Summary of Contents for YitaHome SZGRD-V1
- Page 1 ASSEMBLY INSTRUCTIONS SZGRD-V1 PSPPPG-0001 PSPPPG-0002 DOG HAIR VACUUM & PET GROOMING KIT...
- Page 2 ASSEMBLY INSTRUCTIONS This machine is intended for household use only and NOT for commercial or industrial use. • Only use the machine indoors and keep the area you’re cleaning light well. • Keep fingers, hair and loose clothing away from moving parts and openings whilst using the machine.
- Page 3 ASSEMBLY INSTRUCTIONS Item no. Reference Image Description Qty. Clean water tank Cleaning stains Pet body cleaning Brush pet's toes Dust box Stretchable hose Electric trimmer...
- Page 4 ASSEMBLY INSTRUCTIONS Item no. Reference Image Description Qty. Limit combs 3mm/6mm 9mm/12mm Ｉ Comb base Grooming comb head Slicker comb head Crevice tool Round brush Charging cord...
- Page 5 ASSEMBLY INSTRUCTIONS clean water tank clean water tank disassembly handle on-off button complete machine handle dirty water tank disassembly handle dirty water tank switch lock dirty water tank brush head hose power line hanger handle hanger assembly handle brush head...
- Page 6 ASSEMBLY INSTRUCTIONS HOW TO USE THE PET TRIMMER ACCESSORIES 3mm/6mm 9mm/12mm Ｉ When using accessories, please pay attention to the edges to avoid scratching your hands.
- Page 7 ASSEMBLY INSTRUCTIONS How to use the electric trimmer (can be used alone) Attention 1.Press the first time on/ off switch, it works at high speed. Press twice, it works at the standard speed. Press three times, it stop. 2.Long press for 3s under working, the child lock will start working, It will not work when pressing switch, long press for 3s, it starts working again.
- Page 8 ASSEMBLY INSTRUCTIONS Adjustment of Electric Clippers 1.6mm 2.2mm 2.8mm Reduce hair retention length Slide up (don't press the yellow self-locking button). Increase hair retention length Slide down (press and hold the yellow self-locking button). 1.0mm Charge through accessory N. Customer prepared...
- Page 9 ASSEMBLY INSTRUCTIONS Ｉ Electric Trimmer Grooming Comb It can shave your pet's hair and suck it It can clean the floating hair on pets and the into the dust cup to prevent it from garbage in the hair, and at the same time it falling elsewhere.
- Page 10 ASSEMBLY INSTRUCTIONS HOW TO USE THE CLEANER Cleaning stains Pet body cleaning Brush pet's toes When using accessories, please pay attention to the edges to avoid scratching your hands.
- Page 11 ASSEMBLY INSTRUCTIONS Instructions for assembly and disassembly of clean/dirty water tank 1.Put one hand on the machine, and use the other hand to pull clean water tank disassembly handle upward vertically, and gently pull up the clean water tank. Pull up 2.Open the top cover of clean water tank and fill in clean water.
- Page 12 ASSEMBLY INSTRUCTIONS 3.Put the head of the clean water tank into the open support position of the machine, and then press vertically down. After hearing the “click”, the installation is finished. CLICK!
- Page 13 ASSEMBLY INSTRUCTIONS Starting up and cleaning Prepare /start the work Power on: plug the machine power line into the socket to make machine connect the power. Press the button and Press the button again to the machine is on. disconnect the power. Do not excessively tilt or dump the machine during use to avoid water leakage.
- Page 14 ASSEMBLY INSTRUCTIONS After adding water to the clean water tank, connect the power and press the on /off button, and then the machine enters the working state, and the front suction position of brush head has continuous suction. Press the trigger for water ejection from the nozzle. Release the trigger and stop spraying water.
-
Page 15: Basic Maintenance
ASSEMBLY INSTRUCTIONS BASIC MAINTENANCE Dirty water tank cleaning Attention: In order not to affect the performance of the machine, it is recommended that you clean the machine after each usage. 1.Remove the top cover of the dirty 2.If there is stubborn dirt on the water tank, take out the float and inner wall of the usd water tank, float frame, and empty the sewage... -
Page 16: Important Note
ASSEMBLY INSTRUCTIONS Accessories cleaning First press the release button with your thumb in the position shown in the figure, the other hand pulls accessory window and take it out. After removing, rinse it with clean water and install it back. Accessory window Press and release Dust box cleaning... -
Page 17: Troubleshooting
ASSEMBLY INSTRUCTIONS TROUBLESHOOTING Abonormal situation Possible causes Treatment method The machine does The plug is not fully RefIx the plug to make sure not operate inserted into the machine is on electrical socket Product suction • The used water tank •... -
Page 18: Technical Specification
ASSEMBLY INSTRUCTIONS TECHNICAL SPECIFICATION Product name Pet Grooming Vacuum Kit PSPPPG-0001 Mode number PSPPPG-0002 Rated voltage 120V Frequency 60Hz Rating power 400W Clean water tank capacity 1500mL Dirty water tank MAX line capacity 800mL Net Weight 5.8kg Product size 385*196*300mm DISPOSAL •... - Page 19 Pure & Easy CONTACT US: If you have any questions about the installation of YITAHOME products, just contact us at +� (���) ���-���� from Mon-Fri �:�� AM-�:�� PM PST / Sat. �:�� AM-��:�� PM PST or e-mail us at after-sale.cs@hotmail.com Alternative method to contact us (amazon.com orders only)
