- Page 1 PXLNET TRANSMITTER MANUAL Part number: 050211 v4 - March 2024...
-
Page 2: Table Of Contents
TIPS & TROUBLESHOOTING Standard troubleshooting checklist GENERAL INFORMATION Online resources Remarks Disclaimer Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 2 of 14... -
Page 3: Introduction
Built in power supply for DiGidot C4 Can be used with any third-party SPI controller Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 3 of 14... -
Page 4: Technical Drawings
15.5mm 0.98 in/ 25mm 0.37 in/ 9.50mm 2.56 in/65mm 2.56 in/ 65mm Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 4 of 15... -
Page 5: Product Description
Pin 7 brown/white = (DMX) GND/DC- Pin 8 brown = (DMX) GND/DC- ANSI-EXTA E1-11 standard Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 5 of 15... -
Page 6: Technical Specifications
EN60950-1:2006 +A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC60950-1 / EN60950-1, EN61006-6-3, EN55032 Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 6 of 15... -
Page 7: Before Installation
The only way to power o this product is to disconnect it from the power source. The product is designed for indoor use (dry locations) only. Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 7 of 15... -
Page 8: Installation & Wiring
Use the supplied Power Jack cable to power the DiGidot C4. 12-24 VDC Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 8 of 15... -
Page 9: Mounting
Do not use this product outdoors or in humid environments (short circuit risk) Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 9 of 15... -
Page 10: Power Supply
DiGidot C4 controller. If the grounds are not connected, this may cause malfunctioning. Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 10 of 15... -
Page 11: Wiring Schemes
See chapter ‘Installation & Wiring’ for more information about power distribution. Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 11 of 15... - Page 12 Data - Data + Data - Data + Data - 12-24 VDC Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 12 of 15...
-
Page 13: Operation
DMX device inputs or use a DMX XLR adapter. For the exact pinout, check product description above. Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 13 of 14... -
Page 14: Tips & Troubleshooting
Part Number Part # Description DiGidot PxLNet Transmitter 050211 Specifications may be modified or improved without notification Organic Lighting | 12203 Magnolia Avenue, Suite 1, Riverside CA 92503 | 626.969.6140 | www.organiclighting.com | 03/2024 14 of 14...
