  • Page 1 AIO4045 USER’S MANUAL TABLE OF CONTENTS...

  • Page 2: Table Of Contents

    CHAPTER 1 MOTHERBOARD..........1 1.1 SYSTEM FEATURES..............1 1.2 SYSTEM SPECIFICATIONS...........1 1.3 AIO4045 BOARD LAYOUT............2 1.4 DRAM INSTALLATION............3 1.5 SRAM INSTALLATION............4 1.6 CPU INSTALLATION.............5 1.7 AWARD BIOS SYSTEM CONFIGURATION SETUP..10 1.8 ALTERNATIVE SYSTEM SPEED........14 CHAPTER 2 IDE...............15 2.1 SOFTWARE INSTALLATION..........16 - DOS DRIVER..............16 - WINDOWS 3.1 DRIVER.............18...

  • Page 3: Chapter 1 Motherboard

    AIO4045 User’s Manual CHAPTER 1 MOTHERBOARD 1.1 System Features q Support INTEL 486SX, 486DX, 486DX2, P24T, P24D, S-SERIAL. AMD 486DX, 486DX2. Cyrix M6, M7. q Support L1 write back CPU. 1.2 System Specifications CPU Clock : 25/ 33/ 40 MHz...

  • Page 4: Aio4045 Board Layout

    1.3 AIO4045 Board Layout PARALLEL COM2 W83757F W83758F JP66 JP73,JP69-JP67 JP54 JP61 BIOS JP60 W89C904AXF W83C492F ALG2228 W83C759F JP17 JP37 JP36 JP35 486 CPU JP52 JP32 W83C491F JP29 6 JP1 JP30, JP31 SIM4 JP1-...

  • Page 5: Dram Installation

    AIO4045 User’s Manual 1.4 DRAM INSTALLATION The AIO4045 main board can support expanded memory from 1MB to 128MB. Either 1MB, 2MB, 4MB, 8MB, 12MB, 16MB, 24MB, 32MB, 64MB, 128MB SIM DRAM can be used on the AIO4045 motherboard. n The board layout below shows the locations of the DRAM memory...

  • Page 6: Sram Installation

    1.5 SRAM INSTALLATION JP36 JP35 486 CPU W83C491F CACHE CONFIGURATION SIZE 128K 256K 512K TAG RAM DATA RAM TAG RAM DATA RAM TAG RAM DATA RAM (U13) (U9,U10,U14,U (U13) (U9,U10,U14, (U13) (U9,U10,U14,U U15) 8K*8 32K*8 32K*8 64K*8 32K*8 128K*8 JP35 JP35 JP35 JP34...
  • Page 7 AIO4045 User’s Manual JP37 486 CPU JP32 W83C491F 6 JP1 JP1-JP3 CPU CLOCK 20 MHz 25 MHz 33 MHz 40 MHz JP1, JP2, JP3 JP1, JP2, JP3 JP1, JP2, JP3 JP1, JP2, JP3 J1: POWER LED & K/B LOCK J2: SPEAKER (3-4 SHORT)
  • Page 8 486SX JP14 486DX/DX2 JP14 JP37 JP16 8 7 6 JP32 JP44 P24D JP14 JP37 JP26 JP16 JP28 JP29 JP32 JP44 P24T JP32 JP14 JP28 JP29 JP44 JP16 JP26...
  • Page 9 AIO4045 User’s Manual 486DX/DX2 JP14 JP37 enhance JP44 JP16 JP59 JP32 JP28...
  • Page 10 · CYRIX CPU TYPE SELECT JP14 JP32 JP37 JP44 JP16 JP59 JP61 JP28 JP29 JP14 JP32 JP37 JP44 JP16 JP59 JP61 JP28 JP29...
  • Page 11 AIO4045 User’s Manual CPU POWER VOLTAGE 3.3V FOR DX4 5V FOR NORMAL JP17 JP31 JP17 OTHER JUMPER DESCRIPTION JUMPER DESCRIPTION JP45 SUSPEND RESUME JP66 CMOS CLEAR...
  • Page 12 CONNECTOR DESCRIPTION CONNECTOR PIN OUT SIGNAL NAME J1: KEY LOCK LED POWER NOT USED GROUND KEYBOARD INHIBITOR GROUND J3: TURBO/SW GROUND SELECT PIN TURBO SPEED NORMAL SPEED J4: LED +ANODE -CATHODE J5: RESET GROUND RESET IN KB: KEYBOARD KEYBOARD CLOCK KEYBOARD DATA CONNECTOR SPACE...

  • Page 13: Award Bios System Configuration Setup

    AIO4045 User’s Manual 1.7 AWARD BIOS SYSTEM CONFIGURATION SETUP...
  • Page 14 This section will explain how to set up the system configuration (CMOS) under the AWARD BIOS. The SETUP program is contained in the system's Read-Only-Memory rather than on a diskette. To enter SETUP, press the <Del> key when the system is booting up. The following menu appears: Please enter "...
  • Page 15 AIO4045 User’s Manual ROM ISA BIOS (2C4J6000) CMOS SETUP UTILITY AWARD SOFTWARE,INC. STANDARD CMOS SETUP PASSWORD SETTING IDE HDD AUTO DETECTION BIOS FEATURES SETUP SAVE & EXIT SETUP CHIPSET FEATURES SETUP EXIT WITHOUT SAVING POWER MANAGEMENT SETUP LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ¯®¬...
  • Page 16 ROM ISA BIOS (2C4J6000) CMOS SETUP UTILITY AWARD SOFTWARE,INC. STANDARD CMOS SETUP PASSWORD SETTING BIOS FEATURES SETUP IDE HDD AUTO DETECTION SAVE & EXIT SETUP CHIPSET FEATURES SETUP EXIT WITHOUT SAVING POWER MANAGEMENT SETUP LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ¯®¬...
  • Page 17 AIO4045 User’s Manual ROM ISA BIOS (2C4J6000) CMOS SETUP UTILITY AWARD SOFTWARE,INC. STANDARD CMOS SETUP PASSWORD SETTING BIOS FEATURES SETUP IDE HDD AUTO DETECTION CHIPSET FEATURES SETUP SAVE & EXIT SETUP EXIT WITHOUT SAVING POWER MANAGEMENT SETUP LOAD BIOS DEFAULTS...
  • Page 18 IRQ 6&7 as Wakeup Event ¯®¬ : Select Item Floppy Disk activity detect : Enable Esc : Quit Keyboard activity detect : Enable F1 : Help PU/PD/+/- : Serial Port activity detect : Disable Modify Parallel Port activity detect : Disable F5 : Old Values (Shift) F2 : Color VL Bus activity detect...
  • Page 19 AIO4045 User’s Manual ROM ISA BIOS (2C4J6000) CMOS SETUP UTILITY AWARD SOFTWARE,INC STANDARD CMOS SETUP PASSWORD SETTING BIOS FEATURES SETUP IDE HDD AUTO DETECTION CHIPSET FEATURES SETUP SAVE & EXIT SETUP POWER MANAGEMENT SETUP EXIT WITHOUT SAVING LOAD BIOS DEFAULTS...

  • Page 20: Alternative System Speed

    1.8 ALTERNATIVE SYSTEM SPEED After booting the system, hold down <Ctrl> and <Alt> keys, then press <-> to select low-speed, press <+> to select high-speed. Please review the following configuration : CPU SPEED NORMAL Þ TURBO HOLD DOWN <Ctrl> AND <Alt> KEYS, PRESS <+> CPU SPEED TURBO Þ...

  • Page 21: Software Installation

    AIO4045 User’s Manual CPU SPEED >33MHz <=33MH (JP53) HDD MODE MODE1 MODE0 (JP53) MODE2 MODE3 I/OCHECK READY DISABL ENABLE (JP52) 2.1 SPECIFICATIONS q Compatible with HOST VESA bus standard q I/O address 1F0 to 1F7 q Floppy Disk Controller l Support up to two 3.5” or 5.25” floppy disk drives l 360K/720K/1.2M/1.44M...
  • Page 22 WBIDE.EXE [Options] (A) The WBIDE.EXE is two in one exceptional program: A DOS Device Driver and a Configuration Utility. 1) A Device Driver on DOS. To edit the line - DEVICE=[d:\path\]WBIDE.EXE [/S] [/L] [/C] into the CONFIG.SYS file, and reboot the DOS. [Note]: The WBIDE.EXE driver will detect automatically the IDE disk configuration data : Xfer-bit &...

  • Page 23: Windows 3.1 Driver

    AIO4045 User’s Manual (B) Functional Description: 1) WBIDE DOS Device Driver supports up to four IDE disks. They are 1FXH I/O port address and 17XH I/O port address. The IDE disks, where are attached into 17XH port connector, do not specify CYL/HD/SECT parameters in ROM BIOS SETUP.

  • Page 24: Netware Driver

    You should install Windows 3.1 first. And then execute SETUP.EXE in subdirectory WINDRV on DOS prompt, it will install Windows 3.1 driver WIDE310.386 automatically. -OR- You can refer README.TXT in subdirectory WINDRV to install Windows 3.1 driver WIDE310.386 by yourself. [NOTE] Before you execute Windows 3.1 with WIDE310.386 Driver, the DOS device driver - WBIDE.EXE must be run...

  • Page 25: Chapter 3 Vga

    AIO4045 User’s Manual 4. OS/2 Refer to the OS2IDE2X.DOC in OS2 subdirectory for OS2 driver installation CHAPTER 3 VGA Trademarks AutoCAD and AutoShade are trademarks of Autodesk Inc. Ò , OS/2, VGA and PS/2 are trademarks of International Business Machines Corporation.

  • Page 26: Introduction

    3.1 INTRODUCTION AIO-4045 is an all purpose single-chip graphics controller based adapter which excels in GUI, CAD and DOS application environments. It delivers high speed, high resolution display with true color support at 16.7 million colors. It is a cost effective and ideal graphics solution for desktop PC users.
  • Page 27 AIO4045 User’s Manual Full 32-bit , GUI Acceleration. Green PC support, VESA DPMS Power Saving. 24-bit DAC included ( Support 16.7M True Colors ). Displays up to 1280´1024 resolution at 16 colors. JP57: IRQ9 Enable Disable (default) 3.3 SOFTWARE DRIVERS...
  • Page 28 INSTALL program will automatically copy all available AIO-4045 utility programs into the specified drive path. 1. Using VMODE.EXE VMODE is a menu-driven program to help you select the AIO-4045 video modes which are available for display. With a few simple keystrokes, you can switch the display into one of the many extended high resolution modes listed.
  • Page 29 AIO4045 User’s Manual Windows with the option of another VGA card, do the following steps to re-configure MS Windows to support the AIO-4045 VGA. Enter MS Windows directory and run MS Windows SETUP program by typing "SETUP". A display with the current settings will appear on the screen. Use the arrow key to highlight the Display Settings and press [Enter].
  • Page 30 Note: It is necessary to restart Windows if you select a different display resolution than the one you are currently using. 10 Should you select a different display resolution in the future, simply select the new resolution by double-clicking on the Avance Logic logo icon and restart Windows.
  • Page 31 AIO4045 User’s Manual Steps 1-4 are required only for the first time installation of Avance Logic drivers. On subsequent installation of drivers you may skip the steps 1-4. On OS/2 window (under Command Prompt) run DSPINSTL. Select “Primary Display” and click “OK”.
  • Page 32 NOTE Please note that the volume label of “Display Driver Diskette” is “DISP 1”. If you make copies of this disk, make sure you give correct volume label. (Use DOS command “LABEL” to change the volume label of a disk.) Close all Windows Seamless and FullScreen applications before you use DSPINSTL.
  • Page 33 AIO4045 User’s Manual Once you have successfully installed Avance Logic Inc. SVGA drivers, you can easily change Video Refresh rate (without changing screen resolution) by performing steps 5 thru 9. Select “CANCEL” when prompted at step 10 and onward still you exit from DSPINSTL. Do system shutdown immediately.
  • Page 34 4. Windows NT Enter Windows NT. Select Windows NT SETUP, click on the option "Change System Settings". Go to the option "Display" and select "Others". Insert ALG 2228 windows NT drivers disk into A drive. Select the display resolution of your choice then reboot your system.
  • Page 35 AIO4045 User’s Manual Insert the ALG2228 driver disk 2 and type "Install". Select "AutoCAD/R11". Start ACAD. Select option 5, "Configure AutoCAD from the Main Menu". Select Option 3, "Configure Video Display and select device number. For Example, "ADI P386 v4.0/4.1 display".
  • Page 36 Select "Avance VGA P386 ADI V4.2 32-bit Display List, by Avance Logic". Select the display resolution you desire. Follow the directions provided by the ACAD program to complete the configuration. Save new changes and you have completed the installation. 8. VersaCAD/5.X The AIO-4045 VGA supports the following high resolution software drivers for VersaCAD/5.X: AC16.COM for 16-color modes, and...
  • Page 37 AIO4045 User’s Manual Select the option for Driver Installation and select the option for VersaCAD. Provide the correct drive path for the VersaCAD directory and press [Enter]. The INSTALL program will automatically copy all available driver files into the specified directory.
  • Page 38 Setting Proper ADI Environment for AutoCAD Protected Mode Display List Drivers To allow successful installation, first you will need to setup your ADI environment properly by using the following steps: Insert the AIO-4045 Driver Disk 2 into your floppy drive A. At the DOS prompt, simply type: A:\INSTALL [Enter]...
  • Page 39 AIO4045 User’s Manual RCPVGA41.EXP (w/o Display List) DSPEGA41.EXP (with Display List) SDSP.EXP (Display List with Linear Address) Reboot your system to activate the new AUTOEXEC.BAT file. NOTE! Do not install Display List with Linear Address driver(SDSP.EXP) if you have a system which contains 16 MB of the memory. Due to the limitation on the ADI4.1 and AT bus, installing SDSP.EXP...
  • Page 40 Select pointing device: 1. Autodesk Device Interface pointer. 2. P386 Autodesk Device Interface pointer. Pointer selection: Enter the option number to choose the appropriate pointing device. Select the display device driver: Select display device: 1. Autodesk Device Interface display driver. 2.
  • Page 41 AIO4045 User’s Manual procedures under Installing High Resolution Protected Mode ADI Display List Drivers for AutoCAD R11, AutoShade V2.0. NOTE! The dual screen feature will not be supported if you are using the Protected Mode ADI Display List driver. Select display resolution by entering the option number.
  • Page 42 When you are prompted "Does the display and AutoShade rendering devices share a single screen? (default = NO):" When you are prompted with the message "Does the display and Autodesk RenderMan rendering devices share a single screen? (default = NO):" Type Y and press [Enter] 10 When you are prompted "Does FLIP SCREEN require a redraw? (default = NO):"...
  • Page 43 AIO4045 User’s Manual The AIO-4045 VGA Card supports the following high resolution software drivers for CADKEY/3: AC16.EXE for 16-color modes, and 640x480 16-color 800x600 16-color 1024x768 16-color 1280x1024 16-color (1MB DRAM) AC256.EXE for 256-color modes, and 640x480 256-color 800x600 256-color...
  • Page 44 NOTE! Use [Ctrl]-[S] to pause for reading and press [Enter] to continue (You may want to print out the contents of the ALCK3.DAT). Use line editor to append the entire contents of the ALCK3.DAT into the filename "GRDEV.DAT". Inside the CADKEY directory, type "CONFIG" to re-configure ADKEY.
  • Page 45 AIO4045 User’s Manual 12 Again, you will be prompted "Enter the size for the CADKEY graphics marker". Simply press [Enter] again to select the default configuration. 13 Continue with the rest of the installation procedure until you are able to select option (9) "Exit and save changes".
  • Page 46 Provide the correct drive path for the EASYCAD directory and press [Enter]. The INSTALL program will automatically copy all available driver files into the specified directory. Select the driver name with the resolution you would like to display and copy the driver to filename DSDRV.BIN. example, select DSA1024.BIN for your 1024 x 768 display and type "COPY DSA1024.BIN DSDRV.BIN"...
  • Page 47 AIO4045 User’s Manual When the SETUP screen appears, choose option 2, "All other uses of the setup program". Choose option 2 for running Framework III from your hard disk drive. Select option 2 again for CONFIGURATION. Choose option 1 to select the "PRIMARY HARDWARE"...
  • Page 48 11 From the Main Menu, type "7" to save all your settings. 12 Save the new configuration. Choose option "2" for running Framework III from the hard disk drive. Once you have made the choice, strike any key to exit to DOS. i.e.
  • Page 49 AIO4045 User’s Manual Type "Lotus" to open the Lotus Main menu. Select "Install" from the Lotus Main menu. Select "Advanced options" from the Install menu. Select "Add new driver to library" from the Advanced Options menu. Select "Modify current driver set" from the menu.
  • Page 50 Select the option for Driver Installation and select the option for PCAD. Provide the correct drive path for the PCAD directory and press [Enter]. The INSTALL program will automatically copy all available driver files into the specified directory. Available display drivers for PCAD version 4.0. 800x600/16 AP800.DRV 1024x768/16...
  • Page 51 AIO4045 User’s Manual 2 Select the option for Driver Installation and select the option for Ventura Publisher. Provide the correct drive path for the VP directory and press [Enter]. The INSTALL program will automatically copy all available driver files into the specified directory.
  • Page 52 Go to the directory where you have stored WordPerfect or insert the WordPerfect program diskette into floppy drive A if you are using a floppy system and type: WP/S [Enter] Select option 3, "Set Screen and Beep options". Enter the numbers for the column and row to match the one you have selected with the VMODE.EXE program.
  • Page 53 AIO4045 User’s Manual A:\INSTALL [Enter] Select the option for Driver Installation and select the option for WordPerfect/5.0. Provide the correct drive path for the WP50 directory and press [Enter]. The INSTALL program will automatically copy all available driver files into the specified directory.
  • Page 54 Start WordPerfect program by typing "WP". Setup new display by pressing keystroke "SHIFT-F1". Select option "(2) Display". Select new Screen driver. Select option "(2) Graphics Screen Type". Ext. 16 colors - ..- 1024x768 - 1280x1024 (required 1MB) Ext.
  • Page 55 AIO4045 User’s Manual Check your DOS system disk or directory to see if you have the file named "DEBUG.COM" or "DEBUG.EXE". Make a backup copy of the WS.COM file from your WordStar diskette or the WordStar directory on your hard drive, and give it a new filename "WS132.COM".
  • Page 56 Insert the AIO-4045 Driver Disk 1 into your floppy drive A. At the DOS prompt, simply type: A:\INSTALL [Enter] Select the option for Driver Installation and select the option for WordStar 4. Provide the correct drive path for the WS4 directory and press [Enter].
  • Page 57 AIO4045 User’s Manual 12 Run VMODE.EXE to select the extended video mode (be sure that the mode you selected is the same as the one you have chosen earlier in the WordStar configuration). 13 Start WordStar Release 4 by typing:...
  • Page 58 4.1 OVERVIEW The Jumperless LAN, referred to as W89C904AX Series, are designed in one type of boards as described below: INET2000B: Equipped with BNC ports, which allow connecting to thin coaxial cables. Featuring a high data transmission rate of 10 mega bits per second, the Cards conform to the IEEE 802.3 standard protocol.
  • Page 59 AIO4045 User’s Manual ¯ 16 Bit Ethernet adapter. ¯ Novell NE2000 Ethernet AT hardware compatible board. ¯ Compliant with IEEE 802.3 Ethernet Standard. ¯ The board with 10Base-2 BNC Interface. ¯ Supports Netware, TCP/IP, NDIS, ODI and NetBIOS etc. ¯ Supports 16K/64K multi-packet RAM buffer.
  • Page 60 The main menu will appear: Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17 (a) There is 1 Winbond W89C904AX only. I/O base=300h, IRQ=3, IO Mapping. ‘Enter’ key = OK ‘Enter’ key = CANCEL LANSTART is a copy righted s/w by Winbond Elec. Corp, lisence to Winbond Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17 get id number ...
  • Page 61 AIO4045 User’s Manual Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17 Main Functions Configure the W89C904AX Show current configuration of W89C904AX set configuration A set configuraiton B set configuration C write new configuration to EEPROM Update new configuraioin to W89C904AX...
  • Page 62 Configuration B Thick : Thin Ethernet GDLINK : Enable GDLINK EIO16 : Normal IO 16 ECHRDY : Normal IOCHRDY BPWE : Boot PROM Write Enable Press any key to exit..LANSTART is a copy righted s/w by Winbond Elec. Corp, lisence to Winbond ¡¹...
  • Page 63 AIO4045 User’s Manual F1: Help F10: Exit á: up â: down <Enter>: execute <Esc>: End testing LANSTART is a copy righted s/w by Winbond Elec. Corp, lisence to Winbond ¡¹ INT : Interrupt Request (IRQ) Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17...
  • Page 64 F1: Help F10: Exit á: up â: down <Enter>: execute <Esc>: End testing LANSTART is a copy righted s/w by Winbond Elec. Corp, lisence to Winbond Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17 Main Functions Configure the W89C904AX Set Configuration Thin Ethernet Thick...
  • Page 65 AIO4045 User’s Manual F1: Help F10: Exit á: up â: down <Enter>: execute <Esc>: End testing LANSTART is a copy righted s/w by Winbond Elec. Corp, lisence to Winbond Boot ROM Address The “disable” and a list of Boot ROM addresses will be displayed when this option is selected.
  • Page 66 Note: There are no mapping limitations between Boot ROM address and I/O base address. Yet you should be careful not to let the conflict happen between your your Shared RAM address and Boot ROM address: Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17 Main Functions...
  • Page 67 AIO4045 User’s Manual 3. Diagnosing the Card Select the “Diagnose” option in the main menu and press <Enter> to open the “Diagnose”. You are allowed to do the tests from the Diagnose. To perform one of tests, press <Enter> after the option is high-lighted.
  • Page 68 F1: Help F10: Exit á: up â: down <Enter>: execute <Esc>: End testing LANSTART is a copy righted s/w by Winbond Elec. Corp, lisence to Winbond Internal Test: Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17 Main Functions Diagnose Network functional test register read/write test...
  • Page 69 AIO4045 User’s Manual By pressing the <Esc> key allows you to leave the software and return to the Main Menu as the table below: Winbond W89C904AX LANSTART (Setup, Diagnostics and Tx/Rx) Ver 1.17 Main Functions Configure the W89C904AX Diagnostics Transmit/receive p Access physical ad Press “X”...
  • Page 70 Disable video, parity checking, DMA. Reset math coprocessor. Clear all page registers, CMOS shutdown byte. Initialize timer 0, 1, and 2, including set EISA timer to a known state. Initialize DMA Controllers 0 and 1. Initialize interrupt controllers 0 and 1. Initialize EISA extended registers.
  • Page 71 AIO4045 User’s Manual Controller 0 Keyboard detect and initialization. Test DMA Controller 1 Test Page Test DMA Page Registers. Registers 12-13 Reserved Test Timer Test 8254 Timer 0 Counter 2. Counter 2 Test 8259-1 Verify 8259 Channel 1 masked interrupts by alternately Mask Bits turning off and on the interrupt lines.
  • Page 72 Controller Reserved Chipset Initialization Program chipset registers with Setup values. Display virus protest disable or enable. Initialize Floppy Initialize floppy disk drive controller and a drives. Drive & Controller Initialize Hard Initialize hard drive controller and any drives. Drive & Controller Detect &...
  • Page 73 AIO4045 User’s Manual APPENDIX B BEEP CODE During the POST (Power On Self Test) routines, which will be performed each time when the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 74 No. of Beeps 1. Refresh Failure- The memory refresh circuitry of the motherboard is faulty. 2. Parity Error- A parity error was detected in the base memory ( the first block of 64KB ) of the system. 3. Base 64KB Memory Failure- A memory failure occurred within the first 64KB of memory.
  • Page 75 RMA FORM When M/B can't work well, please fill this form to describe related situations. If the space is not enough to use, you can attach separate paper. MODEL: MODEL NO.: HARDWARE: CPU: Brand _____________, Model ___________, Speed _____________ MHz CO-PROCESSOR: Brand___________, Model __________, Speed ________MHz SIMM: Brand________, Speed________ ns, Q'ty _______ pcs, Total ________ MB CACHE: Brand ____________, Speed ___________ns, Total ____________K...
