- Page 1 User Manual EFIX PRECISION AGRICULTURE eSteer10 User Manual...
-
Page 2: Table Of Contents
4.5 Camera ........................... 26 4.6 Error Message Viewing ......................26 4.7 Minimum Speed Setting......................28 4.8 Scene Mode Switching ......................30 4.9 Data backup and restore ......................32 4.9.1 Data backup ........................ 32 4.9.2 Manual Data Restoration .................... 34 eSteer10 User Manual... -
Page 3: Instructions For Product Usage
Please strictly follow the instructions and refrain from making arbitrary changes to the software parameters. Any equipment hardware failures or damages caused by human error are not covered under the warranty. eSteer10 User Manual... -
Page 4: Product Introduction
2 Product Introduction 2.1 Introduction to Main Components Device name Pictures Receiver Display Steering wheel Rear view camera eSteer10 User Manual... -
Page 5: Software Interface
9. View Zoom In/Out: Allows for zooming in or out of the view. The camera function overlays the background with the live image from the camera. 10. Compass: Shows the orientation or direction of the vehicle. 11. Quick Line Guidance: Provides a fast and efficient way to create a guidance line for the vehicle. eSteer10 User Manual... - Page 6 C: Implement Settings, including ISOBUS VT, Plow Width and Row spacing D: Select Brightness Mode and Adjust Display Brightness E: Help, including Reversing heading, One-Key Assistance, Line Guidance, Row Spacing Calculation Guidance, Width Guidance, Parameter Viewing, and One-Key Log Upload eSteer10 User Manual...
- Page 7 1. Vehicle and Navigation Line Display 2. Settings Interface, where all functions and configurations are accessible 3. Manual/Automatic State Display and Switching eSteer10 User Manual...
-
Page 8: Product Usage
B: X/Y, where X represents the current satellite signal delay, and Y represents the current signal mode (NET for network base station mode, and a numerical value for radio base station mode indicating the currently used channel). C: Current positioning accuracy error. eSteer10 User Manual... -
Page 9: Receiver Settings
Click on the "Work Mode" button, located at the back, followed by the "[ ]" symbol. From the options that appear, select " Controller/Display Network." ② In the Differential Settings, click on "Add" to add the corresponding base station information. eSteer10 User Manual... - Page 10 [ ] icon to return to the main interface. If all three signal icons in the top-left corner of the main interface are gray and not zero, it indicates that the signal is normal and available. eSteer10 User Manual...
-
Page 11: Implement Settings
For detailed instructions on calculating and adjusting row transitions, refer to section 4.2 in the documentation. Please input the respective values for each parameter according to your specific implement and operational requirements. eSteer10 User Manual... -
Page 12: Line Guidance
"B" to set the B point. Ensure that the direction between the A and B points is consistent. After setting the B point, the navigation line will be automatically saved, and the generated navigation line will appear on the screen, indicating that the line setup is complete. eSteer10 User Manual... - Page 13 Please select the desired line type based on your specific requirements and operational needs. Step 3: Click on the "Create" button in the top-left corner to go back to the main interface and start the line guidance process. eSteer10 User Manual...
-
Page 14: Auto Steering
"Auto Mode," it indicates that the system is currently under automatic control. Clicking on this button allows you to switch between the two modes, toggling between manual and automatic control. Manual mode Auto mode eSteer10 User Manual... -
Page 15: Powering Off
3.7 Powering off There is system power switch attached with the display, press it to turn on/off the whole system. eSteer10 User Manual... -
Page 16: Common Functions
3. This action will reset the AB Line and move it to the current position of the vehicle. Note: It is important to align the vehicle's direction as closely as possible with the AB Line before performing the zeroing operation. Before RZ After RZ eSteer10 User Manual... -
Page 17: Row Spacing Calculation
10cm larger and you want the vehicle to shift left, click the "←" arrow 10 times and then click "OK." The quick adjustment method provides a convenient way to fine-tune the transition rows without the need for extensive manual adjustments. eSteer10 User Manual... - Page 18 Scene 2, the first row turns right. Selecting the wrong scene may result in incorrect transition row calculations. Following these steps and accurately inputting the transition row data will ensure the automatic calculation of transition rows and proper modification of the implement width and center offset values. eSteer10 User Manual...
-
Page 19: Help
Step 1: Click on "Line Guidance" in the "Help" menu to initiate AB Line guidance. Please note that the provided translations are based on the given descriptions and may require further context or adjustment to fit the overall context of your application. eSteer10 User Manual... - Page 20 Due to the issue of implement misalignment, the transition rows may not be accurate. Users can use the Transition Row Calculation Guidance feature to manually adjust the transition rows. Step 1: Click on "Transition Row Calculation Guidance" in the "Help" menu to initiate the guidance for transition row calculation. eSteer10 User Manual...
- Page 21 Step 3: Click on the "Transition Row Auto Calculation" function. First, select the corresponding scene that matches the actual situation. Then, based on the diagram, measure and input the distances of the two transition rows (in meters). eSteer10 User Manual...
- Page 22 Step 4: After inputting the distances, click on "Done" to complete the configuration of the implement center offset. The next set of transition rows that occur during the back and forth operation will validate whether the modification has been applied correctly. eSteer10 User Manual...
- Page 23 D. Width Guidance This feature is designed to guide users in adjusting the implement width after replacing the implement. Step 1: Click on "Width Guidance" in the "Help" menu to enter the "Implement Management" interface. eSteer10 User Manual...
- Page 24 Step 2: Click on the blank space next to "Implement Width" and "Row Spacing" to modify the implement width and row spacing. Step 3: After making the necessary modifications, click on "OK" to confirm the changes. eSteer10 User Manual...
-
Page 25: Parameters Adjustment
If there is excessive steering wheel oscillation and decreasing the proportional gain does not yield significant results, decrease this value. This is necessary when the steering frequency is high, leading to excessive steering wheel and wheel oscillation or erratic turns. eSteer10 User Manual... -
Page 26: Camera
② The number area represents the status bar. The "[ ]" symbol indicates an abnormal working state, while "[ ]" indicates a normal working state. ③ The number area displays the error cause or reason. eSteer10 User Manual... - Page 27 You can follow the suggested solutions to try to resolve the issue on your own. If your attempts are unsuccessful, you can send the error information to local technical support, which will help them in troubleshooting and resolving the problem. eSteer10 User Manual...
-
Page 28: Minimum Speed Setting
Click on "Other Settings." Enter the desired minimum speed and click on the "Set" button located next to it. Wait for the software to display the message "Minimum speed setting successful" to confirm that the setting has been successfully applied. eSteer10 User Manual... - Page 29 User Manual...
-
Page 30: Scene Mode Switching
The steps to switch the scene mode are as follows: Click on the "Settings" button in the main interface. Click on "Steering calibrations” eSteer10 User Manual... - Page 31 Once you have entered the parameter scene switch interface, you can click on the corresponding scene. After selecting a scene, click on "Apply" and wait for 3-5 seconds. When the software displays a message indicating successful application, it means that the scene has been switched successfully. eSteer10 User Manual...
-
Page 32: Data Backup And Restore
The software supports both automatic and manual data backup methods. Automatic Data Backup: The system automatically backs up the current configuration file every 3 hours and overwrites the previous backup. Manual Data Backup: Click on the "Settings" option on the main interface. eSteer10 User Manual... - Page 33 Once you are in the backup and restore settings, you will be able to view the current real-time information. To backup the current information, click on "Backup" and the software will display a prompt saying "Backup Successful". eSteer10 User Manual...
-
Page 34: Manual Data Restoration
Based on the names and dates associated with the backup files, choose the backup file you want to restore the settings from. Once selected, click on "Restore" and wait for the software to display a prompt saying "Restore Successful" to confirm the successful restoration. eSteer10 User Manual... - Page 35 EFIX Geomatcis Co., Ltd. 1st Floor, No. 258 Pingyang Rd., Minhang District, Shanghai, 201102, CHINA Email: sales@efix-geo.com | support@efix-geo.com Website: www.efix-geo.com eSteer10 User Manual...
