INSTRUCTION MANUAL
Dough Dividers
Item
47582
Model
BE-IT-0015M
Warning!
Before you begin using your appliance, PLEASE READ
AND UNDERSTAND THIS DOCUMENT CAREFULLY
before installing, operating, maintaining, or servicing.
There are many important safety messages in this
manual and on your appliance. Always read all safety
messages.
Failure to do so can result in appliance failure, property
damage, serious injury or death. Appliance failure, injury
or property damage due to improper installation is not
covered by warranty.
DO NOT RETURN THIS PRODUCT TO THE STORE!
For questions or assistance with this product, call
TRENTO Toll free: 1-800-465-0234 or visit the support
section from our website, www.trentoequipment.com
Version: Revised - 03/20/2024
WARRANTY
PARTS AND LABOUR
1-800-465-0234
47583
48582
BE-IT-0030M
BE-IT-0015M-1P BE-IT-0030M-1P
Stop!
www.trentoequipment.com
E L E V A T I N G C U L I N A R Y E X C E L L E N C E
48583
trentoservice@trentoequipment.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BE-IT-0015M and is the answer not in the manual?

Questions and answers

Summary of Contents for Trenton BE-IT-0015M

  • Page 1 47583 48582 48583 Model BE-IT-0015M BE-IT-0030M BE-IT-0015M-1P BE-IT-0030M-1P Warning! Before you begin using your appliance, PLEASE READ AND UNDERSTAND THIS DOCUMENT CAREFULLY before installing, operating, maintaining, or servicing. There are many important safety messages in this manual and on your appliance. Always read all safety messages.

  • Page 2: Table Of Contents

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E TABLE OF CONTENTS Section Page General Information --------------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------------- 4 - 6 Technical Specifications ------------------------------------------------------------------------------- 7...

  • Page 3: General Information

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E GENERAL INFORMATION Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc.

  • Page 4: Safety And Warranty

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E GENERAL INFORMATION consignes de sécurité. Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces instructions pour une référence ultérieure.
  • Page 5 E L E V A T I N G C U L I N A R Y E X C E L L E N C E SAFETY AND WARRANTY Ensure the machine is off during cleaning, maintenance and lubrication. Return the safety guards to their original position after cleaning, maintenance or lubrication of the machine.
  • Page 6 E L E V A T I N G C U L I N A R Y E X C E L L E N C E SAFETY AND WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.

  • Page 7: Technical Specifications

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E TECHNICAL SPECIFICATIONS Item Number 47582 47583 48582 48583 Model BE-IT-0015M BE-IT-0030M BE-IT-15M-1P BE-IT-30M-1P Description Manual Electrical 220V / 60Hz / 3...

  • Page 8: Installation

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E INSTALLATION transport. If found, promptly inform the carrier. You are always advised to photograph the damage. Remove the fastening brackets as in the figure and, using a forklift (or a lifting device), remove the machine from the pallet.

  • Page 9: Operation

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E OPERATION DESCRIPTION OF THE COMMAND KEYPAD - MANUAL UNITS a. Stop button. b. Start button. WORKING CYCLE The phases follow for correct use of the rounding divider.

  • Page 10: Maintenance

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E OPERATION USEFUL ADVICE To obtain a good product, proceed as follows: • Do NOT put flour on the shaping plate. •...
  • Page 11 E L E V A T I N G C U L I N A R Y E X C E L L E N C E MAINTENANCE 3. Release the divider handle and lower the pressure handle. The knife exits. 4.

  • Page 12: Parts Breakdown

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Knife Support Group...
  • Page 13 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Head Plate Group...
  • Page 14 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Operate Knife Group...
  • Page 15 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Operate Ring Group...
  • Page 16 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Frame Group...
  • Page 17 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Casing Group...
  • Page 18 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Knife Safety Group...
  • Page 19 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Rounding Plate Group...
  • Page 20 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Sliding Trolley Group...
  • Page 21 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Motor Group...
  • Page 22 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P 60Hz Pulley Group...
  • Page 23 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Rounding Lever Group...
  • Page 24 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Electrical Group...
  • Page 25 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 48582 BE-IT-0015M-1P 15 Div. Knife Group Page 25 / 44...
  • Page 26 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47583 BE-IT-0030M 48583 BE-IT-0030M-1P 30 Div. Knife Group Page 26 / 44...
  • Page 27 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M Knife Support Group Item No.
  • Page 28 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M Head Plate Group Item No.
  • Page 29 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M Operate Ring Group Item No.
  • Page 30 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M Casing Group Item No. Description Position Item No.
  • Page 31 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M Sliding Trolley Group Item No.
  • Page 32 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M Rounding Lever Group Item No.
  • Page 33 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 47582 BE-IT-0015M 15 Div. Knife Group Item No. Description Position Item No.
  • Page 34 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Knife Support Group Item No.
  • Page 35 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Head Plate Group Item No.
  • Page 36 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Operate Ring Group Item No.
  • Page 37 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Casing Group Item No. Description Position Item No.
  • Page 38 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Sliding Trolley Group Item No.
  • Page 39 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Rounding Lever Group Item No.
  • Page 40 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 48582 BE-IT-0015M-1P 15 Div. Knife Group Item No. Description Position Item No.

  • Page 41: Electrical Schematics

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E ELECTRICAL SCHEMATICS ITEM MODEL 47582 BE-IT-0015M 47583 BE-IT-0030M Page 41 / 44...
  • Page 42 E L E V A T I N G C U L I N A R Y E X C E L L E N C E ELECTRICAL SCHEMATICS ITEM MODEL 48582 BE-IT-0015M-1P 48583 BE-IT-0030M-1P Page 42 / 44...

  • Page 43: Warranty Registration

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E WARRANTY REGISTRATION Thank you for purchasing an Trento product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below.
  • Page 44 E L E V A T I N G C U L I N A R Y E X C E L L E N C E TRENTO IS A SIGNATURE LINE OF PROFESSIONAL RESTAURANT EQUIPMENT FROM OMCAN OFFERING PREMIUM EUROPEAN BRANDS TO THE NORTH AMERICAN MARKET.
