Summary of Contents for Fredette S1150
- Page 1 FREDETTE S1150...
- Page 2 FREDETTE This Guide provides necessary instructions on machine operation and maintenance. Before operation or use of this machine, please carefully read and understand this Guide. When ordering the replacement parts, please refer to the spare and accessory parts manual attached to the machine. Before matching parts or accessories, please firstly determine your machine model and serial number.
-
Page 3: Table Of Contents
FREDETTE Content Precautions This machine is suitable for industrial and commercial use and specially used for cleaning indoor hard floor instead of other purposes. Please use the Precautions......................3 suggested scouring pad and brush as well as the commercially available floor Instructions on Machine Operation..............4... -
Page 4: Instructions On Machine Operation
FREDETTE Instructions on Machine Operation 3. When using the machine: -please walk slowly when encountering the slope and sliding surface. -Please slow down when turning. -report immediately when the machine is broken or the operation fails. -do not let the children play on or around the machine. -
Page 5: Reception Of Machine
FREDETTE 2. Carefully install the battery in the battery cabin and connect the battery cable Reception of Machine according to the following figure Machine Unpackaging 1. Please carefully check whether there is damage on the packing box of the Blue machine. -
Page 6: Machine Operation
FREDETTE Machine Operation 4. Plug the AC (alternating current) power cord of the charger to the 1.Panel power socket with sound grounding. Key Switch. Clockwise switch to turn on. Counter clockwise to turn off 5. The charger will automatically start charging and will automatically Use direction switch to forward and reverse switch off when it is full. -
Page 7: Maintenance Instruction And Replacement Of Wearing Parts
FREDETTE Maintenance instruction and replacement of wearing parts 2.Replace of Roller brush Take off the roller supporter. When you need to replace or clean the Roller brush, Open the side Cover, Unscrew the rubber guard and take off it. Take off the side plate of the roller brush. -
Page 8: Technical Parameters
Clockwise to switch the nuts on both sides of the tire to adjust the brakes doesn’t work Technical parameter Unit S1150 and the both sides bake balance until the brake works well. properly Associated parts: Controller, fuse (below one), Bidirectional contactor... - Page 9 FREDETTE Equipment operation 1.Steer wheel and operation panel 2.LED light Turn off the power switch when cleaning the machine. 3.Accelerator 4.Brake pedal This machine uses the special brush specified by the manufacturer. Assembling other 5.Sprayer brushes may affect the sweeper performance 6.Side-brush...
- Page 10 FREDETTE Then when you want to release the parking brake, you can first kick the parking pedal forward, the parking pedal is played to the front up, and then as long as you press on the brake to release the parking.The brake pedal is back on and the accelerator is ready to use.
- Page 11 FREDETTE 2.Filter element dust removal and cleaning Before or after the sweeper used, please pull up the dust handle and rotate it clockwise and counterclockwise to achieve the dust shock of the filter element. Filter remove cleaning: clean the floor machine in the use of a month or vacuuming...
