Summary of Contents for HAKO 5305.70
- Page 1 Assembly Manual Fleet-Recorder (5305.70)
- Page 2 Citymaster 1600. undertaken by a Hako service centre or make sure that only original spare parts a workshop authorised by Hako. are used. Only original spare parts...
- Page 3 Fleet-Recorder Citymaster 600/1600 Fleet-Recorder Citymaster 600/1600 Parts list 1 Fleet-Recorder 2 I-Button-Reader 3 User key 4 Antenna 5 Buzzer 6 Holder 7 2x flanged button head bolts 8 1x O-ring 9 1x W77 cable loom 10 1x clamp Parts not displayed: Fuse insert Sticker Sealing tape...
- Page 4 Fleet-Recorder Citymaster 600/1600 Installing the Fleet-Recorder Citymaster 600/1600 Caution Prior to installation, place the vehicle on a level surface and hold it with the parking brake. Switch the engine off and pull out the ignition key. Make all the electrical connec- tions according to the circuit diagram of the respective machine variant.
- Page 5 Fleet-Recorder Citymaster 600/1600 1.2.3 Installing the I-Button-Reader 1. Disassemble the right-hand control panel (Fig. 3/1). 2. Drill a hole measuring 13 mm in diameter into the panel according to the sketch (Fig. 3/2). 3. Install the I-Button-Reader (Fig. 3/3). 4. Position the RFID lock sticker on the control panel (Fig.
- Page 6 Fleet-Recorder Citymaster 600/1600 1.2.4 Installing the Fleet-Recorder 1. Disassemble the roof of the Citymaster. 2. Attach the holder for the Fleet-Recorder to the frame of the cab using the flanged button head bolts (Fig. 4/1). 3. Attach the Fleet-Recorder (Fig. 4/2) to the holder using an O-ring (Fig.
- Page 7 Fleet-Recorder Citymaster 600/1600 - Insert the 16-pole plug A20/X3 of CM1600 the W77 cable loom (Fig. 4/9). 4. Attach the cable to the holder using cable ties (Fig. 4/9). 5. Run the W77 cable loom in the profile of the roof frame (Fig. 5/1), guide it to the front and fix it into position using cable ties (Fig.
- Page 8 Fleet-Recorder Citymaster 600/1600 Schematic diagram of the W77 cable loom (Citymaster 600/1600) A20/X1 A20/X2 B30/X1 A20/X3...
