Maxsys PC4820 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PC4820 v1.2 • Installation Manual
WARNING: This manual contains information on limitations
regarding product use and function and information on the
limitations as to liability of the manufacturer. The entire manual
should be carefully read.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC4820 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxsys PC4820

  • Page 1 PC4820 v1.2 • Installation Manual WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.
  • Page 2 LIMITED WARRANTY WARNING Please Read Carefully Note to Installers Digital Security Controls Ltd. warrants the original purchaser that for a period of twelve months from the date of purchase, the product shall be free of defects in materials and This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warning to the attention of the users of this system.

  • Page 3: Table Of Contents

    2.5 Door Locking Devices – LK1 & LK2 Terminals ........................3 2.6 Access Card Readers ................................3 PC4820 Connection Chart ................................4 PC4820 List of Supported Readers and Cards ..........................4 Cabling Specifications ..................................5 PC4820 Access Control Module Reader Connections ........................ 5 Programming the PC4820 3.1 Programming Reader Types ..............................
  • Page 4 PC4820 Access Control Module • Lock device and Reader Connections • Battery and AC Connections • Typical Zone Circuits • Combus Connections...

  • Page 5: Introduction

    • Polaris, Shadow Prox, HID Proximity and 26-bit readers, and 26-bit standard Wiegand card readers. The Standard Weigand format PC4820 also supports the use of any request to exit device Access Card Compatibility including the T-REX exit detector. • Polaris POL-C1CN - Polaris Magnetic Cards 1.1 PC4820 Access Control Module...

  • Page 6: Installation And Wiring

    PC4010/4020 v3.0 Installation Manual Instructions for details on wiring and proper (Section 2.4 “Capacitance Limits”). mounting locations.) NOTE: Do not run the Combus to the PC4820 in shielded 2 Tamper protection cable. A tamper switch may be installed on the cabinet to protect it from unauthorized entry.

  • Page 7: Outputs - Led, Buz And Out Terminals

    Access card readers with integrated keypads may be used When using this output to switch an external device, the with the PC4820. In order to use this reader type, the negative terminal of the device must be connected to the user must first present their access card.

  • Page 8: Pc4820 Connection Chart

    Can be used for Arm or Post inputs. See PC4820 Wiring Diagram for wiring instructions. * Tamper connection not available on the MiniProx detector PC4820 List of Supported Readers and Cards Reader Type Reader Part Numbers Supply Voltage Card Part Numbers...

  • Page 9: Cabling Specifications

    I n s t a l l a t i o n a n d W i r i n g PC4820 Access Control Module Reader Connections Polaris Readers (POL-1, POL-2, POL-2KP) Shadow Prox Readers * NOTE: Only use the +5V power supply when using NOTE: Only use the +12V power supply when using the Polaris Readers.

  • Page 10: Programming The Pc4820

    6. a downloading session has disconnected. assigned must also be selected in the Arm/Disarm Mask The data transfer can take up to 2.5 minutes per PC4820 for proper operation of this function. module. When the transfer is completed, all keypads will beep 16 times.

  • Page 11: Arming And Disarming With Access Cards

    Zone 17 to 128 may be used (Zone 9 to 64 on the PC4010). The PC4820 can be set up so that users may arm and disarm, or postpone the autoarm of any active partition You can use any zone supervision option provided by on the system.
  • Page 12 enabled in order for arming to occur. See your PC4010/ schedule time window, the door will be unlocked but 4020 Instruction Manual for information on the partition(s) will not be disarmed when the door is programming access codes and cards. opened.

  • Page 13: Access Level

    3.8 Programming Access Cards one or more partitions. In order for an access card to function on the PC4820 the The default date schedule is 00 (disabled). card must first be programmed into the PC4010/4020.

  • Page 14: Diagnostics

    PC4820 is capable of providing diagnostics INPUTS DOOR 1) and AUX+. information for various conditions that may appear on 4. On the selected PC4820, connect a short from the the module. terminals marked as OUT (for OUT DOOR 1) and •...

  • Page 15: Pc4820 Programming Worksheet

    PC4820 Programming Worksheet Record your PC4820 module programming information here. Make one copy of this sheet for each PC4820 you will install. NOTE: XX = module #; YY = door # [0011] PC4820 Options [0011XX] PC4820 Module Number: I ___ _ _ _ I _ _ _ _ _ _ I...
  • Page 16 Security Products ©1998 Digital Security Controls Ltd. 1645 Flint Road, Downsview, Ontario, Canada M3J 2J6 (416) 665-8460 • Fax (416) 665-7498 • 1-800-387-3630 Printed in Canada 29002622 R1...
