USERS GUIDE SCREENPLAY
VISTA, GENESIS I, GENESIS II SERIES
REGULATORY MODEL
SERIES NAME
P122
SCREENPLAY VISTA
P123
SCREENPLAY VISTA
P124
SCREENPLAY GENESIS I
P125
SCREENPLAY GENESIS II
P126
SCREENPLAY GENESIS II
LENS TYPE/RESOLUTION
STANDARD THROW
SHORT THROW
STANDARD THROW
STANDARD THROW
SHORT THROW
SVGA
XGA
WXGA
SP2234
SP2236
SP2234ST
SP2236ST
SP122
SP124
SP126
SP222
SP224
SP226
SP224ST
SP226ST
1080P
WUXGA
SP2238
SP2238ST
SP228
SP229

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISTA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ScreenPlay VISTA Series

  • Page 1 USERS GUIDE SCREENPLAY VISTA, GENESIS I, GENESIS II SERIES REGULATORY MODEL SERIES NAME LENS TYPE/RESOLUTION SVGA WXGA 1080P WUXGA P122 SCREENPLAY VISTA STANDARD THROW — SP2234 SP2236 SP2238 — P123 SCREENPLAY VISTA SHORT THROW — SP2234ST SP2236ST SP2238ST — P124...
  • Page 2: Table Of Contents

    ADJUSTING THE IMAGE HEIGHT AND TILT .......................27 ADJUSTING THE ZOOM, LENS SHIFT AND FOCUS ..................27 ADJUSTING THE VERTICAL AND HORIZONTAL KEYSTONE ................27 CONNECTING ............................29 CONNECTION DIAGRAM ........................... 29 USING ..............................30 LEDs ................................... 30 KEYPAD ................................30 REMOTE CONTROL ............................31 [page 2] | screenplay.net...
  • Page 3 13.2.3 RS232 CODES READ FROM PROJECTOR ....................65 13.3 SUPPORTED RESOLUTIONS AND REFRESH RATES..................68 13.4 ON SCREEN DISPLAY (OSD) MENU TREE ......................70 14. SPECIFICATIONS ...........................79 14.1 VISTA, P122 & P123, SPECIFICATIONS ......................79 14.2 GENESIS I, P124, SPECIFICATIONS ........................81 screenplay.net | [page 3]...
  • Page 4 15.2 FOR USERS IN CANADA ............................ 85 15.3 FOR USERS IN EUROPEAN UNION ........................86 15.4 FOR USERS IN THE UNITED KINGDON AND NORTHERN IRELAND ..............86 15.5 FOR USERS IN RUISSIA ............................87 16. WARRANTY ............................88 [page 4] | screenplay.net...
  • Page 5: About This Guide

    The manufacturer is not liable for cases of material damage or personal injury INFORMATION caused by incorrect handling or non–compliance with the safety instructions. In such cases, the warranty will be voided. screenplay.net | [page 5]...
  • Page 6: Obtaining Documentation And Information

    Monday – Friday 6am – 5pm PST +1 877-388-8360 support@screenplay.net screenplay.net/support Europe, Middle East & Africa Monday – Friday 8am – 5pm CET eusupport@screenplay.net screenplay.net/support Asia Pacific Monday – Friday 8am – 5pm ICT apsupport@screenplay.net screenplay.net/support [page 6] | screenplay.net...
  • Page 7: Product Description

    ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ Security On/Off Se tting ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ screenplay.net | [page 7]...
  • Page 8 AV Mute ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ ⃝ Crestron Connect Certified [page 8] | screenplay.net...
  • Page 9: Intended Use And Reasonably Foreseeable Misuse

    WXGA 1080P WUXGA MODEL P122 SCREENPLAY VISTA STANDARD THROW — SP2234 SP2236 SP2238 — P124 SCREENPLAY GENESIS I STANDARD THROW SP122 SP124 SP126 — — P125 SCREENPLAY GENESIS II STANDARD THROW SP222 SP224 SP226 SP228 SP229 screenplay.net | [page 9]...
  • Page 10: Right Side

    WXGA 1080P WUXGA MODEL P122 SCREENPLAY VISTA STANDARD THROW — SP2234 SP2236 SP2238 — P124 SCREENPLAY GENESIS I STANDARD THROW SP122 SP124 SP126 — — P125 SCREENPLAY GENESIS II STANDARD THROW SP222 SP224 SP226 SP228 SP229 [page 10] | screenplay.net...
  • Page 11: Left Side

    WXGA 1080P WUXGA MODEL P122 SCREENPLAY VISTA STANDARD THROW — SP2234 SP2236 SP2238 — P124 SCREENPLAY GENESIS I STANDARD THROW SP122 SP124 SP126 — — P125 SCREENPLAY GENESIS II STANDARD THROW SP222 SP224 SP226 SP228 SP229 screenplay.net | [page 11]...
  • Page 12: Top

    WXGA 1080P WUXGA MODEL P122 SCREENPLAY VISTA STANDARD THROW — SP2234 SP2236 SP2238 — P124 SCREENPLAY GENESIS I STANDARD THROW SP122 SP124 SP126 — — P125 SCREENPLAY GENESIS II STANDARD THROW SP222 SP224 SP226 SP228 SP229 [page 12] | screenplay.net...
  • Page 13: Back

    ㉓ ㉓ ㉔ ㉕ REGULATORY SERIES NAME LENS TYPE / RESOLUTION SVGA WXGA 1080P WUXGA MODEL P122 SCREENPLAY VISTA STANDARD THROW — SP2234 SP2236 SP2238 — P123 SCREENPLAY VISTA SHORT THROW — SP2234ST SP2236ST SP2238ST — screenplay.net | [page 13]...
  • Page 14 HDMI 2, 1.4 Input Adjustable feet USB A for service and wireless dongle power 5v/1.5A Air exhaust grill VGA Input Short throw fixed lens Composite Input Air Intake grill S-VIDEO Input Cable and Lock slot 3.5mm Audio Input [page 14] | screenplay.net...
  • Page 15: Safety

    • Near heat sources such as radiators, heat registers, stoves, or other devices that produce heat • Near water or in direct sunlight • In an enclosure such as a book case or a cabinet that restricts air flow screenplay.net | [page 15]...
  • Page 16: Electrical Safety Information

    Disconnect the power supply before cleaning the projector. Do not use abrasive cleaning cloths or chemicals. 3.1.8 SERVICE AND REPAIR SAFETY INFORMATION The projector contains no user serviceable parts. Contact ScreenPlay for service or repair. SAFE DISPOSAL Follow the instructions in the DISPOSAL section in this user guide for safe disposal of the projector.
  • Page 17: Unpacking And Installing

    Table mounted front proejction 2. Table mounted rear projection 3. Ceiling mounted front projection 4. Ceiling mounted rear projection screenplay.net | [page 17]...
  • Page 18: Placement And Distance From The Screen

    59,84 118,11 153,54 2,44 1,83 96,06 72,05 141,73 185,04 10,6 3,05 2,29 120,08 90,16 177,17 232,28 13,4 4,06 3,05 159,84 120,08 236,22 307,09 18,1 5,08 3,81 200,00 150,00 295,28 385,83 22,4 4,57 240,16 179,92 354,33 27,2 [page 18] | screenplay.net...
  • Page 19 129,92 7,48 2,66 1,49 104,72 58,66 118,11 153,54 9,45 3,32 1,87 130,71 73,62 149,61 192,91 11,81 4,43 2,49 174,41 98,03 196,85 255,91 15,75 5,53 3,11 217,72 122,44 248,03 318,90 19,69 6,64 3,74 261,42 147,24 295,28 23,23 screenplay.net | [page 19]...
  • Page 20 1,35 53,15 20,46 8,06 3,23 2,02 127,20 79,50 1,68 66,14 25,07 9,87 3,88 2,42 152,64 95,40 2,02 79,53 29,68 11,69 5,38 3,37 212,00 132,50 2,81 110,63 41,45 16,32 302,9 6,52 4,08 256,86 160,54 133,86 50,24 19,78 [page 20] | screenplay.net...
  • Page 21 259.20 34.29 13.50 200  4.06 3.05 160.00 120.00 7.88 8.78 310.40 345.60 45.72 18.00 250  5.08 3.81 200.00 150.00 9.86 10.97 388.00 432.00 57.15 22.50 300  6.10 4.57 240.00 180.00 11.83 13.17 465.60 518.40 68.58 27.00 screenplay.net | [page 21]...
  • Page 22 211.79 29.89 11.77 200  4.43 2.49 174.32 98.05 6.51 7.17 256.24 282.39 39.85 15.69 250  5.53 3.11 217.89 122.57 8.14 8.97 320.30 352.99 49.81 19.61 300  6.64 3.74 261.47 147.08 9.76 10.76 384.36 423.59 59.77 23.53 [page 22] | screenplay.net...
  • Page 23 150  3.05 2.29 120.00 90.00 1.58 62.40 28.35 11.16 200  4.06 3.05 160.00 120.00 2.11 83.20 37.80 14.88 250  5.08 3.81 200.00 150.00 2.64 104.00 47.24 18.60 300  6.10 4.57 240.00 180.00 3.17 124.80 56.69 22.32 screenplay.net | [page 23]...
  • Page 24: Clearance

    19.72 CLEARANCE Allow at least 30cm clearance around the intake and exhaust vent and ensure that the intake vents do not recycle hot air from the exhaust vent. ❶ Air intake vent ❷ Air outtake vent [page 24] | screenplay.net...
  • Page 25: Ceiling Mount

    “Please note that damage resulting from incorrect installation will void the warranty. If you buy a ceiling mount from another company, please be sure to use the correct screw size. Screw size will vary depending on the thickness of the mounting plate. screenplay.net | [page 25]...
  • Page 26: Mounting Hole Diagram

    Be sure to keep at least 10 cm gap between the ceiling and the bottom of the projector. Avoid installing the projector near a heat source. 115.00 mm 55.00 mm 55.00 mm 107.00 mm [page 26] | screenplay.net...
  • Page 27: Adjusting

    Adjust the settings by using the arrow keys keys Press the Return symbol or Enter button to select a setting. Press the Menu symbol or *Menu *button to close the OSD menu.The menu will close and the projector will automatically save the new settings. screenplay.net | [page 27]...
  • Page 28 Press the Menu button to close the OSD menu.The menu will close and the projector will automatically save the new settings. INFORMATION “Ensure that the projection screen or projection surface is within the required distance from the projector. Refer to “4.3 Placement distance from screen” for more information. [page 28] | screenplay.net...
  • Page 29: Connecting

    CONNECTING CONNECTION DIAGRAM Speakers Screen screenplay.net | [page 29]...
  • Page 30: Using

    ❷ Lamp ❸ Temperature KEYPAD ❶ Up / Keystone correction + ❷ Information ❸ Right / Re-sync ❹ Enter ❺ PowerDown / Keystone correction - ❻ Menu ❼ Directional arrows ❽ Left / Source ❾ Power [page 30] | screenplay.net...
  • Page 31: Remote Control

    ⓲ Menu ⓰ ❼ ⓳ Directional keys ⓯ ❽ ⓴ Re-sync ㉑ AV Mute ⓮ ❾ ⓭ ❿ ⓬ ⓫ INFORMATION Some keys may have no function for models that do not support the key’s feature. screenplay.net | [page 31]...
  • Page 32: Installing Batteries In The Remote Control

    2. Insert AAA batteries in the battery compartment. Ensure each battery’s polarity ± is aligned correctly. 3. Replace back cover on the remote control and press down until it clicks in to place. [page 32] | screenplay.net...
  • Page 33: Remote Control Ir Codes

    5 meters (16.4 feet) when reflecting the IR beam using a screen. The range will depend on the screen’s surface and reflectivity. Direct sunlight or florescent lamps can reduce the range of the remote control. screenplay.net | [page 33]...
  • Page 34: Turning The Projector On

    3. Remove the lens cap. 4. Press the Power button on the keypad or the the symbol on the remote control. The ScreenPlay startup screen will appear after approximately 10 seconds. The Power LED will flash blue and then steady blue. ATTENTION Make sure that people cannot step on any electrical cables or trip over the cables.
  • Page 35: Viewing 3D Content

    Viewing 3D projected content may cause disorientation for some viewers. Accordingly, DO NOT place your 3D projector near open stairwells, cables, balconies, or other objects that can be tripped over, run into, knocked down, broken or fallen over. screenplay.net | [page 35]...
  • Page 36: Enabeling 3D Mode

    2. Select Auto. 3. Press Enter. Other options: • SBS: Display 3D signal in “Side-by-Side” format. • Top and Bottom: Display 3D signal in “Top and Bottom” format. • Frame Sequential: Display 3D signal in “Frame Sequential” format. [page 36] | screenplay.net...
  • Page 37: Using The On Screen Display (Osd)

    HLG content for simulation effect. • HLG SIM.: Decodes and displays Hybrid Log Gamma (HLG) content for the deepest blacks, brightest whites, and vivid cinematic colour using the REC.2020 colour gamut. This mode will be automatically screenplay.net | [page 37]...
  • Page 38: Adjusting The Image Colour And Temperature

    Display › Image Settings › Color. 2. Press Enter. MAGNIFYING THE IMAGE Display › Zoom. Select 2. Press Enter. SELECTING AN ASPECT RATIO Select Display › Aspect Ratio. 2. Select the desired aspect ratio. 3. Press Enter. [page 38] | screenplay.net...
  • Page 39: Adjusting The Brightness

    CHANGING THE PASSWORD Select Setup › Security › Change Password. 2. Type the new password. 3. Press Enter. INFORMATION Do not lose the password. The password can only be reset at an authorized ScreenPlay repair facility. screenplay.net | [page 39]...
  • Page 40: Controlling The Projector From A Web Browser

    7. Type the projector’s IP address type the user name and password. The default user name and password is admin. 8. Click Login. The projector’s configuration page appears. INFORMATION This section is only applicable to p122 and p123 vista products. [page 40] | screenplay.net...
  • Page 41 USING THE ON SCREEN DISPLAY (OSD) Web Control Aspect Ratio Support list below Aspect Ratio WXGA 1080P 16:9 (Follow OSD->Screen Type) 16 :1O (Follow OSD->Screen Type) Native AUTO screenplay.net | [page 41]...
  • Page 42 Notice aspect ratio same with OSO. The aspect ratio of WXGA model will change dueto the screen type setting. [page 42] | screenplay.net...
  • Page 43 USING THE ON SCREEN DISPLAY (OSD) screenplay.net | [page 43]...
  • Page 44 USING THE ON SCREEN DISPLAY (OSD) INFORMATION Only applicable to Superior Series 8.14 DIRECTLY CONNECTING A COMPUTER TO THE PROJECTOR [page 44] | screenplay.net...
  • Page 45: Cleaning

    Please follow all safety and handling instructions listed with the cleaning solution and keep out of reach of children. For schools conducting an overall deep clean of their facilities, here are steps to appropriately protect your ScreenPlay product in advance of chemicals being sprayed or fogging devices being employed: •...
  • Page 46: Disposal

    DISPOSAL Please ensure that those with access to your ScreenPlay products are aware of the cleaning procedure. ATTENTION Ensure your ScreenPlay product is fully covered on all sides before facilities deep cleaning. Chemicals must not be allowed to enter or be sprayed on to the surface of the product, this will avoid any damage to the internal electronic components and outer casing parts.
  • Page 47: 12. Troubleshooting

    No image AV-Mute is on Ensure the AV-MUTE (video off) buttons has not been pressed. No image Brightness and/or contrast Use the On Screen Display (OSD) menu to adjust the brightness and contrast setting is too low screenplay.net | [page 47]...
  • Page 48: Solving Video, Audio And Remote Control Issues

    Install new batteries. work. Remote does not Batteries installed Remove and reinstall the batteries. work. incorrectly. Remote does not Remote is too far from The remote should be within 16.4 feet (5m) of the projector. work. projector. [page 48] | screenplay.net...
  • Page 49: Servicing

    IR receiver. Ensure the operating angle of the remote control is within ±20° to the projector’s IR receiver. Ensure there are no fluorescent light sources shining on the projector’s IR receiver. If you are still experiencing technical issues with your projector, please contact ScreenPlay Customer Support Here 12.5 SERVICING Servicing is required when the projector has been damaged, exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 50: Rs232 Projector Command Codes

    HDMI (HDMI 1) 32 20 31 0D Commands 7E 30 30 31 Direct Source S010 ~XX12 15 32 20 31 35 HDMI 2 Commands 7E 30 30 32 S011 ~XX20 1 Picture Mode Presentation 30 20 31 0D [page 50] | screenplay.net...
  • Page 51 S021 ~XX34 n BrilliantColorTM 34 20 a 0D (a=31 30) 7E 30 30 33 S022 ~XX35 1 Gamma Film 35 20 31 0D 7E 30 30 33 S022 ~XX35 2 Gamma Video 35 20 32 0D screenplay.net | [page 51]...
  • Page 52 (right+) 39 20 31 0D 7E 30 30 35 S029 ~XX59 2 Four corners top-left (left+) 39 20 32 0D 7E 30 30 35 S029 ~XX59 3 Four corners top-left (up +) 39 20 33 0D [page 52] | screenplay.net...
  • Page 53 7E 30 30 36 Format (Aspect S030 ~XX60 7 Auto 30 20 37 0D Ratio) 7E 30 30 36 n = 0 (a=30) ~ 10 S031 ~XX61 n Edge mask 31 20 a 0D (a=31 30) screenplay.net | [page 53]...
  • Page 54 7E 30 30 37 S037 ~XX70 11 30 20 31 31 Language Suomi ελληνικά 7E 30 30 37 S037 ~XX70 12 30 20 31 32 Language 7E 30 30 37 繁體中文 S037 ~XX70 13 30 20 31 33 Language [page 54] | screenplay.net...
  • Page 55 7E 30 30 37 S037 ~XX70 27 30 20 32 37 Language Română 7E 30 30 37 S037 ~XX70 28 30 20 32 38 Language Slovenčina 7E 30 30 37 S037 ~XX70 29 30 20 32 39 Language Pilipino screenplay.net | [page 55]...
  • Page 56 “Off (0/2 for backward 7E 30 30 37 compatible) with ~XX78 0 S046 38 20 32 20 Security password ~nnnn = ~nnnn a 0D ~0000 (a= 7E 30 30 30 30) ~9999 (a=7E 39 39 39 39)” [page 56] | screenplay.net...
  • Page 57 30 32 20 30 Information Hide compatible) 7E 30 30 31 S056 ~XX103 1 30 33 20 31 Keypad Lock 7E 30 30 31 Off (0/2 for backward S056 ~XX103 0 30 33 20 30 Keypad Lock compatible) screenplay.net | [page 57]...
  • Page 58 7E 30 30 31 ~XX110 2 31 30 20 32 Brightness Mode 7E 30 30 31 ~XX110 4 31 30 20 34 Brightness Mode Dynamic 7E 30 30 31 ~XX110 6 31 30 20 36 Brightness Mode Power [page 58] | screenplay.net...
  • Page 59 IR Function Down 34 0D 7E 30 30 31 ~XX140 15 34 30 20 31 IR Function Keystone + 35 0D 7E 30 30 31 ~XX140 16 34 30 20 31 IR Function Keystone – 36 0D screenplay.net | [page 59]...
  • Page 60 = -5 (a=2D 35) ~ 5 S072 ~XX201 n 30 31 20 a Black level (a=35) 7E 30 30 32 S073 ~XX204 1 30 34 20 31 7E 30 30 32 ~XX204 0 30 34 20 30 [page 60] | screenplay.net...
  • Page 61 7E 30 30 33 ~XX322 3 32 32 20 33 Filter Reminder 800hr 7E 30 30 33 ~XX322 4 32 32 20 34 Filter Reminder 1000hr 7E 30 30 33 S081 ~XX323 1 32 33 20 31 Filter Reset screenplay.net | [page 61]...
  • Page 62 ~XX341 n 34 31 20 a Gain ~ 50 (a=35 30) 7E 30 30 33 Colour Setting Cyan n = -50 (a=2D 35 30) S097 ~XX342 n 34 32 20 a Gain ~ 50 (a=35 30) [page 62] | screenplay.net...
  • Page 63 30 35 20 33 3D Format Frame Sequential 7E 30 30 35 S106 ~XX506 0 30 36 20 30 Wall Colour OFF (Whiteboard) 7E 30 30 35 S106 ~XX506 1 30 36 20 31 Wall Colour Blackboard screenplay.net | [page 63]...
  • Page 64: 13.2.2 Sent From Projector Automatically

    SP2234 SP2238 SP2236 INDEX ASCIICODE HEXCODE FUNCTION PROJECTORRETURN SP2234ST SP2238ST SP2236ST “Projector Information a=0, Standby a=1, Warming a=2, Cooling A001 a=3, Out of Range INFOa a=6, Fan Lock a=7, Over Temperature a=8, Lamp(SSI) Hours Running Out” [page 64] | screenplay.net...
  • Page 65: 13.2.3 Rs232 Codes Read From Projector

    31 32 36 Okaaa aaa=-50~+50” 20 31 0D “Aspect Ratio aa=0, None aa=1, 4:3 7E 30 30 aa=2, 16:9 R010 ~XX127 1 31 32 37 Okaa aa=3, 16:10 20 31 0D aa=5, LBX aa=6, Native aa=7, Auto” screenplay.net | [page 65]...
  • Page 66 7E 30 30 “Standby Power Mode 31 35 30 R020 ~XX150 16 a=0, Eco. 20 31 36 a=1, Active” 7E 30 30 “Refresh rate 31 35 30 R015 ~XX150 19 a=string (e.g. 20 31 39 Ok60Hz)” [page 66] | screenplay.net...
  • Page 67 20 34 0D 7E 30 30 R026 ~XX555 1 35 35 35 LAN MAC Address Ok##:##:##:##:##:## 20 31 0D 7E 30 30 “Projector ID R027 ~XX558 1 35 35 38 Okaa aa=00~99” 20 31 0D screenplay.net | [page 67]...
  • Page 68: Supported Resolutions And Refresh Rates

    Side–by–Side (Half) Input Resolutions 1920×1080P @24 Hz Top–and–Bottom 1920×1080P @24 Hz Frame packing 1920×1080i @ 50Hz 1920×1080i @ 60Hz 1280×720P @50Hz HDMI 1.3 Side–by–Side(Half) SBS mode is on 1280×720P @60Hz 800×600 @ 60Hz 1024×768 @ 60Hz [page 68] | screenplay.net...
  • Page 69 24/50/60 Mac 60 WUXGA 1920×1200 (*1) 60/50hz Mac 60 (*1) 1920×1200 @60Hz only support RB (reduced blanking) (*2) Support 3D timing for 3D Ready projector (STD) and True 3D projector (Option) (*3) Window 10 standard timing screenplay.net | [page 69]...
  • Page 70: On Screen Display (Osd) Menu Tree

    2. Wall Colour is Blackboard. Gamma item will be hide. Advanced BrilliantColorTM 1 ~ 10 Warm Colour Temp Medium Cold Red- Hue -50 ~ 50 Red- Saturation -50 ~ 50 Colour Settings Red- Gain -50 ~ 50 Exit [page 70] | screenplay.net...
  • Page 71 -50 ~ 50 RGB Gain/Bias Green Bias -50 ~ 50 Blue Bias -50 ~ 50 Reset Exit AUTO Only for non-HDMI source Colour Space RGB (0~255) Only for HDMI source RGB (16~235) Only for HDMI source screenplay.net | [page 71]...
  • Page 72 Only for WXGA, 1080p models. Native Original image without any scaling Auto Edge Mask 0 ~ 10 Zoom -5 ~ 25 -100 ~ 100 One step: 2 Image Shift -100 ~ 100 One step: 2 Exit [page 72] | screenplay.net...
  • Page 73 1. Only for 1920x1080 60Hz timing 2. Disable Keystone/Overscan/ Enhanced Gaming Zoom/Image Shift/Aspect Ratio when turn On Picture Mode Lock Audio SETTING 1 SETTING 2 SETTING 3 VALUES Mute — — Off / On (ICON) Volume — — 0—10 screenplay.net | [page 73]...
  • Page 74 Russian Magyar Hungarian Čeština Czech ‫يبرع‬ Arabic ไทย Thai Türkçe Turkish ‫یسراف‬ Farsi Tiếng Việt Vietnamese Bahasa Indonesia Indonesian Bengali বাংলা Front (ICON) Rear (ICON) Projection Front-Ceiling (ICON) Rear-Ceiling (ICON) Top-Left (ICON) Menu Location Top-Right (ICON) [page 74] | screenplay.net...
  • Page 75 Extron => Port 2023 AMX Device Discovery => Port Apply 9131 PJ Link => Port 4352 Telnet => Port 23 HTTP => Port 80, Webpage Exit Control Default Advanced Logo Neutral Same as below Background Colour setting screenplay.net | [page 75]...
  • Page 76 If IR Function setting from On IR Function to Off, Keypad Lock will be automatically changed to Off. AV Mute Remote Settings Wall Colour Executed through the “AV Mute” User 1 Brightness key on the remote control Contrast Gamma [page 76] | screenplay.net...
  • Page 77 Sleep Timer (min) 0 ~ 990 One step: 30 Advanced Quick Resume VGA Out (Standby) USB Power Standby not supported Exit Lamp Hours (DisplayOnly) Range 0~99999 Lamp Reminder Bright Lamp Settings Brightness Mode Dynamic Lamp Reset Exit Reset screenplay.net | [page 77]...
  • Page 78 (DisplayOnly) Refresh Rate (DisplayOnly) Picture Mode (DisplayOnly) Bright (DisplayOnly) Range 0~99999 Eco. (DisplayOnly) Range 0~99999 Lamp Hours Dynamic (DisplayOnly) Range 0~99999 Total (DisplayOnly) Range 0~99999 Brightness Mode (DisplayOnly) System (DisplayOnly) Firmware Version (DisplayOnly) Project ID (DisplayOnly) [page 78] | screenplay.net...
  • Page 79: 14. Specifications

    Mini D-sub 15-pin (VGA) ✅ ✅ ✅ ✅ ✅ ✅ Composite Video ✅ ✅ ✅ ✅ ✅ ✅ S-Video — — — — — — HDMI™ 1.4 ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ screenplay.net | [page 79]...
  • Page 80 Simiplifed Users Guide ✅ ✅ ✅ ✅ ✅ ✅ VGA Cable ✅ ✅ ✅ ✅ ✅ ✅ Regional Power Cord ✅ ✅ ✅ ✅ ✅ ✅ Remote Control (no Battery) ✅ ✅ ✅ ✅ ✅ ✅ [page 80] | screenplay.net...
  • Page 81: Genesis I, P124, Specifications

    Digital Zoom Demagnification / 0.8× ~ 2.0× Magnification  Focus Adjustment Manual CONNECTIVITY—INPUTS Mini D-sub 15-pin (VGA) ✅ Composite Video — S-Video ✅ HDMI™ 1.4 ✅ RJ45 - LAN 10/100/1000 — 3.5 mm Stereo Mini Jack ✅ screenplay.net | [page 81]...
  • Page 82 WEEE, EU RoHS, China RoHS, CEL, CECP IN THE BOX Projector ✅ ✅ ✅ Simiplifed Users Guide ✅ ✅ ✅ VGA Cable ✅ ✅ ✅ Regional Power Cord ✅ ✅ ✅ Remote Control (no Battery) ✅ ✅ ✅ [page 82] | screenplay.net...
  • Page 83: Genesis Ii P125 & P126, Specifications

    Digital Zoom Demagnification / 0.8× ~ 2.0× Magnification  Focus Adjustment Manual CONNECTIVITY—INPUTS Mini D-sub 15-pin (VGA) ✅ Composite Video — S-Video ✅ HDMI™ 1.4 ✅ ✅ RJ45 - LAN 10/100/1000 — 3.5 mm Stereo Mini Jack ✅ screenplay.net | [page 83]...
  • Page 84 Storage Humidity (%) 10 ~ 85 Security Kensington Security Slot™, PIN Code Lock & Timer Safety and Regulatory CB, CE, EAC, cTUVus, CCC, FCC, UKCA, NOM, PSB, BIS Environmental WEEE, EU RoHS, China RoHS, CEL, CECP [page 84] | screenplay.net...
  • Page 85: Product Compliance

    13190 SW 68th Parkway, Suite 120 Portland, Oregon 97223, 15.2 FOR USERS IN CANADA INFORMATION This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada. screenplay.net | [page 85]...
  • Page 86: For Users In European Union

    Room 1001, 10/F, Houston Centre, 63 Mody Road, Tsim Sha Tsui East, Kowloon, Hong Kong. EU Authorised Representative 24hour Solutions B.V. Van Nelleweg 1, 3044 BC, Rotterdam, The Netherlands info@24hour-ar.com www.24hour-ar.com 15.4 FOR USERS IN THE UNITED KINGDON AND NORTHERN IRELAND INFORMATION UK COMPLIANCE [page 86] | screenplay.net...
  • Page 87: For Users In Ruissia

    представителя в России, и этот продукт соответствует требованиям TR TC 004/2011, TR TC 020/2011 и TR CU 020 /2011г. местные испытания на соответствие и согласования ООО « АУВИКС » 129085, г. Москва, Звездный бульвар, д. 21, стр. 1 +7 (495) 797-57-75 info@auvix.ru screenplay.net | [page 87]...
  • Page 88: 16. Warranty

    DEAD ON ARRIVAL (DOA) All new sealed ScreenPlay products carry a fourteen (30) day Dead on Arrival (DOA) warranty policy for the first consumer purchaser. A new replacement unit will be provided if the product is found to be non-operational within fourteen (30) days of purchase or fails due to a manufacturing fault.
  • Page 89 3. Replacement of the product OBTAINING WARRANTY SERVICE Submit your request using the service form or contact your local ScreenPlay support, information and details can be located at www.screenplay.net/support Be sure to read our RMA instructions closely to ensure a smooth and timely process of your report; these will be sent to you with the RMA confirmation.
  • Page 90 TRADEMARKS ScreenPlay and the ScreenPlay wordmark are registered trademarks of Maxnerva. All other trademarks or registered trademarks are property of their respective companies. Copyright © 2023 by Maxnerva Technology Services Limited.
