SeaLand ITX-B110 User Manual

Based on intel® tiger lake mini-itx motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Intel○ R Tiger Lake Processor
ITX-B110 VER:1.1
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITX-B110 and is the answer not in the manual?

Questions and answers

Summary of Contents for SeaLand ITX-B110

  • Page 1 Intel○ R Tiger Lake Processor ITX-B110 VER:1.1 - 1 -...
  • Page 2 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Order Information Model Processor Frequency Memory VGA HDMI LVDS USB COM 485/422 Power 2*SODDR4 COM2/3 DC12V 1 ITX-B110_C316L VER:1.1(6305) 6305 1.8G 2ch/24Bit 2*I225V 2*SODDR4 COM2/3 DC12V 2 ITX-B110_I526L VER:1.1(1135G7) I5-1135G7 2.4G 2ch/24Bit...
  • Page 3 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Safety Instructions 1．Please read this manual carefully before using this product. 2．Please put all unused/uninstalled boards and cards in anti-static bags. 3．Please first place your hands on grounding metal object for a while before you go to take out the board from its package, so as to release body electrostatic.

  • Page 4: Table Of Contents

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Catalog Chapter 1 Product Introduction .....................- 5 - 1.1 Product Introduction ....................- 5 - 1.2 Product Specification ....................- 5 - Chapter 2 Installation Instruction ..................- 9 - 2.1 Motherboard Dimension ..................- 9 - 2.2 Interface Schematic Diagram ................
  • Page 5 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.1 Enter Into BIOS Interface ................... - 31 - 3.2.2 Main Menu（BIOS Information and Time/Date） ..........- 33 - 3.2.3 Advance ......................- 34 - 3.2.4 CPU Configuration ....................- 35 - 3.2.5 ACPI Settings ..................... - 36 - 3.2.6 Miscellaneous Configuration ................- 37 -...

  • Page 6: Chapter 1 Product Introduction

    1 or 2 Intel I225V Gigabit Ethernet, 2 or 6 COM port, support M.2 5G module, M.2 SSD / M.2 WIFI6. ITX-B110 combines stable reliable industrial grade performance and intelligent digital multimedia player advantage, can be widely used for advertising, education, media player, LCD screen, traffic control, information system, financial equipment, vehicle, military, etc.
  • Page 7 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Note: 1* EDP optional, same pin port with LVDS, need change hardware LVDS screen voltage can support 12V, default 3.3V Before using LVDS, please must check the LCD’s working voltage to make setting...
  • Page 8 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 1* JHDMI port, 2*10pin 1* LVDS port, 2*15pin, support dual channel 24bit. (1* EDP optional) 1* LVDS backlight power supply port, 1*6pin 1* Screen dimming function port, 1*4pin 6* RS232 COM port, COM1 support the 9...
  • Page 9 This motherboard install EFI WIN10 OS, cannot copy the OS to use on other motherboard Dimension、Environment Dimension：170mm x 170mm Working Temp.：-10℃～60℃ Working Humidity：5～95% relative humidity, non-condensing Storage Temp.：-20℃～70℃ Product Photo: Image 1：ITX-B110 VER:1.1 Front View Image 2：ITX-B110 VER:1.1 I/O View - 8 -...

  • Page 10: Chapter 2 Installation Instruction

    Note：Please wear anti-electrostatic glove during installation, static electricity may cause damage to components. ITX-B110 VER:1.1 Dimension Drawing Tips: 1. Please must use suitable screws and right installation method, otherwise may bring damage to motherboard.

  • Page 11: Interface Schematic Diagram

    Mini-ITX Motherboard pin, otherwise may cause damage to the motherboard. 2.2 Interface Schematic Diagram ITX-B110 I/O Port Schematic Diagram Tips: LVDS screen working voltage support 3.3V、5V、12V selectable by jumper, defaulted as 3.3V. Before using LVDS please must learn the LCD’s required rated working voltage.

  • Page 12: Installation Steps

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.3 Installation Steps Please follow below steps to assemble your computer: 1．Please refer to the manual to adjust all jumpers on ITX-B810 correctly. 2．Install other expansion cards. 3．Connect all signal cable, power cables, panel control circuit and power supply.

  • Page 13: Jpw1 Jumper Setting

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard elimination of previous system settings and make the system back to the original settings (factory setting). Steps： (1) Power off computer, unplug power supply. (2) Use jumper cap short circuit “JBAT1” pin 2-3 5 to 6 seconds, then put back to defaulted setting pin 1-2 shorted;...

  • Page 14: Module Voltage Setting（Pwr_Sel1

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Setting JPW1 1-2 Short Disable Auto Power On 2-3 Short Enable Auto Power On 2.5.3 4G Module Voltage Setting（PWR_SEL1） PWR_SEL1 Definition： Setting PWR_SEL1 1-2 Short 3.3V 2-3 Short 3.8V 2.6 Interface Description Please read the following instructions carefully before connecting external devices in case cause damage to the motherboard.

  • Page 15: Com Port (Com1、Com2、Com3-6、Jp16、Jp17、Jp19、Jp20、Jpcom2、 Jpcom3)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard +12V SATA_TXP SATA_TXN SATA_RXN SATA_RXP Tips： 1、 SATA power supply port PWROUT1 pin 1 is +12V output, pin4 is +5V output, please use our company standard power cable, in case burn the hard disk.
  • Page 16 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard COM1、COM2 Definition: Signal Name Signal Name COM3-6 Definition: Signal Name Signal Name COM3_DCD COM3_RXD COM3_TXD COM3_DTR COM3_DSR COM3_RTS COM3_CTS COM3-RI COM4_DCD COM4_RXD COM4_TXD COM4_DTR COM4_DSR COM4_RTS COM4_CTS COM4-RI COM5_DCD COM5_RXD COM5_TXD COM5_DTR...
  • Page 17 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 1-2 Short RS232 3-4 Short COM1 5-6 Short +12V JP17 Setting： Setting Function (JP17) 1-2 Short RS232 3-4 Short COM2 5-6 Short +12V JP19 (COM2 RS485/422)Setting： Setting COM2 2-3,5-6,8-9,11-12 Short RS232 1-2,4-5,7-8,10-11 Short RS485/422 JP20 (COM3 RS485/422)Setting：...

  • Page 18: Display Port (Vga1、Jvga1、Hdmi1、J_Hdmi1、Lvds/Edp1、Inverter1、 Invt_Pwr1、Pan_Pwr1、Jsw1、Sw1)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard COM2/3 RS422 Definition： Signal Name Signal Name T/R+ T/R- RXD+ RXD- 2.6.3 Display Port (VGA1、 JVGA1、 HDMI1、 J_HDMI1、 LVDS/EDP1、 INVERTER1、 INVT_PWR1、PAN_PWR1、JSW1、SW1) The board external provide 1* VGA port, 1* HDMI port Internal provide 1* JVGA port,1*12pin; 1*JHDMI port, 2*8pin;...
  • Page 19 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard LVDS/EDP1 HDMI PAN_PWR1 VGA1 INVT_PWR1 JVGA1 INVERTER1 JSW1 J_HDMI1 VGA1 Definition： Signal Name Signal Name Green Blue DDCDATA HSYNC VSYNC DDCCLK JVGA1 Definition： Signal Name Signal Name VSYNC HSYNC - 18 -...
  • Page 20 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard DDC_SDA DDC_SCL HDMI1 Definition Signal Name Signal Name TMDS Data2+ TMDS Data2 Shield TMDS Data2- TMDS Data1+ TMDS Data1 Shield TMDS Data1- TMDS Data0+ TMDS Data0 Shield TMDS Data0- TMDS Clock+ TMDS Clock Shield TMDS Clock- Reserved (N.C.)
  • Page 21 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard EDP_TX1- EDP_TX1+ EDP_AUX- EDP_AUX+ LVDS1 Definition: Signal Name Signal Name LCDVDD LCDVDD LCDVDD LVDS_A0- LVDS_A0+ LVDS_A1- LVDS_A1+ LVDS_A2- LVDS_A2+ LVDSA_CLK- LVDSA_CLK+ LVDS_A3- LVDS_A3+ LVDS_B0- LVDS_B0+ LVDS_B1- LVDS_B1+ LVDS_B2- LVDS_B2+ LVDSB_CLK- LVDSB_CLK+ LVDS_B3- LVDS_B3+ Screen voltage can be different for different LCD, the board provide 3.3V,5V,12V...
  • Page 22 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard voltage. When the selected LCD voltage same with the LCD screen voltage, LCD screen can be displayed normally. Settings as follows： INVERTER1(Backlight Power Supply Port) Definition: Signal Name 12V/5V (INV_PWR1Setting) 12V/5V (INV_PWR1Setting)
  • Page 23 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 1、2、3、4 represents 1，5、6、7、8 represents 0. For example：1、0011 switch locations is：5634， 2、0101 switch locations is：5274， 3、1010 switch locations is：1638， 4、Factory defaulted switch locations is 1234, that is 1111 - 22 -...

  • Page 24: Power Supply (Dc12V_In1、Dc12V_In2)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.6.4 Power Supply (DC12V_IN1、DC12V_IN2) The board provide 1*4pin power connector, support 12V input output 1* power adaptor port, support 12V input output DC12V_IN2 DC_IN1 DC12V_IN2 Definition： Signal Name - 23 -...

  • Page 25: Kb/Ms Port（Kbms1

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.6.5 KB/MS Port（KBMS1） Board provide 1*6pin KB/MS port (red color), need install PS/2 cable to use this port KBMS1 KBMS1 Port Definition: Signal Name +5V(standby) KB_DT KB_CK MS_DT MS_CK - 24 -...

  • Page 26: Audio Port (Jphone1、Jmick1、Fp_Audio1、Jspkr1)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.6.6 Audio Port (JPHONE1、JMICK1、FP_AUDIO1、JSPKR1) Board provide 1* JPHONE1、JMICK1 standard audio port; Built-in a 2*5pin front audio port, 1*4pin power amplifier port. JMICK1 FP_AUDIO1 JPHONE1 JSPKR1 FP_AUDIO1 (Front Panel Audio Port) Definition: Signal Name...

  • Page 27: Usb Port (Usb1、Usb2、F_Usb1、F_Usb2、F_Usb3)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.6.7 USB Port (USB1、USB2、F_USB1、F_USB2、F_USB3) The board external provide 2* USB3.0, 2* USB2.0 Internal 6*USB2.0 (2.54mm, 2*5pin) Note: USB1 / F_USB1 optional, USB1 / LAN2 optional For single LAN, external 4*USB, internal 4*USB2.0 For dual LAN, external 2*USB, internal 6*USB2.0...

  • Page 28: Lan And Fan Connector (Lan1、Lan2、Cpufan1、Sysfan1)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.6.8 LAN and Fan Connector (LAN1、LAN2、CPUFAN1、SYSFAN1) Provide 2 * standard Gigabit LAN port Built-in 1* 4pin CPU smart fan connector, 1* 4pin system fan connector SYSFAN1 LAN1/2 CPUFAN1 CPUFAN1、SYSFAN1 Definition： Signal Name +12V Remark：DET：fan speed pulse output；PWM：fan speed PWM control...

  • Page 29: Front Panel Port (Fpanel1)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.6.9 Front Panel Port (FPANEL1) The board provide a 2*5pin front panel pin port, used for connecting with front panel power button and LED indicator. FPANEL1 FPANEL1 Definition: Signal Name Signal Name...

  • Page 30: Programmable Input Output Port（Gpio1

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard on the front panel of chassis, for connecting or cutting off power supply. 2.6.10 Programmable Input Output Port（GPIO1） Please write GPIO driver program under OS (windows series please refer to the information of related Microsoft Driver; Linux, UNIX, please refer to the related Linux Driver framework model), use GPIO driver to drive GPIO module, the following is called a driver.

  • Page 31: Mini-Pcie Port (Ngff1、Wifi1、Ssd1)

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 2.6.11 Mini-PCIE Port (NGFF1、WIFI1、SSD1) Board internal provide 1*M.2 slot, support M.2 Key B 5G module. Internal provide 1* M.2 slot, 1*M.2 Key E WIFI6 module Internal provide 1* M.2 slot, support M.22260/2280 PCIE X1 /SATA SSD, auto...

  • Page 32: Chapter 3 Bios Setting

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Chapter 3 BIOS Setting 3.1. BIOS Description BIOS （Basic Input and Output System） , through CMOS chip on motherboard, it recorded parameter settings of each hardware of the system. BIOS contains the BIOS setup program, for users to set system parameters according to their own needs, to make the motherboard work normal or execute specific function.
  • Page 33 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 6、 <Page Up/+> Add numeric value or change <Page Down/-> Reduce numeric value or change <F1> Set sub menu help <F9> Set default values (optimize to factory settings) <F10> Save BIOS settings Note ：...

  • Page 34: Main Menu（Bios Information And Time/Date

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.2 Main Menu（BIOS Information and Time/Date） Bios ID ： Build Date and Time ： System Date ： Set the current date. In the form of month / day / year. The setting range is: Month (Jan.-Dec.)，Date(01-31)，Year(Max to 2099)，Week(Mon.～Sun.).

  • Page 35: Advance

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.3 Advance CPU Configuration: ACPI Settings：Advanced configuration and power management interface settings. Miscellaneous Configuration: include timing start up, AC power loss (auto power on), NCT61X6D Super IO Configuration：include COM port interrupt code and address setting.
  • Page 36 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.4 CPU Configuration Read only items contain details of the CPU, including the CPU manufacturers, models, frequency, the first level cache size, the second level cache size and other information. Intel Virtualization Technology ：...

  • Page 37: Acpi Settings

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.5 ACPI Settings Enable ACPI Auto Configuration ：This item is ACPI auto configuration, support （Enabled）or（Disabled）BIOS ACPI auto configuration, defaulted（Disabled）. Enable Hibernation： Enabled or Disabled system sleep function（OS/S4 sleep state). This option does not take effect under some OS. Default is (Enabled).

  • Page 38: Miscellaneous Configuration

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.6 Miscellaneous Configuration Resume On RTC Alarm: Set timing boot RTC Alarm Date (Days): Set the scheduled auto power on date, “0” means every day RTC Alarm Time (Hours): wake-up time unit in hours RTC Alarm Time (Minutes): wake-up time unit in minutes RTC Alarm Time (Seconds): wake-up time unit in seconds.

  • Page 39: Super Io Configuration

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard electric; Power On: Power on directly after connecting to electric; Last State: keep previous state after connecting to electric. Watch dog Controller: [Disabled], [Second mode], [Minute Mode] 3.2.7 Super IO Configuration Serial Port 1 Configuration ： serial IO port setting, Super IO configuration, include COM port interrupt code and address setting.

  • Page 40: Pc Health Status

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.8 PC Health Status PC Health Status ： displays the current system temperature, CPU temperature, fan speed, and other relevant voltage value. The above parameters have a certain range, system cannot operate beyond the scope.

  • Page 41: Usb Configuration

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.10 USB Configuration Legacy USB Support ： This is used for old version USB setting, if need to support USB devices in DOS, such as U disk, USB keyboard, etc. set this option as [Enabled] or [Auto]. Otherwise, choose [Disabled].

  • Page 42: Chipset

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.11 Chipset PCH-IO Configuration ： South Bridge configuration, Include audio card, LAN card, auto power on, etc System Agent (SA) Configuration ： North bridge configuration option, include video memory, LVDS, etc VT-d ：Intel's I/O virtualization technology, requires chipset to support, some chipset support it, and some don't.
  • Page 43 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Memory Configuration: Graphics Configuration: GTT Size: video memory size DVMT Pre-Allocated：dynamic allocated video memory value. DVMT Total Gfx Mem：dynamic allocated total Graphic card value. Aperture Size：graphic card shared main memory size SATA And RST Configuration: SATA Mode Selection：(AHCI or IDE)

  • Page 44: Boot

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard SATA Controller speed: Serial-ATA Port 0: (Enabled or Disabled) Serial-ATA Port 1: (Enabled or Disabled) 3.2.12 Boot Setup Prompt Timeout：click the Setup shortcut key to wait time. If did not click the setup shortcut key in the setup time it will continue to startup.

  • Page 45: Security

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.13 Security Password character length: the minimum length is 3, the maximum length is 20. Administrator Password ：used for setting the supervisor password. - 44 -...

  • Page 46: Save & Exit

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard 3.2.14 Save & Exit Save Changes and Reset ： Save the BIOS settings, and exit the settings interface, continue to start the computer Discard Changes and Reset ： Discard changes and exit setup interface, restart the computer.

  • Page 47: Appendix

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard Appendix Appendix one: Glossary of terms ACPI Advanced configuration and power management. The ACPI specification allows the operating system to control most of the power of the computer and its additional equipment.
  • Page 48 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard DIMM Dual in-line memory module. A memory chip group of small circuit board. The memory bus width of 64bit. DRAM Dynamic random access memory. A normal computer general memory types. A transistor and a capacitor is usually used to store a single bit. With the development of technology, type and specification of DRAM has in computer application becomes more and more diverse.

  • Page 49: Appendix Two：common Issue Analysis And Solution

    ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard properly connected and whether the normal work. PS/2 The IBM development of a keyboard and mouse interface specification.PS/2 is a DIN only 6PIN interface can also be used to connect to other devices such as a modem.
  • Page 50 ITX-B110 Based on Intel® Tiger Lake Mini-ITX Motherboard state, can improve brightness through the brightness control. 5 Display in the "power save" mode, press any key on the keyboard 1. Please check whether the CMOS battery voltage is lower than BIOS Setup can not 2.8V, if so, please replace a new battery, set again and save...
