- Page 1 VAMOOSE ELECTRIC CYCLE LTD. 5323 82 AVENUE NW EDMONTON, ALBERTA T6B 2J6 HELLO@VAMOOSECYCLE.COM PH: +1 587.991.2133 USERS GUIDE K5266...
-
Page 2: Table Of Contents
Contents Preface..........................- 1 - 1. Appearance and Dimension..................- 2 - 1.1 Material and Color....................- 2 - 2. Function and Button Definition..................- 3 - 2.1 Function description....................- 3 - 2.2 Normal Display Area....................- 3 - 2.3 Button Definition....................- 3 - 3.Operation Cautions....................... -
Page 3: Preface
Preface Dear Users, To ensure better performance of your e-bike, please read through the K5266 LCD product introduction carefully before using. We will use the most concise words to inform you of all the details (including the hardware installation, setting and normal operation use of the display) when using our display. -
Page 4: Appearance And Dimension
1. Appearance and Dimension 1.1 Material and Color K5266 product shell adopts aluminum alloy material, display panel is equipped with 3.8mm hard glass. The material of the enclosure allows normal use in temperatures ranging from -20℃ to 60℃ and ensures good mechanical properties. Dimension (unit: mm) K5266 has a dedicated N5-U button. -
Page 5: Function And Button Definition
2. Function and Button Definition 2.1 Function description K5266 provides you with a variety of function modes, to meet your riding needs. Its functions are as follows: ◆Battery power indication ◆Speed indication ◆Distance indication (including TRIP distance and ODO distance) ◆Walk assist and headlight control ◆Error code indication ◆Various setting parameter... -
Page 6: Operation Cautions
button is named as DOWN; button is named as HEADLIGHT. 3.Operation Cautions Be careful during use, do not plug in and out the connector of display when electrified. Avoid collision. The film used by the display is waterproof film, please do not tear it off, so as not to affect the waterproof performance of the display. -
Page 7: Display Interface
If you do not use the E-bike for more than 10 minutes, the display will turn off automatically. 5.2 Display Interface Display interface After the display is turned on, it shows real time speed. The PAS level is displayed in the middle of the screen, single TRIP (unit: km) is displayed in the upper part, and ODO (unit: km) and power (unit: W) are displayed in the lower part (press MODE button to switch). -
Page 8: Walk Assist
Trip distance PAS level Power (watt) 5.3 Walk Assist Hold DOWN for 2 seconds to start walk assist mode. The e-bike will keep at an even speed output 6km/h. Release the button to exit walk assist mode. Walk assist indication The walk assist function can only be used when the user pushes the electric vehicle, please do not use it in the riding state. -
Page 9: Battery Indicator
5.5 Battery Indicator When the battery is fully charged, the power is 100%; when the battery is 0%, it indicates that the battery is seriously undervoltage and needs to be charged immediately. Battery indicator 5.6 Turn On Headlight The e-bike is with headlight function, shortly press HEADLIGHT button, the headlight will be switched on and off. -
Page 10: Error Code
USB charging indication 5.9 Error Code When the vehicle’s electronic control system fails, the display will automatically display an error code. For the definition of the detailed error code, see Appendix 1. Error code interface 6. User Settings In the startup state without speed, hold UP button for 2 seconds, the display will enter the setting state. -
Page 11: Backlight Brightness Setting
User setting interface 6.1 Backlight Brightness Setting The backlight brightness is adjustable from 1 to 3 , default is 3. The parameter can be changed by UP/DOWN button. Press MODE button to confirm and exit the brightness setting state. Backlight brightness setting interface 6.2 Display Unit (Metric/Imperial) Setting Users can press UP/DOWN to select display units. -
Page 12: Speed Limit Setting
Unit setting interface 6.3 Speed Limit Setting The default maximum riding speed is 25Km/h. Change this value to set the maximum riding speed of the e-bike. When the e-bike exceeds the set value, the controller will stop supplying power to the motor to protect the rider's safety. The maximum speed setting can be selected from 12Km/h to 40Km/h. -
Page 13: Wheel Size Setting
6.4 Wheel Size Setting Available values are: 16 inch, 18 inch, 20 inch, 22 inch, 24 inch, 26 inch, 700C, 28 inch. Use UP/DOWN button to select the wheel size corresponding to the e-bike to ensure the accuracy of the speed display and mileage display. The factory default wheel size value is 26inch. -
Page 14: Version Information
6.6 Version Information Press MODE button to enter the version interface, and press MODE to exit. Version information interface 6.7 Exit Setting When the setting item is selected, hold MODE button to save and exit the setting state, or if no operation is performed within one minute, the display will automatically exit the setting state. -
Page 15: Version
II. The following conditions are not covered by the warranty: 1. The casing is opened 2. Connector is broken 3. The display leaves the factory, the casing is scratched or the casing is damaged. 4. Scratch or break of the display lead wire 5. -
Page 16: Appendix 1: Error Code Definition
Appendix 1: Error Code Definition Error Code Definition Current Abnormal Throttle Abnormal Motor phase problem Motor Hall Signal Abnormal Brake Abnormal Communication Abnormal - 14 -... - Page 17 VAMOOSE ELECTRIC CYCLE LTD. 5323 82 AVENUE NW EDMONTON, ALBERTA T6B 2J6 HELLO@VAMOOSECYCLE.COM PH: +1 587.991.2133 - 15 -...
