Summary of Contents for diLUSSO MCO25FTB
- Page 1 Built-in Combi Microwave Oven MCO25FTB Installation and Operating Manual Read the instructions carefully before using the product. Keep this manual for future reference.
-
Page 2: Table Of Contents
CONTENTS Important Notes page 3 Installation Instructions page 6 Oven Parts & Accessories page 9 Operation Instructions Page 10 To set the Clock Microwave Cooking Grill Cooking Combination Cooking Convection / Fan Force Cooking Convection Cooking (Without pre-heating function) ... -
Page 3: Important Notes
Important Notes Dear Customer Thank you for choosing our product. This appliance is simple to use; however please read this handbook carefully before installing and operating it. Herein, you will find the correct method of installation and tips for best use and maintenance of the product. ... - Page 4 Install and locate this oven only in accordance to the installation instructions provided. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after the heating has ended. ...
- Page 5 Power Connection: THE APPLIANCE MUST BE CONNECTED IN ACCORDANCE WITH CURRENT ELECTRICAL RULES AND REGULATIONS. THIS APPLIANCE IS FITTED WITH A PLUG AND MUST BE PROPERLY EARTHED. Installation is to be carried out by an qualified electrician. Before connecting to the mains, make sure that: ...
-
Page 6: Installation Instructions
Installation Instruction Warning : The fitted cabinet must not have a back wall behind the appliance. Do not cover ventilation slots and suction holes. Screws Mounting Bracket Trimkit Cover Built in cabinet requirements : Remark : All dimensions are in mm 380+2 Version 1.0 2022... - Page 7 Wall mounted cabinet : Read the instructions written on the Bottom Cabinet Template. Put the template at the bottom panel of the cabinet. Cabinet Bottom Cabinet Template Mark the bottom panel with position “a” according to the template. Remove the template and fix the bracket with screws. Version 1.0 2022...
- Page 8 Installing the combi microwave oven Put the combi microwave oven to the compartment. Make sure the back of the oven is locked on the bracket. Do Bracket Open the door, fix the oven to the cabinet with screw, as shown in the diagram below : Then cover the installation hole with the trimkit plastic cover.
-
Page 9: Oven Parts & Accessories
Oven Parts & Accessories Control panel Turntable shaft Turntable ring assembly Glass tray Observation window Door assembly Safety interlock system Grill Rack( Only be used in grill function and be placed on the glass tray ) Turntable Assembly Note : Hub (underside) ... -
Page 10: Operation Instructions
Operating Instructions This combi microwave oven uses modern electronic touch controls to set cooking parameters. To set the Clock In standby mode, press “ KITCHEN TIMER/CLOCK ” twice, “00:00” displays. Hour figures flash. Turn the sensor dial in a clockwise or anti-clockwise direction “ ”... -
Page 11: Combination Cooking
Combination Cooking ” key once and “P100” will be displayed. Press the “ MICROWAVE/GRILL/COMBI./CONVE. Continue to press the “ ” key or use the sensor dial “ ” to select the MICROWAVE/GRILL/COMBI./CONVE. combi functions C-1 to C-4. Refer to the table for the combination cooking functions. ... -
Page 12: Convection Cooking (Without Pre-Heating Function)
Convection Cooking (Without pre-heating function) ” key once and “P100” will be displayed. Press the “ MICROWAVE/GRILL/COMBI./CONVE. Continue to press the “ ” key or use the sensor dial “ ” to select the MICROWAVE/GRILL/COMBI./CONVE. convection functions . Continue pressing to choose the temperature setting (130C to 220C). ... -
Page 13: Timer
Press “ WEIGHT/TIME DEFROST ” twice, the oven display will show “dEF2”. Use the sensor dial “ ” to adjust the defrost time of 5 minutes. ” key once. Press the “ MICROWAVE/GRILL/COMBI./CONVE. Use the sensor dial “ ”... - Page 14 Automatic Pre-programmed Chart Menu Weight (g) Display Power Reheat 100% 1 (about 230g) Potato 100% 2 (about 460g) 3 (about 690g) 100% Meat Vegetable 100% Fish 50 (with water 450ml) Pasta 100 (with water 800ml) 150 (with water 1200ml) Soup 100% A8 Cake Preheat at 180 degree...
-
Page 15: Inquiry Function
Inquiry Function In the cooking state, press “ MICROWAVE/GRILL/COMBI./CONVE. ” key once, the current power or temperature will be displayed for 2-3 seconds. During cooking state, press“ KITCH N TIMER/CLOCK ” to check the current time. It will be displayed for 2-3 seconds. -
Page 16: Cleaning And Maintenance
Cleaning and Maintenance Caution: Prior to cleaning or maintenance, always disconnect the power supply. Make sure a steamer cleaner is not used. CLEANING OF STAINLESS STEEL In order to have your oven retain its new appearance; regular cleaning and care should be performed to protect the stainless steel finishes. - Page 17 Materials which are combi microwave safe : Utensils made from Remark Browning dish Follow the manufacturer’s instructions. The bottom of browning dish must be at least 3/6inch or 5mm above the turntable. Incorrect usage of browning dish may cause the turntable to break.
-
Page 18: Troubleshooting
Turntable assembly is dirty Clean the turntable assembly during combi oven operation. Technical Data Model Number MCO25FTB 230-240V~ 50Hz Rated Voltage Rated Input Power (Microwave) 1400-1450W Rated Output Power (Microwave) 850-900W Rated Input Power (Grill) 1000-1100W Rating Input Power (Convection)
