- Page 1 INSTRUCTION MANUAL Cutter 4100NS 009553 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
ENGLISH SPECIFICATIONS Model 4100NS Wheel diameter 110 mm 125 mm at 90° 32.5 mm 40 mm Max. cutting capacities at 45° 21.5 mm 27 mm No load speed (min 12000 Overall length 238 mm Net weight 3.0 kg Safety class •... -
Page 3: Specific Safety Rules
Personal safety 20. Maintain power tools. Check for misalignment Stay alert, watch what you are doing and use or binding of moving parts, breakage of parts common sense when operating a power tool. and any other condition that may affect the Do not use a power tool while you are tired or power tools operation. - Page 4 Always use undamaged wheel flanges that are 13. Never lay the power tool down until the wheel of correct diameter for your selected wheel. has come to a complete stop. The spinning Proper wheel flanges support the wheel thus wheel may grab the surface and pull the power reducing the possibility of wheel breakage.
-
Page 5: Functional Description
FUNCTIONAL DESCRIPTION Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the wheel. Corners, sharp edges or bouncing have a CAUTION: tendency to snag the rotating wheel and cause Always be sure that the tool is switched off and •... - Page 6 "OFF" position when released. 1. Switch trigger 2. Lock button 009564 CAUTION: Use only the Makita wrench and hex wrench to • install or remove the wheel. 009558 Installing water pipe (Accessory) 1. Screw For tool with lock button To start the tool, simply pull the switch trigger.
-
Page 7: Maintenance
Water flow CAUTION: THIS TOOL SHOULD ONLY BE USED ON 1. Water pipe • HORIZONTAL SURFACES. 2. Water cock 3. Vinyl tube Be sure to move the tool forward in a straight line • and gently. Forcing and exerting excessive pressure or allowing the wheel to bend, pinch or twist in the cut can cause overheating of the motor and dangerous kickback of the tool. - Page 8 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Diamond wheels (Dry type) • Diamond wheels (Wet type) • Curving diamond wheels •...
