Alvey 82WGVC2 Instructions For Use

82WGVC2 PARTS LIST
Part No Part Description
D2A-MW Stainless Steel Base Clamp
D3A-BCV Stainless Steel Guide Assembly
D4F-RM Handle Assembly
R5B5 Ratchet Wheel
R5C7 Drag Lever & Activator
R5E10 Ratchet Button & Spring
R5G3 Silent Drag Pawl Spring Light
R5K1 ON/OFF Cam
R6A18 Spindle
R6C5 Spindle Spring
R6D2 Spindle D Washer
R6E4 Spindle Screw
R6F3 Dome Hex Nut
R6J7 Spindle Washer
R6P2 Nitrile Washer Spindle Screw
R7A4 Drag Friction Tube
R7B/C15 Drag Clutch Washer Set 82
R7D5 Drag Star Adjusting Nut
D7E-MW Drag Handle Plate
R7F2 Drag Handle Plate Lock Nut
R7J4 Silent Drag Pawl
R7L1 Silent Drag Cam
R7M7 Drag Pawl Post 825
82WGVC2
CONGRATULATIONS and thank you for purchasing one of our new winches as
your choice of fishing reel. These reels are constructed from the highest
quality materials to ensure your reel will last for many years.
Plus, all these other
advantages -
Special Features
High speed recovery:
→ Heavy Duty
Offset handle plate allows for
extra fast retrieve on unbaited
rig. Allows you to rebait and be
back fishing in a flash. → Vented Back
Control large fish with ease:
→ Belleville Power
Powerful one-to-one direct wind
means you only need about a
quarter of the effort required to
lift a similar weight on a spinning
→ On/Off Drag
reel.
You can fish harder and
longer: Simple, rugged
→ Vented Fibreglass
construction means you can
forget that fiddly maintenance,
because your Alvey reel will
resist the effects of salt water
and sand
Reel Icon Pty Ltd Trading as
Alvey Reels Australia ABN 57 625 261 707
2-6 Antimony Street Carole Park Qld 4300
t: +61 7 3271 2844 f: +61 7 3271 2451
Fixed G clamp:
Stainless steel clamp will fit
rails up to 50mm diameter.
Alvey 5 Year Guarantee:
Any faulty Alvey part or reel
Handle Plate
will be replaced at no
charge providing
manufacturer finds the part
or reel has had normal
usage and attention.
Washer and
Multi-plate Clutch
Switch
Alvey 10 Year Guarantee:
Any faulty Alvey part or reel
Spool
will be replaced at no
charge providing
manufacturer finds the part
or reel has had normal
usage and attention.
For more hints and tips on maintenance,
please visit the spare parts page at
www.alvey.com.au
