Anti-Tip Block

To reduce the risk of tipping over the microwave drawer and
causing serious injury, the anti-tip block must be properly
installed. The anti-tip block must be installed 14-13/16" above
the area where the microwave drawer will sit. When installed to
the wall, make sure the screws completely penetrate the dry wall
and are fully secured in either wood or metal so that the anti-tip
block is completely stable.
NOTE: If the microwave drawer is ever moved to a different
location, the anti-tip block must also be moved and
reinstalled with it.
When fastening the anti-tip block, make sure the screws do not

Electrical Outlet

The electrical requirements are a 120V 60Hz, AC only, 15 ampere
or more protected electrical supply. It is recommeded that a
separate ciricuit serving only this appliance be provided. The
drawer is equipped with a 3-prong grounding plug, and it must
be plugged into a wall receptacle that is properly installed and
grounded. Should you only have a 2-prong outlet, it is your
responsibility to install a correct wall receptacle.
The microwave drawer can also be installed using an electrical
outlet in an adjacent cabinet within the area where the provided
electrical cord can reach. Always check electrical codes for
requirements.
NOTE: Do not use extension cords or adapter plugs with this
appliance.
accordance with all applicable codes and standards. Turn off
MWD2401AS Use, Care, and Installation Guide
CAUTION
penetrate electrical wiring or plumbing.
WARNING
Electrical wiring must be done by qualified person(s) in
electrical power at service entrance before wiring.
Installation Instructions
Suggested electrical
outlet location
Anti-tip
block
6"
4"
