- Page 1 POWER STATION 5000W S5-E 3000W S3-E USER MANUAL ALFA IN a.s. www.alfain.eu Power station S5-S3 manual EN 01...
-
Page 2: Table Of Contents
Content: Introduction ....................4 Product list ....................5 Product description ..................5 Parameter specifications ................5 Function description ................6 LCD screen description ................7 Instruction for use ..................8 Recharge methods ..................9 AC charging .................... 9 Solar charging ..................11 Car charging .................. - Page 3 Personal settings and more ..............23 7.4.1 Modify avatar and nickname .............. 23 7.4.2 Change password ................23 FAQ ......................23 Fault code and troubleshooting ..............25 Storage and maintenance ................27 Electrical waste disposal ................27 Warranty list .................... 27 ALFA IN a.s.
-
Page 4: Introduction
1. Introduction Dear consumer, Company ALFA IN a.s. thank you for purchasing our product; we believe you will be satisfied with our machine. Congratulations on choosing a professional device for an independent power generator based on battery storage. To ensure safe operation, please carefully read the user manual. Improper device use may result in personal injury or damage to the device or other property. -
Page 5: Product List
2. Product list 1. Power station 2. AC charging cable 3. Anderson cable 4. Anderson – car charging cable 5. Anderson - 7909 cable 6. Anderson - MC4 cable 7. User manual and Warranty card 3. Product description Parameter specifications Output technical parameters 5000W 3000W... -
Page 6: Function Description
Common information IP Grade IP22 Working 0-40 °C temperature Dimensions 641,5*304,5*437,5mm Weight 51 kg 37,8 kg Function description ALFA IN a.s. www.alfain.eu Power station S5-S3 manual EN 01... -
Page 7: Lcd Screen Description
Pos. Name AC Output port (16A Max) LCD Screen Anderson output port USB-C Output USB-A Output AC Output power On/Off switch Main power On/Off switch IOT On/Off switch 12V Car charger output port DC 5521 Output port DC Output power On/Off switch AC Recharging input port Anderson input port Circuit breaker port... -
Page 8: Instruction For Use
Pos. Name Battery capacity percentage Fault warning Remaining discharge time display AC output USB-A USB-C High-temperature protection Cooling fan Low-temperature protection Car charge port status DC 5521 port status Input power display Output power display Wi-Fi and Bluetooth connection Battery capacity circle 4. -
Page 9: Recharge Methods
NOTICE: Never cover the device, and always keep the air vents clean 1. After the product is turned on, short press the main power button, and the LCD screen will turn off, but the product will not be turned off. 2. - Page 10 NOTICE: For fast charging, use the power cable that was included. Do not use other cables for charging. Plug the cable into a mains socket and ensure the mains output is more than 16A. Otherwise, reduce the charging speed using the AC charging switch. The company is not responsible for any consequences caused by failure to follow these instructions, including charging with other power cables.
-
Page 11: Solar Charging
Solar charging Use the accessories Anderson-MC4 cable and 6 pcs MC4-7909 (only one pc of MC4- 7909 cable is included). With approximately 1500W of solar panel power, the device will be fully charged in about 3,5 hours. For charging the device, it is also possible to use PV panels of frame or foil construction in possible serial or serial-parallel connection under maximum voltage 140V, maximum current 15A. -
Page 12: Car Charging
NOTICE: 1. The solar charging cable (MC4-7909) cable is included in the delivery. Solar panels and connection cables with MC4 connectors are not part of the package. 2. When using the matching solar panel to charge this product, please connect it according to the user manual. -
Page 13: Other Function
NOTICE: 1. Please ensure that the product and the power pack are turned off before connecting the power pack to this product. 2. After this product is connected to the power pack, make sure that the LCD of this product shows the input power, and then start to use it. 3. -
Page 14: Disconnection Switch
NOTICE: This function is a non-professional UPS function and does not support 0ms switching. Please do not connect it to devices that require a high uninterrupted power supply (such as data servers and workstations) or use it after multiple tests to confirm whether it is compatible. - Page 15 4. Certain modifications of the device are installed with thermal protectors under the sockets. When the rated current is exceeded, the socket is disconnected. By pressing the thermal protection button, the disconnected circuit can be reconnected. ALFA IN a.s. www.alfain.eu Power station S5-S3 manual EN 01...
-
Page 16: App
7. APP Control, monitor and customize your power station from afar with the APP. Download at: https://wp2- us.doiting.com/release/wpoem/downLoad.html?param=1,JTEnK3,0 Scan the QR code to download the smart control APP. Sign up and log in 7.1.1 Sign up Open the APP and click "Sign up now" to sign up. Enter your email or phone number in the form to request a verification code. -
Page 17: Log In
7.1.2 Log in 7.1.3 Log in by third– party account The Android version APP allows If you have an account already, tap users to log in through Google accounts. "Log in" to enter your account name and The IOS version APP allows users to log in password. -
Page 18: Connection Setup
Connection setup There are three connection methods for the devices: Bluetooth, the device's Wi-Fi hotspot, and IOT. When the APP establishes a Bluetooth or a Wi-Fi hotspot connection with the device, you can view the real-time status of the device through the APP and then control and manage the device wirelessly. - Page 19 To connect to your device using Bluetooth, press "Use Bluetooth direct connection" on your mobile device. You can tell when the two devices are paired by the icon flashing more slowly. NOTE: The application can be on multiple devices, but only one device will be connected to the battery source.
- Page 20 2. Automatically discover Bluetooth If the "Discover devices" dialogue does not appear on the APP's home page, you can click the "Add device" button to search for nearby Bluetooth devices. If you click the "Add device" button, the APP does not scan the Bluetooth devices to be added. You can manually select the corresponding device, reset it according to the APP guidelines, and then connect the Bluetooth.
-
Page 21: Device's Wi-Fi Hotspot Connection
7.2.2 Device’s Wi-Fi hotspot connection Click the "Add device" button on the APP’s home page. You can select the corresponding device that supports a Wi-Fi hotspot connection in the manually added device list, and according to the instructions of the APP, click the "IOT" button to reset the device and connect to the Wi-Fi hotspot. -
Page 22: Device Control And Upgrade
Device control and upgrade 7.3.1 Device control After the successful connection, the APP will display the connected device. You can enter the device details page by clicking the corresponding device icon to view the real-time status and data and control it. Device is offline When there is no Bluetooth, Wi-Fi hotspot, or IOT connection between the APP and the device, it is offline, and you cannot view the device status and data or control the device... -
Page 23: Personal Settings And More
Personal settings and more 7.4.1 Modify avatar and nickname Enter the APP, click the button at the upper left to enter the homepage, and then click the avatar and nickname area at the top to enter the personal settings page. On the personal settings page, click the avatar or nickname button and follow the prompts on the page to modify the avatar or nickname. - Page 24 8. Is the actual output capacity of the product consistent with the capacity states in the user manual? The capacity listed in the manual is the nominal capacity of the battery. Due to efficiency losses due to charging and discharging, the actual capacity may be lower. 9.
-
Page 25: Fault Code And Troubleshooting
9. Fault code and troubleshooting Code Description Performance Troubleshooting Press the AC output AC output short circuit Flashing, no E000 power ON/OFF button protection output for recovery. Flashing icons indicate which circuit overloads. Output overload Flashing, no Overload protection E001 protection output needs to be restored... - Page 26 You need to press the USB-C port overload and Flashing, no E012 DC ON/OFF switch to short circuit output restore manually. Restart the Battery low voltage corresponding function Flashing, no E013 protection when DC button to restore the output discharge function and charge in time.
-
Page 27: Storage And Maintenance
Storage and maintenance 1. Please store the product away from water, heat, and metal objects. 2. To prolong the battery's service life, it is recommended to use or store this product in an environment temperature between 20°C and 30°C. 3. For long-term storage, please charge and discharge the product once every three months (discharge to 0% first, then fully charge, and discharge to 60%) for long-term storage.
