Summary of Contents for VisionNet 491105
- Page 1 QUICK USE GUIDE Wall-mounted charger EV WALLBOX EV CHARGING STATION p.n.491105 (MODE A) (MODE C)
- Page 2 CONTENT IN THE BOX （MODE A ） STATION REFERENCE PLATE PAPER EV CHARGING STATION HOOK TOOLS NEEDED FOR INSTALLATION ELECTRIC DRILL 30MM PLASTIC BOLTS SCREW SHIM (FOR PLATE AND HOOK) ×4 ×10 HAMMER 30MM SCREWS 95MM SCREWS 30MM METAL BOLTS (FOR PLATE AND HOOK) SCREWDRIVER ×10...
- Page 3 Hammer the 30mm plastic bolts Reference paper Take down the reference paper Drill the holes Fix the plate with 30mm screws Place station onto plate...
- Page 4 Rmove the front board Fix the socket on the wall Remove the protective film Installation is completed PHASE PHASE Connect each wire correctly Fix the hook with four plastic bolts...
- Page 5 CONTENT IN THE BOX （MODE C ） STATION REFERENCE PLATE PAPER EV CHARGING STATION HOOK TOOLS NEEDED FOR INSTALLATION ELECTRIC DRILL 30MM PLASTIC BOLTS (FOR PLATE AND HOOK) HAMMER ×10 SCREWDRIVER 30MM SCREWS (FOR PLATE AND HOOK) ×10...
- Page 6 Hammer the 30mm plastic bolts Reference paper Drill the holes Take down the reference paper Place station Fix the plate with onto plate 30mm screws...
- Page 7 Remove the protective film Installation is completed PHASE PHASE Fix the hook with four plastic bolts Connect each wire correctly...
- Page 8 SECURITY WARNING ATTENTION Non-compliance with the operating instructions can cause serious consequences. Manufacturer does not assume any liability for damage caused by disregarding operating instructions or other warnings marked on the device. High voltage, fire hazard! Never use the device if the housing is damaged or opened! This product is not suitable for people with limited mobility, sensory or psychological disabilities, and those who lack use experience or a certain degree of knowledge.
