Summary of Contents for Sygonix 1761732
- Page 1 Operating instructions RSL wireless mini remote control Item no. 1761732...
-
Page 2: Explanation Of Symbols
Latest operating instructions Download the latest operating instructions via the link www.conrad.com/downloads or scan the QR code shown. Follow the instructions on the website. Explanation of symbols An exclamation mark in a triangle indicates important ins- tructions in this operating manual that absolutely have to be observed. -
Page 3: Intended Use
Intended use With a wireless remote control an appropriate wireless remote-control switch of the RSL system (or a load attached to it) can be switched on or off wirelessly. The wireless remote control uses a Type CR2032 battery. It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. - Page 4 • Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity, moisture, flammable gases, vapours and solvents. • Do not place the product under any mechanical stress. • If it is no longer possible to operate the product safely, take it out of operation and protect it from any accidental use. Safe operation can no longer be guaranteed if the product: - is visibly damaged, - is no longer working properly,...
-
Page 5: Operating Elements
b) Batteries • Correct polarity must be observed while inserting the battery. • The battery should be removed from the device if it is not used for a long period of time to avoid damage through leaking. Leaking or damaged batteries might cause acid burns when in contact with skin, therefore use suitable protective gloves to handle corrupted batteries. -
Page 6: Operation
Then place a type CR2032 battery inside, observing the correct polarity. The plus pole of the button cells points from you outward. • Place the housing cover and press the two halves together carefully so that the retaining clips snap into place. Do not exert any force. •... - Page 7 b) Deletion of a previously saved receiver from the Mini Remote Control • Shift the radio receiver (e.g. a wireless incorporated switch, a ra- dio-controlled socket, etc.) to the programming mode. Please refer to the operating manual of the radio receiver (usually press the button on the wireless receiver for more than 3 seconds, until the LED be- gins to flash on the radio receiver).
- Page 8 • If the radio receivers have a dimming function, read carefully its operating instructions. Range • The wireless remote control has a range of up to 30 m. However, this range is the so-called “free-field range” (range with line of sight between the transmitter and re- ceiver and without interference).
-
Page 9: Care And Cleaning
Care and cleaning • Apart from the occasional battery change the product is mainte- nance-free for you. • Clean the product with a soft, clean, dry cloth. • Never use aggressive cleaning agents or chemical solutions since these might damage the surface of the casing or impair the oper- ation. - Page 10 Disposal a) Product This symbol must appear on any electrical and electronic equipment placed on the EU market. This symbol indica- tes that this device should not be disposed of as unsorted municipal waste at the end of its service life. Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose of it separately from unsorted municipal waste.
-
Page 11: Technical Data
b) (Rechargeable) batteries Remove batteries/rechargeable batteries, if any, and dispose of them separately from the product. According to the Battery Directive, end users are legally obliged to return all spent batteries/rechargeable bat- teries; they must not be disposed of in the normal household waste. Batteries/rechargeable batteries containing hazardous substances are labelled with this symbol to indicate that disposal in household waste is forbidden. - Page 12 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is pro- hibited. This publication represent the technical status at the time of printing. Copyright 2022 by Conrad Electronic SE.
