HBM 500 PNEUMATIC
MOTORCYLE LIFT.
CAPACITY 700 Kg.
INSTRUCTIONS FOR USE
HBM MACHINES B.V.
Grote Esch 1010 – 2841 MJ Moordrecht.
Telefoon: 0182 525468
Fax: 0182 635119
E-mail:
info@hbm-machines.com
- Website:
http://www.hbm-machines.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HBM 500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HBM Machines HBM 500

  • Page 1 HBM 500 PNEUMATIC MOTORCYLE LIFT. CAPACITY 700 Kg. INSTRUCTIONS FOR USE HBM MACHINES B.V. Grote Esch 1010 – 2841 MJ Moordrecht. Telefoon: 0182 525468 Fax: 0182 635119 E-mail: info@hbm-machines.com - Website: http://www.hbm-machines.com...

  • Page 2: Warranty

    WARRANTY This HBM Machines product complies with the highest standards of workmanship, durability and safety. HBM Machines guarantees original buyers a faultless operation of its products for a one year period with respect to material and construction. This warranty is null and void in case of defects occurring due to the following causes: ...
  • Page 3 In no case shall HBM Machines be liable for the death or injuries of persons, for damages to goods or to the machinery itself, which was caused by operation of machinery supplied by HBM Machines. MAKING USE OF WARRANTY  To use your right to warranty you should send the machinery or its part tuo us, postage paid.

  • Page 4: Safety Measures

    Please note – where machines or machinery is mentioned, the text also applies to tools. © HBM Machines 2009. All Rights reserved. SAFETY MEASURES 1. Only well trained personnel is allowed to operate this machine. In case you are unfamiliar with this type of machine, please get educated before you start operating it! 2.
  • Page 5 (if possible) do not accept your delivery. In case your product arrives in damaged condition (whatever the cause) but the packing case is intact, contact HBM Machines. In case of doubt, ring HBM Machines. In case of obvious damage, always take...

  • Page 6: Unpacking And Assembly

    1. Read the Instructions for Use in full before assembling, commissioning and using this product. If you have any question after having read these instructions, please ask HBM Machines for advice. Then follow the instructions. 2. Please note that Instructions for Use contain sufficient information about the product, enabling normal operation according to its intended use.
  • Page 7 HOISTING AND LIFTING 1. Heavy products are here defined as products weighing over 25 kilograms, the accepted limit for a weight that can be comfortably lifted and shifted by hand. If you (attempt to) lift or shift loads heavier than 25 kilograms without proper lifting or hoisting machinery, you do so at your own risk and you will be responsible for all consequences.
  • Page 8 and also concerning the protection of the product from damage (e.g. to the paint) resulting from the use of hoisting and lifting devices. If you don’t comply, you will be responsible for all consequences. 3. Follow the manufacturer’s advice about fixing and securing movable parts or any other measures to be taken during transport and lifting.

  • Page 9: Safety Instructions And Warnings

    MPORTANT PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFETY INSTRUCTIONS AND WARNINGS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE TO PROPERTY AND/OR PERSONAL INJURY. PLEASE KEEP THIS INSTRUCTION MANUAL SAFE FOR FUTURE USE. 1.

  • Page 10: Before First Use

    3. ASSEMBLY Unpack the lift and check contents with list below. Should there be any damaged or missing parts, contact your supplier immediately. Content ·Main Lift Assembly ·Air/Manual Hydraulic Pump Assembly ·Leading plate 3.1 Put the air hydraulic pump (31) by the side of the lift station.

  • Page 11: Maintenance

    lift. 5.5 When the platform has been raised to the working height, turn off the air valve or stop pumping. NOTE: At this moment, make sure the safety handle (41) is on your right side and the locking plate (09) is locked in corresponding pair of safety latch (14) to prevent accidental lowering.
  • Page 12 EXPLODED DRAWING PARTS LIST Part Description Qnty Part Description Qnty Part Description Qnty Platform Screw Air hydraulic pump assy Sliding plate Locking plate base Lift foot pedal Leading plate Safety wire Rubber pad Steel wheel Bolt Release foot pedal Outside lifting arm Washer Lock nut Base assy...

  • Page 13: Eg - Declaration Of Conformity

    HBM MACHINES B.V. Grote Esch 1010 - NL 2841 MJ Moordrecht. Tel. +31 / (0)1 82 / 52 54 68 - Fax. +31 / (0)1 82 / 63 51 19 EG – DECLARATION OF CONFORMITY Certificate of Compliance In Compliance with:...
