Cycles Generator Cycle Time Cycles Cycles Leak Rate Leak Rate Time between cycles Time between cycles psig (bar)/24 Hr psig (bar)/24 Hr Week Week 1.5 (.10) * <...

  • Page 16: Start Up And Operational Procedures

    Start Up and Operational Procedures INSTALLATION Installation Instructions Installation of the ECS AdvancedIQ Nitrogen Generator and air compressor requires ten (10) steps: 1. Mount the nitrogen generator cabinet in the appropriate location. 2. Mount the air compressor in the appropriate location. 3.
  • Page 17 The cabinet includes pre-punched holes in the feet for floor mounting and holes in the back panel for wall support using standard anchors. NOTES: 1. The AG-6500/11000 cabinet does not include holes in the back panel for wall support. 2. The AG-18500/22500 cabinet includes holes in the back panel for wall support. 3.
  • Page 18 Step 4: Connect the Air Compressor Power Supply The air compressor requires a dedicated power supply to prevent interaction with other equipment. Provide a means of power disconnect adjacent to the air compressor in accordance with manufacturer’s published instructions and in accordance with the applicable national and/or local codes (i.e., NFPA 70). The incoming power supply line is connected to the terminal block inside the NEMA 4 power supply box on the air compressor.
  • Page 19 Step 6b: Plumb the Nitrogen/Air Supply Line – With Separate Air Compressor (Figure 3b) A separate air compressor can be used to meet the NFPA 13 30-minute fill requirement or as a back up to the nitrogen generator. In this application, the nitrogen/air discharge plumbing from the Nitrogen Generator and the separate air compressor are connected to the dry pipe or preaction valve trim with isolation valves in each supply line using a minimum ½”...
  • Page 20 Approved Air Maintenance Device (AMD) Reliable - Model A Tyco - Model AMD-1 Victaulic - Series 757 Step 7: Plumb the Condensate Drain Line The Nitrogen Generator will occasionally discharge a small amount of condensate water from the coalescing filters inside the cabinet. It is recommended that the ¼” drain connection be plumbed to a floor drain or building exterior.
  • Page 21 Connect Terminal 14NO to C-Mon Terminal in Connect Terminal 13NO Nitrogen Generator to V+ Terminal in Nitrogen Generator Step 9: Connect Nitrogen Generator to the Internet (where applicable) The nitrogen generator cabinet has ethernet cable connection to connect the nitrogen generator to the internet through a local area network (LAN).
  • Page 22 Monitoring Relay Contact Rating 250 VAC/ 6 Amps Nitrogen Generator Power Monitoring Output Bypass Alarm Monitoring Output (Normally Energized) (Normally De-Energized) Common Trouble Output Nitrogen Generator Running Output (Normally De-Energized) (Energized When Running) Ethernet Connection Relay Contacts – De-Energized NC (12) COM (11) NO (14) Connect Terminal 13NO...

  • Page 23: Commissioning And Start Up Procedure

    COMMISSIONING and START UP PROCEDURE Only qualified personnel should commission the new equipment into service once it is installed. Once the nitrogen generator has been configured, there should be no reason to adjust them. Pre-Commissioning Information Prior to setting the cut-in (turn-on) and cut-out (turn-off) pressures of the nitrogen generator, identify the following sprinkler system pressures: 1.
  • Page 24 NOTE: The only time the nitrogen generator should need to be in the “air bypass” position is for the NFPA 13 30-minute system fill time requirement. 7. Turn the cabinet power switch ON (if not already on). The generator will prompt to complete the commissioning process through the HMI.

  • Page 25: Normal Operation

    3. AdvancedIQ Vents Press the Vent System button on the AdvancedIQ Vent Controller which initiates the fourteen (14) day nitrogen inerting process. At the completion of the fourteen (14) day nitrogen inerting process or when the nitrogen purity has obtained 98%, the AdvancedIQ Vent Controller will automatically cease the nitrogen inerting process.

  • Page 26: Sequence Of Operation

    Sequence of Operation Once in service, the nitrogen generator requires no additional intervention to function properly. Nitrogen generator settings should not be altered without consulting ECS and the unit should not be powered down or bypassed for any reason other than a service or maintenance procedure as detailed in the Maintenance Section.
  • Page 27 ECS Nitrogen Generator Pressure Cycling for Dry Pipe and Preaction Fire Sprinkler Systems OPERATING NOTES: The nitrogen generator produces nitrogen increasing the pressure in the nitrogen supply line which increases the pressure in the fire sprinkler system. When the pressure in the fire sprinkler system reaches the pressure setting of the AMD, the AMD closes (no longer needing supervisory gas).
  • Page 28 Supervisory Gas Mode Once the DPNI “fill and purge breathing” protocol is complete the nitrogen generator will automatically operate in the Supervisory Gas Mode. Whenever a fire sprinkler system needs supervisory gas the nitrogen generator and compressor will automatically operate. 1.
  • Page 29 System Power Loss In the event of a system power loss, all programmed information in the nitrogen generator is stored in the nitrogen generator and the nitrogen generator will automatically restart once system power is restored. 1. Where Standard Vents are installed, the system will automatically return to Nitrogen Inerting Mode or Supervisory Gas Mode, depending on which mode the nitrogen generator was in when the power loss occurred.

  • Page 30: Auxiliary Equipment

    Auxiliary Equipment OXYGEN REMOVAL VENT: STANDARD VENT PAV-D/DQ Specifications Stock Number: PAV-D/DQ Service Pressure: Up to 175 PSIG (12 Bar) System Connection: 1” NPT Male Temperature Range: 40°F to 120°F (4.5°C to 49°C) Dimensions: 13.5” (W) X 7.5” (H) X 4.25” (D) (343mm (W) X 191mm (H) X 108mm (D)) For use under U.S.
  • Page 31 NOTE: Inspection must include the condition of the in-line filter and checking for blockage in the Y-Strainer and the restricted venting orifice. Operating Instructions 1. Verify the vent assembly has been equipped with a restricted venting orifice downstream of the backpressure regulator.
  • Page 32 ECS Standard Vent Assembly Restricted Venting Orifice In-Line Filter Muffler Gas Sample Port Backpressure Regulator Float Valve Connection to Sprinkler System Y-Strainer Isolation Ball Valve with Ball Valve ½” Quick Connect ECS Vent Installation Schematic 1” Outlet Required ECS Vent Nitrogen Supply Fire Sprinkler Riser Dry Pipe/Preaction Sprinkler Valve...

  • Page 33: Oxygen Removal Vent: Smart Vent

    OXYGEN REMOVAL VENT: SMART VENT PSV-D/DE Specifications Stock Number: PSV-D (PSV-DE) Service Pressure: Up to 175 PSIG (12 Bar) System Connection: 1” NPT Male Temperature Range: 40°F to 120°F (4.5°C to 49°C) Dimensions: Vent Assembly: 13.5” (W) X 7.5” (H) X 4.25” (D) (343mm (W) X 191mm (H) X 108mm (D)) For use under U.S.
  • Page 34 3. The second component of the SMART Vent is the electric control box. The control box must be installed on a wall or vertical surface adjacent to the vent assembly installation location. 4. Provide conductors from 120 VAC, 60 Hz (200-240 VAC, 50 Hz) power supply to designated terminals in the electric control box in accordance with the applicable national and/or local codes (i.e., NFPA 70).
  • Page 35 10. If the sprinkler system actuates or another event introduces oxygen to the sprinkler system press the Vent button to restart the purging cycle. ECS SMART Vent Control Box 120 VAC, 60 Hz,1 Phase 200-240 VAC, 50 Hz, 1 Phase Solenoid Solenoid (120 VAC)
  • Page 36 ECS SMART Vent Assembly Solenoid Backpressure Restricted Venting Regulator In-Line Filter Orifice HOUSING Float Valve Muffler Gas Sampling Port Connection To Sprinkler System Y-Strainer with Ball Valve Isolation Ball Valve ½” Quick Connect In-Line Filter Assembly ECS SMART Vent Installation Schematic Filter Wiring Harness Filter Housing...

  • Page 37: Monitoring: In-Line Corrosion Detector Ild-X

    MONITORING: IN-LINE CORROSION DETECTOR (ILD-X) Specifications Stock Number: ILD-X Service Pressure: 175 psi Temp. Rating: -40°F to 120°F (-40°C to 49°C) Elec. Connection: dry contact Pipe Size: 1.25” - 6” Pipe Schedule: Sch. 10 or Sch. 40 Pipe Material: Black Steel or Galvanized ILD-__ __ ____ How to Order Size...
  • Page 38 1. Contact an ECS Engineer to determine a location within the sprinkler system where corrosion is likely to occur. In wet pipe systems locate on a high point at the air/water interface; in dry pipe and preaction systems locate on a horizontal portion of the mains in an area with trapped water. 2.
  • Page 39 ECS Detector Remote Test Station Terminal Strip Connections Detector Remote Test Station Operation Flowchart Press Red LED Push Button RED LED ILD ACTIVATED Press Amber LED Push Button due to Corrosion Push Button Illuminates CONTACT ECS AMBER LED Replace Batteries www.ecscorrosion.com Re-Test ILD ILD Operating Properly...

  • Page 40: Monitoring: Smart Gas Analyzer

    Monitoring: SMART Gas Analyzer (SGA-1) Specifications Stock Number: SGA-1 Sensor Type: Zirconium Dioxide Electrical Connection: 120-240VAC, 50-60 Hz/.5A 24VDC/2A Signal Output: 0-5VDC linear output 4-20mA linear output Output Display: or %N Resolution: 1dp (nn.n%) Accuracy: Sample Connection: 5/32” nylon tubing quick connect For use under U.S.
  • Page 41 Installation Instructions 1. Mount the SMART Gas Analyzer on a wall adjacent to the PAV-D/DQ Vent or the PSV-D/DE SMART Vent (not included). 2. Once mounted, connect the 5/32” tubing to the push-connect fitting on the top of the SGA-1. 3.
  • Page 42 6. When monitoring and a (N.O.) contact closure required, connect to the Over contacts on block J5 (J5-1 & J5-2). a. If a LOW Nitrogen (N )/HIGH Oxygen (O ) percentage alarm is desired, select the corresponding oxygen concentration level using dip 2, 3 or 4 of Switch 1 to energize the Over relay output.
  • Page 43 Operating Instructions 1. Once unit is verified to be wired correctly, power unit on. The status LED light will repeatedly flash green two times quickly for two (2) minutes. The sensor heater is warming up during this period. 2. After the two-minute warm-up period, the sensor and status LED light will flash green one time repeatedly indicating normal operation.
  • Page 44 LED Identification Chart Status LED Color Flash Code Condition ERROR: Low Oxygen Level (less than .3%) ERROR: Assymetry (greater than 5%) Green Normal Operation Green Heater Warming Up Green Averaging Calibration Value Green Set Calibration Value If Needed...

  • Page 45: Commissioning

    Commissioning COMMISSIONING PROCEDURE Safety Warning Only qualified personnel should commission the new equipment into service once it is installed. Prior to any system commissioning on the nitrogen generator, ensure that the nitrogen generator is isolated from all system risers. Failure to do so can result in system damage and/or personal injury. Commissioning Video A commissioning video to assist with the commissioning process of this equipment is available.
  • Page 46 e. Set the sprinkler system Low Air Alarm Pressure. i. Press the pressure display, which displays a keypad. ii. Enter the appropriate pressure, then press keypad Enter key. 6. Enter the installation location information into the HMI Screen (recommended but not required). a.
  • Page 47 Nitrogen Generator Pressure Adjustments The nitrogen generator cut-in (turn-on) and cut-out (turn-off) pressure settings are established and set as part of the commissioning process of the nitrogen generator and do not need to be readjusted unless the fire sprinkler system parameters change. Any adjustments to the nitrogen generator cut-in (turn-on) and cut-out (turn-off) pressure settings will affect the Standard Vent (PAV-D/DQ) or SMART Vent (PSV-D/DE) backpressure regulator settings, which will require readjusting the backpressure regulators to coincide with the changes to the nitrogen generator cut-in (turn-on) and cut-out (turn-off) pressure settings.
  • Page 48 9. The nitrogen purity was verified to be producing 98% nitrogen purity prior to equipment shipment from ECS. Should the purity not be 98%, contact ECS prior to making changes to the nitrogen purity. a. If the nitrogen purity is above 98%, decrease the nitrogen purity by turning the Nitrogen Flow Control Valve counterclockwise in ⅛...
  • Page 49 i. Pull the knob out from the regulator to adjust pressure setting. Turn the knob clockwise to raise the pressure, counterclockwise to lower the pressure. ii. Close the isolation ball valve and allow device to depressurize through the restricted venting orifice to pressure setting. Make adjustment to pressure setting using the knob, then open the isolation ball valve to pressurize device and close the isolation ball valve again to check pressure setting.
  • Page 50 NOTE: This process can only be performed when fire sprinkler system is at normal operating pressure. iv. Push knob back into regulator until it clicks into place. v. Once the nitrogen generator system has been commissioned, open the isolation ball valve on the vent assembly, turn the green power switch on the electric control box to the ON position and push the Vent button.
  • Page 51 2. Check the turn-off function. a. Verify or lower the sprinkler system pressure is below the sprinkler system operating pressure (Example: 18 psig (1.2 bar)). b. If nitrogen generator is not running, manually turn on nitrogen generator and allow sprinkler system to refill and generator shut off. c.

  • Page 52: Commissioning Checklist

    COMMISSIONING CHECKLIST Fire Sprinkler System - General Verify and document the quantity of fire sprinkler systems connected to the nitrogen generator: Qty. _________ Verify and document the capacity of each fire sprinkler systems connected to the nitrogen generator (gallons or sq. ft.): Sys.
  • Page 53 Air Compressor - New Verify and document the location of the air compressor: __________________________ Verify and document the manufacturer of the air compressor: __________________________ Verify and document the model number of the air compressor: __________________________ Verify and document the serial number of the air compressor: __________________________ Verify and document the air compressor on/off pressure settings: __________________________...
  • Page 54 If No, change the cut-in or turn-on pressure of the nitrogen generator to be 3-5 psig (.2-.3 bar) below operating pressure of the fire sprinkler systems’ air maintenance device(s) using the Nitrogen Generator Pressure Adjustment Procedure (section 6.g.) in the Maintenance Section. Verify and document that the cut-in or turn-on pressure of the nitrogen generator is above the low air alarm pressure of the fire sprinkler system(s): Verify and document the cut-in or turn-on pressure of the nitrogen generator: ______________________...
  • Page 55 Leak check all plumbing throughout the nitrogen generator, include the air supply from the air compressor and the nitrogen supply to the fire sprinkler systems, repair any leaks found. Verify and document that the no leaks exist in the nitrogen generator, air compressor supply line and fire sprinkler supply line: Verify and document bypass/nitrogen generation ball valve in the nitrogen generator is in the nitrogen generation position:...
  • Page 56 If No, explain: _________________________________________________________________________ Verify the control box timer is programmed properly: 1. Mode is set to E 2. Scale is set to 20, 30, 40, 50, 60 3. Range is set to 10h 4. Dial is set to 35 Turn on the control box.

  • Page 57: Maintenance

    Maintenance Safety Warning Only qualified personnel can perform inspection, testing and maintenance of the nitrogen generation equipment. Prior to any system maintenance on the nitrogen generation system, ensure that the nitrogen generator is isolated from the compressed air supply and all system risers. Ensure that the nitrogen generation system and the associated piping that is to be manipulated is completely depressurized prior to performing any maintenance.
  • Page 58 Home Screen The Home Screen displays nitrogen supply line pressure, nitrogen generator cut-in and cut-out pressures, nitrogen generator status, nitrogen generator running hours and cycles. The Home Screen also provides access to Screen and Screen. The Home Screen displays any alarm signals developed in the nitrogen generator across the top of the screen NOTE: When the nitrogen generator status screen has three (3) different status: 1.
  • Page 59 Operating Pressure Screen The Operating Pressure Screen provides access to configure nitrogen generator to display pressure in PSI or Bar. The screen allows for setting nitrogen generator cut-in (turn-on) and cut-out (turn-off) pressures, sprinkler system operating pressure, and low air alarm pressures. The Operating Pressure Screen continuously displays the nitrogen supply line pressure.
  • Page 60 Alarm Settings Screen The Alarm Settings Screen provides access to alarm settings on the nitrogen generator. Runtime Alarm (default 3.5 hours), Short-Cycle Alarm (default 10 cycles), Short-Cycle Alarm Time (default 1 hour). The alarm screen allows access to reset the short-cycle alarm signal, turn on/off the Filter Alerts function, turn on/off the Low Air Alarm.
  • Page 61 Information Screen The Information Screen displays the nitrogen generator’s model number, serial number, PLC and HMI software version numbers. The Information Screen provides access to include the ECS Contact Information, Site Location Information, Building Owner’s Contact Information, and Service Contractor Contact Information.
  • Page 62 Alarms Screen The Alarms Screen continuously logs and displays any alarms (low air, short cycling, extended run time and bypass mode) in the HMI. Log Operations Screen The Log Operations Screen continuously logs and displays any changes to the programmed information stored in the HMI.

  • Page 63: Nitrogen Generator Excess Air Adjustment Procedure

    Maintenance Screen The Maintenance Screen continuously tracks and records annual filter changes in the nitrogen generator. After replacing filters, press and hold “Record Filter Change” button for five (5) seconds which records the time and date of the filter change and resets the Filter Alert timer. The Maintenance Screen displays the anticipated remaining life of the filters in hours of use.

  • Page 64: Nitrogen Purity And Flow Rate Procedures

    NITROGEN PURITY AND FLOW RATE PROCEDURES Nitrogen Purity Level Check Procedure Nitrogen purity level in the fire sprinkler system can be checked by inserting the Handheld Gas Analyzer (PHGA-1) into the nitrogen sampling port in the nitrogen generator cabinet or the gas sampling port on the PAV-D/DQ and PSV-D/DE Vents.

  • Page 65: Nitrogen Generator Short Cycling Prevention Procedures

    CAUTION: CAL Err St may result from a sensor that has not reached thermal equilibrium. Nitrogen Production Flow Rate Check Procedure The production rate of the nitrogen generator can be verified using the production flow meter in the nitrogen generator cabinet (see section 6.j., for the Generator Configuration Diagrams). 1.

  • Page 66: Air Maintenance Device Pressure Adjustment Procedure

    NOTES: 1. Exacerbated by a small or short nitrogen supply line between the nitrogen generator and sprinkler system. 2. Nitrogen Generator Short Cycling Prevention Device (AG-18500 and AG-22500 only) regulator should be fully closed unless used. 3. Nitrogen Generator Short Cycling Prevention Device (AG-18500 and AG-22500 only) is typically not needed in most applications.
  • Page 67 3. Accuracy of pressure gauges typically used in the fire sprinkler industry can vary as much as 8-12 psi (.55-.83 bar) (See Operational Information (section 1.d.) for Sprinkler System Gauge Accuracy). Determine the operating pressure for all AMDs connected to a single nitrogen generator. The operating pressure must be the same for all AMDs.
  • Page 68 7. Compare the pressure indicated on the HMI LCD display at the transition (gradual increase to rapid increase) with the pressure indicated on the system air pressure gauges. NOTE: The pressure indicated on the HMI LCD display at the transition of gradual to rapid increase will be the pressure at which the AMD pressure regulation device is currently set.

  • Page 69: Nitrogen Generator Pressure Adjustment Procedure

    b. If subtracting 3 psig (.2 bar) from the target operating pressure results in a pressure that is within 3 psig (.2 bar) of the low air alarm, contact ECS for direction. 13. Program the cut-in (turn-on) pressure into the HMI LCD display in the nitrogen generator (See section 6.g., in the Maintenance Section for the Nitrogen Generator Pressure Adjustment Procedure).

  • Page 70: Filter Replacement

    FILTER REPLACEMENT The nitrogen generators contain three (3) separate cartridge filters and a water separator. It is recommended that each filter be replaced at a minimum as part of an annual preventative maintenance program. ECS offers a replacement filter kit for each model. When maintained properly the nitrogen separation membrane will have an expected service life of twenty (20) years.
  • Page 71 3. Remove filter housing of 5-Micron Coalescing Filter Housing by pulling down on blue housing lock and turning filter housing counterclockwise. 4. Remove black plastic filter plate underneath filter by turning counterclockwise. Remove old Coalescing Filter from the filter housing. 5.
  • Page 72 Filters with Autodrain Filters without Autodrain .01-Micron Coalescing Filter .01-Micron Coalescing Filter 1-Micron Coalescing Filter 1-Micron Coalescing Filter 5-Micron Coalescing Filter Water Separator Water Separator 5-Micron Coalescing Filter .01-Micron Coalescing Filter 1-Micron Coalescing Filter 7. Inspect Water Separator and clean as necessary. 8.

  • Page 73: Oxygen Removal Vent Maintenance

    Air Compressor Maintenance Air compressors connected to the nitrogen generator must be maintained in accordance with the manufacturer’s recommendations, which includes changing the oil filters on a regular basis. OXYGEN REMOVAL VENT MAINTENANCE ECS Oxygen Removal Vent - PAV-D/DQ & PSV-D/DE Maintenance Instructions 1.

  • Page 74: Generator Configuration Diagrams

    GENERATOR CONFIGURATION DIAGRAMS AG-6500 and AG-11000 Nitrogen Generator Configuration 120-240 VAC Power Connections System Monitoring Fuses On/Off Power Switch Signal Connections HMI LCD Display On Cabinet Door Power Supply Solenoid #2 Audible Alarm Nitrogen Sampling Port Ethernet Connection Flow Meter/Flow Meter Ball Valve Nitrogen Back Pressure Regulator and Gauge...
  • Page 75 AG-18500 and AG22500 Nitrogen Generator Configuration System Monitoring Signal Connections 120-240 VAC Power Connections HMI LCD Display On/Off Power Switch On Cabinet Door Audible Alarm Ethernet Connection Fuses Power Supply Flow Meter and Flow Meter Isolation Valve Nitrogen Back Pressure Bypass Alarm Sensor Regulator and Gauge Nitrogen Outlet Valve...

  • Page 76: Troubleshooting

    TROUBLESHOOTING Safety Warning Only qualified personnel can perform inspection, testing and maintenance of the nitrogen generation equipment. Prior to any system troubleshooting on the nitrogen generation system, ensure that the nitrogen generator is isolated from the compressed air supply and all system risers. Be aware of pressurized system components as some of the troubleshooting procedures require system components to be pressurized.

  • Page 77: Wiring Diagrams

    WIRING DIAGRAMS Rev. 8.0...
  • Page 78 Rev. 1.0...
  • Page 79 Rev. 1.0...
  • Page 80 Rev. 1.0...

  • Page 81: Inspection, Testing And Maintenance Report

    INSPECTION, TESTING AND MAINTENANCE REPORT Customer Date Address Inspector City Customer No. State Contract No. Inspection No. Only qualified personnel can perform inspection, testing and maintenance of the nitrogen generation equipment. Prior to any system maintenance on the nitrogen generation system, ensure that the nitrogen generator is isolated from the compressed air supply and all system risers.
  • Page 82 Nitrogen Generator – Quarterly Maintenance Hrs. Count: Verified Verify run time (hours) on nitrogen generator – Hour Meter Verify cycle count on nitrogen generator – Cycle Counter Verify nitrogen generator is turning on/off at low/high pressure Verify pressure gauges are in working order (replace as necessary) Verify all manual valves fully open and close (repair/replace as necessary) Verify all manual valves operate smooth-clean and un-corroded (repair/replace as necessary) Check coalescing filter gauge(s) (replace filters as necessary)

  • Page 83: Miscellaneous

    Miscellaneous ORDER FORM PART # REPLACEMENT CORROSION PRODUCTS QUANTITY AdvancedIQ – Wall Mount Nitrogen Generator System (AG-675/950/2000/3500) FKWM-FS Filter Maintenance Kit, Wall Mount - Annual AdvancedIQ – Stand Alone Nitrogen Generator System (AG-6500/11000/18500/22500) FKSA-FS Filter Maintenance Kit, Stand Alone - Annual Oxygen Removal Vents (PAV-D/DQ and PSV-D/DE) PV-DRF Oxygen Removal Vent Filter...

  • Page 84: System Summary

    SYSTEM SUMMARY Existing Air Compressor Cut-In Cut-Out Gen. 30-Min. Manufacturer Model Number Serial Number psig (bar) psig (bar) Backup Fill New Air Compressor Cut-In Cut-Out Manufacturer Model Number Serial Number psig (bar) psig (bar) Air Maintenance Device (AMD) Pressure Pressure Sprinkler System psig (bar) psig (bar)

  • Page 85: Warranty Information

    WARRANTY INFORMATION The essential purpose of any sale or contract for sale of any of the products marketed or distributed by Engineered Corrosion Solutions, LLC, including Engineered Corrosion Solutions (ECS) and other brands of products, is the furnishing of that product. It is expressly understood that in furnishing said product, ECS does not agree to insure the Purchaser against any losses the Purchaser may incur, even if resulting from the malfunction of said product.
