INSTRUCTIONS FOR USE, NÁVOD K POUŽITÍ
RS485 LAN CONVERTER
RS485 LAN PŘEVODNÍK
1
Installation, service and maintenance of the electrical equipment may be carried out by an
authorized person only.
Montáž, obsluhu a údržbu smí provádět jen osoba s odpovídající elektrotechnickou kvalifikací.
OEZ s.r.o., Šedivská 339, 561 51 Letohrad, Czech Republic
PAQ-RPC-LAN
ENGLISH
ČESKY
994292-Z00
Advertisement
Summary of Contents for OEZ PAQ-RPC-LAN
- Page 1 PAQ-RPC-LAN Installation, service and maintenance of the electrical equipment may be carried out by an authorized person only. Montáž, obsluhu a údržbu smí provádět jen osoba s odpovídající elektrotechnickou kvalifikací. 994292-Z00 OEZ s.r.o., Šedivská 339, 561 51 Letohrad, Czech Republic...
- Page 2 230VAC RS485 230VAC RS485 LAN / RS485 LAN / RS485 OEZ s.r.o., edivsk· 339, 561 51 Letohrad, ä OEZ s.r.o., edivsk· 339, 561 51 Letohrad, ä Czech Republic, www.oez.cz Czech Republic, www.oez.cz Ethernet...
-
Page 3: Connection Conditions
CONNECTION CONDITIONS PODMÍNKY PŘIPOJENÍ The following conditions must be met for the remote control to function properly: 1. The entered IP address of the LAN/RS485 converter must be visible from the remote PC. If the converter and the PC with the control software are located in the same network address segment, no additional special network settings are required. -
Page 4: Converter Setting
• On the OEZ website, under the menu "Ke stažení->Softwarová podpora->Analyzátory sítí" (Downloads- >Software Support->Network Analyzers; https://www.oez.cz/sluzby/analyzatory-siti), a simple software is available to easily find the IP address of the converter in the OEZ-PAQ-LAN-scanner.exe computer network. 1. Výchozí konfigurace převodníku Převodník LAN/RS485 je dodáván ve výchozím nastavení:... - Page 5 IP address from a range defined by the network administrator. • You can find out the assigned IP address using the software utility "OEZ-PAQ-LAN-scanner" or from the network administrator. You can also use external software tools such as IPscanner or Nmap. The MAC address identification for this converter is "00-80-A3 ...
- Page 6 • You can change the dynamically assigned IP address as requested by the network administrator in the "Network" menu. After saving the new settings using the "Apply Settings" menu, the converter will reboot with the new IP address. • Dynamicky přidělenou IP adresu změníte dle požadavku správce sítě v menu 'Network'. Po uložení nového nastavení...
- Page 7 4. Resolving connection problems The prerequisite for the correct function is the visibility-availability of the converter in the Ethernet network. The basic test is to use the 'ping' command, see the figure. If there is a time response, the connection is OK. 4.
- Page 8 Next, check the default configuration settings on the web interface. In the web browser, enter the IP address of the converter in the address line. In the login window that appears, leave both fields blank and confirm. Dále zkontrolujte výchozí nastavení konfigurace na webovém rozhraní. Ve webovém prohlížeči do řádku adresa zadejte IP adresu převodníku.
-
Page 9: Led Diagnostics
LED DIAGNOSTICS DIAGNOSTIKA LED The yellow LED is blinking The LED monitors the activity in the LAN network. Žlutá LED bliká LED dioda monitoruje aktivitu v LAN síti. The yellow LED is shining The converter is properly connected to the LAN network. Žlutá... - Page 10 Napájecí napětí AC 230 V Napájecí svorky L, N RS485 svorky A, B LAN konektor RJ-45 Příkon max. 1.5 VA Indikace napájení zelená LED Indikace stavu připojení do LAN sítě žlutá LED Chipset Lantronix Pracovní teplota -20 ÷ +55 °C Skladovací...
