- Page 1 Fingerprint Reader INSTALLATION MANUAL...
- Page 2 Step 1: Connection - Remove the BFR from its packaging and connect it to the control panel’s reader port and to the LAN as shown in Fig 1. Page 2 of 11 RBH Access Technologies Inc. BFR Installation Manual...
- Page 3 Step 2: Configuring IP – There is two methods to configuring the IP address for the BFR-XXX fingerprint reader. You can use “IP Locator” and /or “the built in Web page”. Method 1: IP Locator - On the AxiomV™ or Integra32 CD in the Communication folder, locate the IP Locator program and run it.
- Page 4 Method 2: Built in Web Page – Change your computer’s IP address to be in the acceptable range of the BFR-XXX’s default IP [192.168.0.66]. In your web browser enter the Default address of the BFR-XXX and the following box will appear. Enter User name “RBH”...
- Page 5 Select the Communication Settings to go to the IP configuration page. Edit the IP settings and click on SAVE. Note: Always use STATIC IP for Type and TCP SERVER for Connection Mode. Page 5 of 11 RBH Access Technologies Inc. BFR Installation Manual...
- Page 6 Click the SAVE button. Step 3: Configuring Weigand Output – You can either select one of the predefined weigand formats or configure a customize format. To select one of the predefined formats, click on Weigand Setup, and select the required format in both the fields as shown below and click on SET.
- Page 7 For a customize format, first need to configure the format in Weigand Format window. Put in all the format information as shown below and click on SET. Page 7 of 11 RBH Access Technologies Inc. BFR Installation Manual...
- Page 8 The new format configured will now show in the list of formats in Weigand Setup window. Select the format and click on SET. Page 8 of 11 RBH Access Technologies Inc. BFR Installation Manual...
-
Page 9: Firmware Upgrade
Firmware Upgrade If Firmware upgrade is required on BFR fingerprint unit, click on Upgrade Firmware on the web browser page. Page 9 of 11 BFR Installation Manual RBH Access Technologies Inc. - Page 10 Browse the upgrade file/files provided, (You may need to upgrade the Firmware on unit as well as Web browser) and click on UPGRADE. Page 10 of 11 RBH Access Technologies Inc. BFR Installation Manual...
- Page 11 For integration with AxiomV™ or Integra32™ see TB65_BFRQuickConfigGuide on the CD. Page 11 of 11 RBH Access Technologies Inc. BFR Installation Manual...
