LCD TV
SERVICE MANUAL
46"
46MF460B/F7
46"
46MF440B/F7
46"
46MF401B/F7
© 2011 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form or for any purpose without the express prior written
consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto
is strictly prohibited.
Information in this document is subject to change without notice. Funai reserves the right to change the content
herein without the obligation to notify any person or organization of such changes.
with the
design is a registered trademark of Funai Electric Co., Ltd and may not be used in any way
without the express written consent of Funai. All other trademarks used herein remain the exclusive property of
their respective owners. Nothing contained in this manual should be construed as granting, by implication or
otherwise, any license or right to use any of the trademarks displayed herein. Misuse of any trademarks or any
other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights
to the fullest extent of the law.
chassis FL10.6
Contents
MAGNAVOX
MAGNAVOX
MAGNAVOX
(Serial No. : YA1A)
(Serial No. : YA1A)
(Serial No. : YA1A)
A01Q0UF/A01QAUF/A01QFUF
110120
