Summary of Contents for W Audio W-4000
- Page 1 W-4000 & W-6000 [220-240V] POWER NOISE FILTERS FOR USE WITH AUDIO-VIDEO EQUIPMENT Instruction Manual Edition 10-20...
-
Page 2: Table Of Contents
Introduction Thank you for purchasing this WAudio power flter. The power filter is a perfect addition to your audio or home theatre system. The electricity we are supplied with at our homes or workplaces is not clean and there is almost always at least some noise. This dirty electricity can have a negative effect on performance of your audio-video system and even affect its life. -
Page 3: Safety Instructions
Safety Instructions IMPORTANT READ THIS SECTION CAREFULLY BEFORE PROCEEDING! WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT REMOVE CHASSIS (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The triangle containing a lightning symbol is intended to alert the user to the presence of uninsulated dangerous voltages within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 4: Important Safety Instructions
Important Safety Instructions... -
Page 5: Controls And Displays
Controls and Displays FLOOR MODELS /W-4000 model shown/ INCORRECT SHELF MODELS /W-6000 model shown/ INCORRECT 1. Power Switch (ON and OFF) 2. Power Indicator 3. Phase Indicator 4. Reset Button 5. Voltage Meter Display 6. Power Cable Input 7. Power Sockets - DIRECT Output (non-filtered) -
Page 6: Hooking Up The Filter
Hooking Up the Filter Power cable Power cable 1. Make sure the filter is turned off (the Power Switch is in the down OFF position and the Power Cable is removed). 2. Using power cables (only a power cable for the filter is supplied with this product) connect your audio-video equipment to the power sockets. -
Page 7: Operation
Operation Note! This unit requires a single-phase 3-conductor electrical outlet. Plug the Power Cable to the filter and into the electrical outlet. Turn on the filter (the Power Switch should be in the upper ON position). The Power Indicator should light up – if not then check the connection to the electrical outlet and whether it is powered. -
Page 8: Specifications
Press the RESET button to restore the power supply. Note! When you want to turn off the power filter we recommend to turn off your audio-video equipment firstly. Specifications W-6000 W-4000 Max Spike Volt 3000V Max Surge Current 1000A Max Clamping Volt... -
Page 9: Kit Content
We strongly advise to contact a professional installer or dealer in order to install WAudio products. We recommend using high quality WAudio power cables and other installation accessories. Kit Content: Power Filter Power Cable Instruction Manual Your product is marked with the symbol as showed on the left. For EU (European Union) member users: This product has been tested and found in compliance with requirements of the European Community...
