- Page 1 Quick Start Guide DANZ Monitoring Fabric Service Node Appliance DCA-DM-SC2 Arista Networks www.arista.com DOC-06723-01...
- Page 2 The trademarks, logos and service marks ("Marks") displayed in this documentation are the property of Arista Networks in the United States and other countries. Use of the Marks are subject to Arista Network Terms of Use Policy, available at www.arista.com/en/terms-of-use. Use of marks belonging to other parties is for informational...
-
Page 3: Table Of Contents
Contents Contents Chapter 1: Overview..................1 1.1 Scope..............................1 1.2 Receiving and Inspecting the Equipment..................1 1.3 Installation Process..........................1 1.4 Safety Information..........................2 1.5 Obtaining Technical Assistance......................2 1.6 Specifications............................. 3 Chapter 2: Setup Preparation................ 7 2.1 Site Selection.............................7 2.2 Tools and Parts Required for Installation..................7 2.3 Receiving and Inspecting the Equipment..................8 2.4 Electrostatic Discharge (ESD) Precautions..................8 2.5 Setting up Your System........................ - Page 4 Appendix C: Parts List................. 28 Appendix D: Front View of the System............29 D.1 Front Panel Features........................29 Appendix E: Rear Panel Features............... 31 Appendix F: RoHS Declaration Statements..........32...
-
Page 5: Chapter 1: Overview
Chapter 1 Overview This guide is intended for network professionals who need to install the DMF Service Node Appliance. The following topics are covered in this section: • Scope • Receiving and Inspecting the Equipment • Installation Process • Safety Information •... -
Page 6: Safety Information
N’ouvrez PAS le boîtier du routeur. Il n’y a AUCUNE pièce réparable par l’utilisateur à l’intérieur. Confiez toute réparation à un technicien qualifié. Obtaining Technical Assistance All customers, partners, resellers, or distributors holding a valid Arista Service Contract can obtain technical support in any of the following ways: •... -
Page 7: Specifications
Overview Specifications The following Appliance Specifications table lists the specifications of the Arista DCA-DM-SC2 DMF Service Node Appliance. Figure 1-1: System Dimensions System Dimensions 482.0 mm (18.97 inches) 434.0 mm (17.08 inches) 42.8 mm (1.68 inches) 35.84 mm (1.41 inches) (with bezel) 22 mm (0.87 inches) (without bezel) - Page 8 Table 1: Weight Specifications The table below shows the unit weight specifications with all drives/SSDs installed. Weight Maximum weight (with all drives/ SSDs) 4 x 3.5-inch system 18.62 kg 4 x 3.5-inch system 18.62 kg (41.05 pound) (41.05 pound) 8 x 2.5-inch system 16.58 kg 8 x 2.5-inch system 16.58 kg (36.55 pound) (36.55 pound)
- Page 9 Overview Table 5: Maximum Vibration Specifications The table below shows the maximum vibration specifications during operations and storage. Maximum Vibration Specifications Operating 0.26G at 5Hz to 350Hz (x, y, and z axes) Storage 1.88 G at 10 Hz to 500 Hz for 15 min (all six sides tested).
- Page 10 105 W/4C, 115 W/6C, 130 W/8C, 140 W/14C or higher wattage processors (TDP>140 W) are not supported. • Redundant power supply configuration is required. • Non-Arista qualified peripheral cards and/or peripheral cards greater than 25 W are not supported. • NVMe drives are not supported. • Apache Pass DIMM and NVDIMM are not supported.
-
Page 11: Chapter 2: Setup Preparation
The following criteria should be considered when selecting a site to install the appliance: • Before you begin, review the safety instructions located at https://www.arista.com/en/support/product- documentation. • Begin installing the rails in the allotted space that is closest to the bottom of the rack enclosure. -
Page 12: Receiving And Inspecting The Equipment
The accessory kit should include screws for attaching the appliance into an equipment rack. When installing the appliance to an equipment rack with unthreaded post holes, nuts and bolts are also required to secure the appliance to the rack posts. Receiving and Inspecting the Equipment Upon receiving the appliance, inspect the shipping boxes and record any external damage. -
Page 13: Front Bezel
Setup Preparation • #1 and #2 Phillips screwdriver. • Wrist grounding strap connected to ground. • Rack mount kit instructions located in the shipping box. Before Working Inside your System Follow these safety guidelines: Refer to Safety Informationfor more information. 1. -
Page 14: Rear Panel Ethernet Connections
Figure 2-2: Locating MAC Address of your System Information tag (front view) 4 iDRAC MAC address and iDRAC secure password label Information tag Service Tag (back view) Open Manage Mobile (OMM) label 2.6.3 Rear Panel Ethernet Connections On the back panel of the DMF Service Node Appliance, locate the Ethernet Integrated 10/100/1000 Mbps NIC connectors. -
Page 15: Manual Ip Address Setup
Setup Preparation 2.7.1 Manual IP Address Setup Note: Direct IP Address Setup requires a terminal connected to the VGA port of the appliance. Refer to Setting Up and Using iDRAC in the DMF Deployment Guide. -
Page 16: Chapter 3: Dmf Service Node Appliance Access
Chapter 3 DMF Service Node Appliance Access iDRAC iDRAC is a GUI based IPMI running on a separate out of band CPU used for monitoring the hardware appliance. • Web Access into iDRAC (System IPMI) • Changing the iDRAC Password 3.1.1 Web Access into iDRAC (System IPMI) iDRAC is supported on the following browsers:... -
Page 17: Changing The Idrac Password
DMF Service Node Appliance Access Login using the default username and password, which are: • Username: root • Password: <password on the Service Tag> Note: Both the username and password are case sensitive. 3.1.2 Changing the iDRAC Password The following options are available to change the iDRAC password: •... - Page 18 2. Under "iDRAC Settings", go to User. Expand the Local Users and select the user for which the password is to be changed. Figure 3-3: iDRAC Settings Page 3. Click the User ID number of the root account to select it.
- Page 19 DMF Service Node Appliance Access 4. Click Edit. The page appears, showing options for changing password for root user. Figure 3-4: Changing the Password 5. Enter the new password in the Password and click Confirm Password. 6. Click Save to apply the password change.
-
Page 20: Chapter 4: Application Setup
Chapter 4 Application Setup Setting Up DMF Service Node Pre-installation Checklist Ensure that installation prerequisite has been satisfied as mentioned in the DMF Installation Prerequisites section of the DMF Deployment Guide. 4.1.1 Setup Steps for DMF Service Node To set up DMF service node, please refer to Service Node Setup and Initial Configuration section of the Deployment Guide. -
Page 21: Appendix A: Series Status Indicators
Appendix A Series Status Indicators This section contains the following topics: • LCD Panel Features • Status LED Indicators • NIC Indicator Codes • Power Supply Unit Indicator Codes LCD Panel Features The system's LCD panel provides system information and status and error messages to indicate if the system is operating correctly or if the system needs attention. -
Page 22: Status Led Indicators
Status LED Indicators Note: The indicators display solid amber if any error occurs. Figure A-2: LCD Panel Features... - Page 23 Series Status Indicators Table 12: Status LED Indicators and Descriptions Item 1 is the health indicator that indicates the health status of the system. The indicator turns solid blue if the system is turned on and in good health. The indicator flashes amber if the system is turned on or in standby, and if any issue occurs (for example, a failed fan or drive).
-
Page 24: Idrac Direct Led Indicator Codes
Icon Description Condition Corrective Action PCIe Indicator The indicator turns Restart the system. Update any solid amber if a PCIe required drivers for the PCIe card. card experiences an Reinstall the card. error. A.2.1 iDRAC Direct LED Indicator Codes The iDRAC Direct LED indicator lights up to indicate that the port is connected and is being used as a part of the iDRAC subsystem. -
Page 25: Nic Indicator Codes
Series Status Indicators Table 14: iDRAC Quick Sync 2 Indicators and Descriptions This table describes the Quick Sync status indicators. The indicator statuses are Off, which is the default state, Solid white, blinks white rapidly, blinks white slowly, blinks white five times rapidly and then turns off, solid amber, and blinking amber. -
Page 26: Power Supply Unit Indicator Codes
Link LED Indicator Activity LED indicator Table 15: NIC Indicator Codes The NIC indicators table describes different NIC indicator codes and conditions of the connectivity. Status Condition Link and activity indicators are off. The NIC is not connected to the network. Link indicator is green, and the activity The NIC is connected to a valid network at its indicator is blinking green. - Page 27 Series Status Indicators Table 16: AC PSU Status Indicator Codes This table describes the AC PSU status indicators and what condition is the PSU when the power indicator light is green, blinking green, blinking amber, and when it is not illuminated. Power Indicator Codes Condition Green...
-
Page 28: Appendix B: Rack Installation
Appendix B Rack Installation This section includes the following topics: • Rack Installation • Two-Post Rack Mount Parts Rack Installation Use the following steps to assemble the racking rails and attach the components to the system. 1. Identifying the Rail Kit Contents. Locate the components for installing the rail kit assembly: •... - Page 29 Rack Installation 3. Installing and Removing Tooled Rails (Threaded Hole Racks). a. Remove the pins from the front and rear mounting brackets using a flat-tipped screwdriver (1). b. Pull and rotate the rail latch sub-assemblies to remove them from the mounting brackets (2). c.
- Page 30 5. Removing the System From the Rack. a. Locate the lock levers on the sides of the inner rails (1). b. Unlock each lever by rotating it up to its release position (2). c. Grasp the sides of the system firmly and pull it forward until the rail standoffs are at the front of the J- slots.
-
Page 31: Two-Post Rack Mount Parts
Rack Installation Two-Post Rack Mount Parts The two-post rack mount kit includes: • Two sliding rail assemblies. • Two hook and loop straps. Figure B-1: Two-Post Rack Mount Parts... -
Page 32: Appendix C: Parts List
Appendix C Parts List This section lists the default and optional installation parts available in the accessory kit. Each appliance comes with an accessory kit that contains necessary parts that are required to install the appliance. Four-post Rack Mount The following accessories are available along with the appliance: Figure C-1: Four-post Rack Mount Kit Parts 2U Rail slide Screws (for fixing rack plugs to rail rod and rail slide) -
Page 33: Appendix D: Front View Of The System
Front View of the System Please refer to the DMF Service Node Specification section in the DMF Hardware Guide document available at arista.com. Front Panel Features This front view displays the features available on the front panel of the DMF Service Node Appliance. - Page 34 System Identification The identification buttons on the front and back panels Button / Indicator can be used to locate a particular system within a rack. When one of these buttons is pressed, the system status indicator on the back flashes until one of the buttons is pressed again.
-
Page 35: Appendix E: Rear Panel Features
Appendix E Rear Panel Features This section displays the rear panel of the DMF Service Node Appliance. Figure E-1: DMF Service Node Rear Panel Ethernet Connector Integrated 1000/10000 Mbps NIC connector. Inband Ethernet Connector port 1(10-GbE SFP+Service interfaces SNI1, SNI2, SNI3 &... -
Page 36: Appendix F: Rohs Declaration Statements
Appendix F RoHS Declaration Statements For Taiwan BSMI RoHS Table, go to https://www.arista.com/assets/data/pdf/AristaBSMIRoHS.pdf.
