Summary of Contents for Camec 053574
- Page 1 BUILT-IN INDUCTION COOKTOP Installation, Operation and Maintenance Instructions Dual Cooking Zones 2,300W Dual Cooking Zones 3,300W Part No. 053574 Part No. 053575 NOTE: Please read this manual carefully before installing and using this appliance. Version 1.0...
-
Page 2: Table Of Contents
CONTENTS General Safety Instructions Safety Warnings Installation Technical Data and Specification Operating Use Maintenance and Cleaning Servicing Warranty Version 1.0... -
Page 3: General Safety Instructions
1. General Safety Instructions Induction cooktop requires the use of cookware made of ferromagnetic material, which reduces cooking food time. This appliance is designed for household, non-professional use in recreational vehicles i.e. caravans, camper trailers, motorhomes etc. Any other use shall be considered improper. - Page 4 WARNING: DO NOT place any combustible material, heavy objects or products on this appliance at any time. WARNING: DO NOT place any metallic objects such as knives, forks, spoons and lids on the cooktop surface since they can get hot. WARNING: DO NOT use your appliance as a work or storage surface.
- Page 5 WARNING: DO NOT use pans with jagged edges or drag pans across the ceramic glass surface as this can scratch the glass. WARNING: DO NOT leave any protective film that may be on the induction hob. WARNING: DO NOT use your appliance for warming or heating the room.
- Page 6 WARNING: DO NOT repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician. WARNING: DO NOT use steam cleaner; scourers or any other harsh abrasive cleaning agents to clean the cooktop, as these can scratch the ceramic glass.
-
Page 7: Installation
3. Installation All installations must be carried out by authorized trades persons only in accordance with these instructions, relevant Federal and State Regulations. Installation Location Do not install directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the electronic components. - Page 8 A (mm) B (mm) C (mm) Min: 50 Min: 30 Air intake Air exit 10mm Built-in Cut Out Dimensions Check to ensure the thickness of the work surface is at least 30mm. A minimum of 50mm space shall be preserved around the cut out, for ...
- Page 9 Electrical Connection Before connecting the induction cooktop to the mains, check the following: The electrical installation where the induction hob is to be connected must be suitable for the power consumed by the induction cooktop. The voltage must correspond to the nominal value specified in the ...
-
Page 10: Technical Data And Specification
The manufacturer is not responsible for any accident resulting from the use of an appliance that is not grounded or from faulty grounding continuity. 4. Technical Data and Specifications Dual Cooking Zones 2,300W (Part No. 053574) Position Description Induction Cooking Zone 1 Max. - Page 11 Down button Up button Timer button Lock button On/Off button Dual Cooking Zones 3,300W (Part No. 053575) Position Description Induction Cooking Zone 1 Max. 1500W Induction Cooking Zone 2 Max. 1800W Glass plate Control panel Down button for Zone 1 Version 1.0...
-
Page 12: Operating Use
Up button for Timer Down button for Zone 2 Up button for Zone 2 Child lock button On/Off button Specifications Part No. 053574 Part No. 053575 Voltage 220-240V ~ 50-60Hz 220-240V ~ 50-60Hz Max Power 2,300W 3,300W Net Weight 4.2KG 4.2KG... - Page 13 You will hear a beep each time a touch is registered. Ensure the touch buttons are always clean, dry, and there is no object (e.g. a utensil or a cloth) covering them. Note: Even a thin film of water may make the touch control buttons difficult to operate.
- Page 14 Choosing the right cookware Do not use cookware with jagged edges or a curved base. Make sure the base of the pan is smooth, lies flat against the glass, and is the same size as the cooking zone. Use cookware whose diameter is as large as the graphic for the ...
- Page 15 Cookware empty or with a very thin base Never place an empty cookware on the cooktop and turn it on, as this can cause the cookware to overheat (due to excess heat) and damage the ceramic glass or the cooktop. If the base of the cookware is very thin, it can also become overheated, ...
- Page 16 To start cooking Touch the “ON/OFF ” button. When the cooktop is turned on, an acoustic warning will sound and the displays will show the indications "0" and "- -", warning that the cooktop is ON and in the standby state. Place a suitable pot on the cooking ...
- Page 17 When you have finished cooking Touch the heating zone selection button that you wish to turn off. Note: This applies to 2.3kW model only. Turn the cooking zone off by touching the “-” and scrolling down to “0”. Make sure the power display shows “0”, then shows “H”.
- Page 18 To lock the buttons Touch the key lock button “ ” To unlock the buttons Make sure the induction cooker is on. Touch and hold the key lock button “ ” for 3 seconds. You can now start using your cooker. ...
- Page 19 At the base of the cooktop, a fan is used to maintain a stable temperature inside the induction cooktop. Every time the cooktop is turned on and the power or temperature is adjusted, the fans will turn on. When the cooktop is turned off, the fans will remain on and automatically turn off when the cooktop is cool enough.
- Page 20 Touch the heating zone selection button. Note: This applies to 2.3kW model only. Turn the cooking zone on by touching the “+” Touch the timer button, the timer indicator shows “30” Note: This applies to 2.3kW model only. Set the time by touching the buttons ...
- Page 21 Touch the heating zone selection button, and then touch the button “Timer”, the timer is cancelled, and the “--” will show in the timer display Note: This applies to 2.3kW model only. When the time is set, it will begin to ...
-
Page 22: Maintenance And Cleaning
6. Maintenance and Cleaning What are the causes? How to clean? Daily soiling on the Disconnect the power from the main. glass surface When turning off the power to the (fingerprints, marks, cooktop, there will be no indication of a food stains or hot surface, but the cooking zone can still unsweetened spills) -
Page 23: Servicing
or paper towel. Reconnect the power. Dirt and spill stains on Disconnect the power from the main. the control panel Clean the control panel area with a clean, damp sponge or cloth. Completely dry the control panel area ... - Page 24 There may be a Make sure the small film of control panel area is water or liquid clean and dry. Use on the buttons the pad of your or you may be finger when using the tip of touching the your finger when controls.
- Page 25 you decrease the heat setting. Cookware do not Cookware is not Use cookware heat up and the suitable for suitable for induction induction, with a display shows “ ” Base of the base large enough cooker is too to be detected and small always place in...
- Page 26 Error Code Possible causes How to Rectify E 1 / E 2 Protection against If the voltage at the mains voltage (<85 V) or high outlet is lower or higher voltage (> 285 V) than specified, contact a qualified electrician. Induction coil temperature Contact National...
-
Page 27: Warranty
8. Warranty This product is covered under a 12 months warranty period. Kindly refer to the warranty policy terms and conditions available on Camec website. For further information or assistance, please contact our National Customer Support Team or visit Camec website.
