- Page 1 Wine Rack Assembly Instructions WRT480R2 Display Shelves MIDDLE Installation instructions BOTTOM Support Base Parts included B*440 C*231 E*42 D*42 H*32 G*42 J*42 K*22...
- Page 2 H*32 G*42 STEP 1 - ASSEMBLING THE BOTTOM FRAME OF MIDDLE-SECTION • Find a flat surface to begin the assembly process. • Start by assembling the bottom section. • Align the first timber slat with the cross metal grid, starting from the center of the frame. •...
- Page 3 Wine Rack Assembly Instructions STEP 2 - ASSEMBLING THE TOP FRAME OF MIDDLE-SECTION Insert one section of the metal frame only halfway down into the wood pieces. ( Instruction Video ) Insert the 2nd section of the metal frame into the 1st section, ensuring a secure fit into the wood pieces.
- Page 4 STEP 3 - BOTTOM BASE Fix the wine rack (the middle section) to the bottom base MIDDLE SECTION BOTTOM Support Base STEP 4 - NECK PROTECTOR Snap the bottle neck protectors onto the front side of the metal frame. This will provide added protection for the necks of your wine bottles and prevent them from accidentally slipping out.
- Page 5 STEP 5 - TOP SECTION | DISPLAY SHELVES Assemble the display shelves (TOP-SECTION) Display Shelves...
- Page 6 STEP 6 - CONNECT THE TOP AND MIDDLE SECTIONS Attach the plastic CONNECTOR CLIPS to the wooden slats on the bottom of the display shelves (TOP SECTION). Then stack on the top of the MIDDLE section. Display Shelves CONNECTOR CLIPS MIDDLE SECTION BOTTOM...
