SPECIFICATIONS/f±}f£
'A/D Conversion .
) D/A Conversion .
) Sampling Frequency •
) Program Memory.
)Frequency Response -
) Nominal Input Level -
) Input Impedance.
)Nominal Output Level
) Output Impedance ••••
) Dynamic Range .
) Controls.
'Display
'Indicator.
'Connectors
'Power Supply
'Current Draw
'Dimensions ••
) Weight .
Accessories
: 18 bit 128 times Oversampling A I Modulation
: 18 bit 16 times Oversampling A I Modulation
:44.1kHz
: 256: 128(User) + 128(Preset)
: 5 Hz to 55 kHz -1/+0 dB (Direct)
12 Hz to 20 kHz -1/+0 dB (Effect)
: +4/-20 dBm (Selectable with LEVEL Switch)
: 400 kQ
: +4/-20 dBm (Selectable with LEVEL Switch)
: 3.6 kQ or less
: 105 dB or greater (IHF-A, LEVEL Switch: +4 dBm) (Direct)
95 dB or greater (IHF-A, LEVEL Switch: +4 dBm) (Effect)
: <Front>
INPUT LEVEL Knob, OUTPUT LEVEL Knob, NUMBER/^LUE Knob,POWER Switch,
EFFECT PARAMETER Buttons(EQ, MOD, DELAY, REVERB, RSS),COMMON Button,
LEVEL Button, NAME Button, EXIT Button, WRITE ButtomfARAMETER Button L/R,
BYPASS Button, UTILITY Button
< Rear> Level Button
: 16 characters, 2 lines (backlit LCD)
: PEAK Indicator
: <Rear>
INPUT Jack L(MONO)/R, OUTPUT Jack
CONTROL Jack, MIDI Connectors(l/
: AC 14V; Supply AC Adaptor
(BOSS BRC-100, 120, 230, 2
: 700 mA
: 482 (W) x 197 (D) x 44 (H) mm
19 (7-3/4) (D) x 1 -3/4, (H)inch
(E1A-1U rack mount type)
: 2.0 kg / 4 lbs 7 oz (excluding the'AC Adaptor)
: Owner's Manual Japanese (70674667)
Biglish (70783723)
BRC-100 (100V) (00899078)
BRC-120 (120V) (00899089)
BRC-230 (230V) (00899090)
FS-5U, FS-5L
EV-5 (Roland),
FV-300L + PCS-33 (Roland)
, BYPASS Jack, Expression Pedal Jack,
. THRU),AC ADAPTOR Jack
AC Adaptor
