Summary of Contents for BED BATH & Beyond A0024-BLBL
- Page 1 USER S MANUAL RATTAN PATIO LOUNGER SET A0024-BLBL *Please allow 2 days for shrink wrap cushion A0024-BLDR back normal thickness after open.
-
Page 2: Before You Start
Contact Us! Need Help! Do NOT return this item. Contact our friendly customer service department for help first. Before You Start Please do not exceed the weight limitation of each items Do not stand on or use any part of this item as step ladder Read each step carefully before starting. - Page 3 Notice: 1. 50% Tighten before fixing all screws, Allen wrench is recommended instead of an electric drill. 2. Place the item on a flat ground to adjust and make sure it remains stable. 3. Tighten up all screws with tools gradually. 4.
- Page 4 Seat frame (1 pc) Right frame (1 pc) Back frame (1 pc) Inner frame (2 pcs) Front frame (1 pc) Side frame (8 pcs) Seat frame (1 pc) Left frame (1 pc) Back frame (1 pc) Seat frame (2 pcs) Front frame (1 pc) Back frame (2 pcs) Front frame (2 pcs)
- Page 5 Sofa connector (6 pcs) Bolt M6x35mm (68 pcs) Bolt M6x30mm (8 pcs) Allen key (1 pc) Seat cushion (6 pcs) Back pillow (6 pcs) Small back pillow (2 pcs) Table glass (1 pc) Pillow (2 pcs)
- Page 6 STEP 1 Connect Back frame (B) & Seat frame (C) with Bolt (1) 4 pcs STEP 2 Connect part from STEP 1 & Right frame (A) with Bolt (1) 3 pcs...
- Page 7 STEP 3 Connect part from STEP 2 & Side frame (E), Inner frame (F) with Bolt (1) & (2) 3 pcs 3 pcs STEP 4 Connect part from STEP 3 & Front frame (D) with Bolt (1) & (2) 6 pcs 1 pc...
- Page 8 STEP 5 Connect Back frame (H) & Seat frame (I) with Bolt (1) 4 pcs STEP 6 Connect part from STEP 5 & Left frame (G) with Bolt (1) 3 pcs...
- Page 9 STEP 7 Connect part from STEP 6 & Side frame (E), Inner frame (F) with Bolt (1) & (2) 3 pcs 3 pcs STEP 8 Connect part from STEP 7 & Front frame (J) with Bolt (1) & (2) 6 pcs 1 pc...
- Page 10 STEP 9 Connect Back frame (K) & Seat frame (L) with Bolt (1) 2 pcs STEP 10 Connect part from STEP 9 & Side frame (E) with Bolt (1) 6 pcs...
- Page 11 STEP 11 Connect part from STEP 10 & Front frame (M) with Bolt (1) 4 pcs STEP 12 Connect Table top frame (N), Big side frame (O) & Side frame (E) with Bolt (1) 5 pcs...
- Page 12 STEP 13 Connect part from STEP 12, Big side frame (O) & Side frame (E) with Bolt (1) 7 pcs STEP 14 After the assembly is complete, link the sofas by Sofa connector (3) as picture.
- Page 13 STEP 15 Put on Seat cushion (5), Back pillow (6), Small back pillow (7) & Pillow (9) to complete sofa.
-
Page 14: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. Liquid spills should be removed immediately.
