Summary of Contents for Affordable KCSPM3648

  • Page 1 AFFORDABLE LIFTS       ...
  • Page 2 _____________________________________________________________________________________ Introduction Congratulations on your purchase of a new lift from Affordable Lifts! This lift has been quality engineered with design features to assure safety and reliability when operated properly. We sincerely hope that this lift will help you accomplish the things that are important to you and those you love.

  • Page 3: Warranty Warning

    _____________________________________________________________________________________ SAFETY Safety is paramount. If you have a question or concern about safe installation or operation please give Affordable Lifts a call at (757) 524-3420 Use common sense when installing or operating this equipment. The installer and operator are responsible for the safe operation of this equipment.
  • Page 4 _____________________________________________________________________________________ ORIENTATION Front, Back, Right and Left - The Column is located on the back side of the lift. The side of the lift opposite the back is the front. Right and left are determined when you face the lift from the front. If you have any questions concerning the installation, operation, or maintenance requirements of your lift, please contact our Service Department at (757) 524-3420.
  • Page 5 _____________________________________________________________________________________ ● Prior to use, ensure that electrical power is installed on a grounded electrical circuit. ● Prior to use, inspect for proper function, required maintenance, or damage. If a problem exists, cease use of the lift immediately. Do not attempt to make repairs or alterations to the lift.
  • Page 6 ● Making sure the lift and its installation complies with any applicable regulations and that any lift operators are properly trained. ● Recognizing that Affordable Lifts' delivery technicians will deliver the lift and are not necessarily qualified or licensed to do related electrical, masonry, carpentry or other contractor type work.
  • Page 7 _____________________________________________________________________________________ LIFT COMPONENTS ILLUSTRATION This photo might not exactly match your particular lift. _____________________________________________________________________________________...
  • Page 8 _____________________________________________________________________________________ LIFT COMPONENTS TABLE Base U-Shaped bars that support the entire unit. Platform The platform is the metal, gated enclosure that carries the passenger up and down Gate(s) A removable and reversible gate is attached to each side of the platform. Each gate has a latch. Bridge(s) A bridge is the flat diamond plate metal surface attached to each side of the platform.

  • Page 9: Operating Your Lift

    _____________________________________________________________________________________ OPERATING YOUR LIFT Step 1 Ensure the lift platform is completely level with the floor or landing where you reside. Refer to the Installation Manual to adjust the platform to the Landing height as needed. Only proceed when the platform is completely level to the floor or landing on which you reside.

  • Page 10: Operating Precautions

    _____________________________________________________________________________________ inches (or feet) of slack, and the platform may then fall until the slack is used up or until the anti-fall device engages and stops the platform. Either condition is undesirable. Therefore do the following: 1) Adjust the top three bolts on the back of the platform collar so that they (the bolts and the nuts) may be rotated just with finger pressure.
  • Page 11 Hoist Cable The cable is a critical piece of your lift. Visually inspect it monthly to make sure it is not kinked, frayed or showing signs of wear. If it is, contact Affordable Lifts for assistance. The SRL is important to the safety of your lift. Visually inspect its cable monthly to make sure it is not kinked, frayed or showing signs of wear.
  • Page 12 _____________________________________________________________________________________ AFFORDABLE LIFTS Owner’s Manual © Affordable Lifts 147 Mill Ridge Road, Suite 232 Lynchburg, Virginia 24502 Phone (757) 524-3420 www.AffordableLifts.com _____________________________________________________________________________________...
